INSTRUCTIONS FOR USE

Pro-Ject Xtension

Speed Change

45.0

PRO-JECT Xtension

Controls, features and connections

1 Low voltage cable and power supply socket

2 Stepped drive pulley

3 Drive belt * 3a Hook *

4 Platter * (comes in separate box)

5 ON/OFF switch, speed selector

6 Arm board 6a Spirit level

7 Adjustable feet *

8 Lid hinges

9 Lid *

Pulley cover (not shown) *

Record weight (not shown) *

Single adapter (not shown) *

Power supply (not shown) *

Gloves (not shown)

Dear music lover,

thank you for purchasing a PRO-JECT AUDIO record player.

In order to achieve maximum performance and reliability with this record player you should study these instructions

for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable

receptacle.

Before starting assembly make yourself acquainted with the parts listed above and correspondingly numbered

in the technical drawings above. Separately packed items are marked with an asterisk *.

Set-up

Screw the four feet (7) onto the threaded bolts located on the underside of the plinth. Make sure the surface

you wish to use the turntable on is level (use a spirit level) before placing the turntable on it.

Carefully place the platter bearing housing over the bearing axle. Put the record weight on the platter and

level the plinth using the spirit level (6a) and the adjustable feet (7).

Fit the drive belt (3) around the platter (4) and the smaller diameter part of the motor pulley (2).

Avoid getting sweat or grease on the belt as these will deteriorate the performance and reduce the belt's

lifespan. Use absorbent kitchen paper to remove any oil or grease from the outer edge of the hub and the belt.

Put the pulley cover on its rests.

Pro-Ject Evolution tonearms

Cartridge downforce adjustment

Remove the transport lock (3) from the tonearm. Store it in the original packaging so they are available for

any future transportation.

Pushing carefully, turn the counterweight (7) onto the rear end of the tonearm tube (2), and so that the

downforce scale (7a) shows towards the front of the player. Lower the armlift and position the cartridge in the

space between arm rest and platter. Carefully rotate the counterweight (7) until the armtube balances out.

The arm should return to the balanced position if it is moved up or down. Do not forget to remove the

cartridge protection cap if fitted.

Once the arm is correctly balanced return it to the rest (3). Hold the counterweight (7) without moving it, and

gently revolve the downforce scale ring (7a) until the zero is in line with the anti-skating prong (8). Check

whether the arm still balances out.

Rotate the counterweight counter clockwise (seen from the front) to adjust the downforce according to the

cartridge manufacturer's recommendations. One mark on the scale represents 1 mN (= 0,1g / 0,1 Pond) of

downforce.

Tonearm Pro-Ject 9cc Evolution: The counterweights (7) supplied are suitable for cartridges weighing

between 5 - 7,5g, 7 - 10g, 9 - 11g or 10 - 14g.

Tonearm Pro-Ject 12cc Evolution: The counterweights (7) supplied are suitable for cartridges weighing

between 4 - 7g, 6 - 9g, 8 - 12g oder 10 - 15g.

Adjust the downforce prior to installing the anti-skating weight.

1 Headshell with finger lift

2 Tonearm tube

3 Tonearm rest and removable transport lock

4 Tonearm lift lever

5 Anti-skating weight *

6 Anti-skating weight wire support

7 Tonearm counterweight * 7a Downforce scale

8 Anti-skating weight adjustment scale

9 Tonearm base

Adjusting the azimuth

The cartridge needle must be vertical in the record groove in order to trace the

groove wall modulations correctly.

A small screw at the bearing end of the arm allows incorrect azimuth to be

corrected if your needle is not mounted exactly perpendicular to the cartridge

body (which is often the case).

Slacken off the screw just enough to be able to revolve the arm tube without

applying force. Note! Do not remove the screw completely!

Screw

With the aid of a good magnifying glass adjust the needle until it is vertical in the groove (i.e. perpendicular

to the record's surface). Ideally this should correspond to the top surface of the cartridge body being parallel

to the record surface, but in practice this is often not the case.

When you are satisfied that the needle is vertical retighten the screw carefully.

Under no circumstances should the arm tube be adjusted with the needle still in the record groove!

Irreparable damage may be caused to the cantilever suspension! The arm must be lifted to make

each adjustment and lowered afterwards to check it.

Anti-skating force adjustment

The anti-skating force must be adjusted corresponding to the downforce as follows:

Downforce Groove in the stub (15)

10 - 14mN 1st from bearing rings

15 - 19mN 2nd " " "

20mN and bigger 3rd " " "

Hang the loop of the thread of the anti-skating weight in the groove of the anti-skating stub (15) corresponding

to the downforce applied to your cartridge and hang the thread in the groove of the wire support (17).

Adjusting the vertical tracking angle -vta-

Put a record on the platter. When the needle is lowered into the record groove and the tonearm is not resting

on the tonearm rest (3), the tube (2) of the tonearm should be parallel to the surface of the record.

If it is not loosen both hexagon screws in the tonearm base (9) just enough to allow vertical movement of the

arm pillar without force and slide the arm up or down until it is parallel.

Carefully retighten the hexagon screws without applying excessive force (which would deform the arm pillar)

– finger tight is quite sufficient.

Fitting and connecting the cartridge

All cartridges with half inch mounting holes can be fitted. Leaving the needle's protection cover on, fit the

cartridge to the headshell using the screws supplied with the cartridge by passing one screw through each

slot in the headshell (1). Do not tighten the nuts yet.

Connect the tonearm wires to the cartridge pins as follows:

white left channel positive (L+)

red right channel pos. (R+)

green right channel return (R -)

blue left channel return (L -)

The full sound quality of the record player can only be achieved if the cartridge is correctly adjusted. Particular

tools like the PRO-JECT alignment tool are required to accomplish this job properly. If you are not well acquainted

with the adjustment of cartridges you are advised to call upon the willing help of your PRO-JECT dealer to

accomplish this task for you.

Please note: adjusting a cartridge and tonearm calls for the greatest care in order to avoid damaging

the cartridge or tonearm bearings. Leave this work to your dealer if you are in any way unsure of the

necessary steps and precautions to be taken.

Connection to the amplifier

Connect the tonearm cables to the Phono input (sometimes labelled gram, disc or RIAA) on your amplifier.

Make sure that the phono input offers correct matching and amplification for the type of cartridge used. Line

inputs (such as CD, Tuner, Tape or Video) are not suitable.

Take care to connect the left and right channels correctly. The right channel is usually marked red, the left

channel black or white. Check the manual supplied with your amplifier for relevant information. An earthing

wire may be connected to the screw terminal between the sockets if you encounter hum problems when using

the record player.

If your amplifier does not have an input suitable for phono cartridges you will require a separate phono

amplifier stage for MM or MC cartridges such as the PRO-JECT PHONO BOX or the PRO-JECT TUBE BOX

which is then connected between the record player and a free line level input of the amplifier.

For detailed product information please refer to the Pro-Ject web site www.project-audio.com.

Mains power connection

The turntable is supplied with a power supply suitable for your country's mains supply. Check the label before

connecting to ensure compliance with the mains rating in your house.

Connect the low voltage plug from the power supply to the socket (1) on the rear of the record player before

connecting the power supply to the mains.

Fitting the lid

Fit the lid (dust cover 9) carefully over the hinge prongs and adjust the screws (8) until the lid stays open

where you want it to without being too stiff to open or close.

Starting the motor, Stand By

Pressing the button Speed Change will switch on the player from stand by. Press and hold the button Speed

Change to put the unit into stand by.

Changing replay speed

The belt must be on the smaller (50Hz models) larger (60Hz models) diameter part of the motor pulley.

Press the button Speed Change to switch between 33 and 45 r.p.m.. The selected speed will be displayed

digitally.

To replay records at 78 r.p.m. perform the following steps: Remove the pulley cover. Using the tool (3a), fit

the belt (3) around the larger (50Hz models, for 60Hz models the smaller diameter has to be used) diameter

step of the pulley (2). Start the turntable by pressing the button Speed Change and switch the speed to

45 r.p.m., the platter will then revolve at 78 r.p.m.. The display still shows 45 r.p.m..

Speed Change +

45.0

Pitch control

Repeatedly pressing the +or -buttons increases or decreases the replay speed in twenty steps of 0,1 r.p.m.

respectively. The adjusted speed is displayed digitally.

Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with the supplied antistatic cloth.

It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid damage.

If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.

Always disconnect the record player from the mains power supply as a precaution before maintenance!

Useful tips

The base and the record player should be positioned on a low-resonance surface such as wood or multiple

layer ply board to avoid structural vibrations disturbing replay.

Technical specifications PRO-JECT Xtension

* Electronic speed change * 33,33/* 45,11 and 78 r.p.m.

Speed variance ±0,09 %

Wow and flutter ±0,01 %

Signal to noise -73dB

Power consumption 2W

Outboard power supply 16V/1.000mA AC, suitable for your country's mains supply

Dimensions (W x H x D) 550 x 250 x 450mm, dust cover open 550 x 550 x 560mm

Weight 20kg

Technical specifications Pro-Ject 9cc Evolution

Tonearm medium mass

Supplied counterweights cartridge weight 5 - 7,5g, 7 - 10g, 9 - 11g or 10 - 14g

Downforce range 10 - 35mN

Effective tonearm length 9 " (230mm)

Overhang 18mm

Tonearm cable length approx. 120cm

Weight 265g (without counterweight)

Technical specifications Pro-Ject 12cc Evolution

Tonearmn medium mass

Supplied counterweights cartridge weight 4 - 7g, 6 - 9g, 8 - 12g or 10 - 15g

Downforce range 10 - 35mN

Effective tonearm length 12 " (304,8mm)

Overhang 13,2mm

Tonearm cable length approx. 120cm

Weight 271g (without counterweight)

Potential incorrect use and fault conditions

PRO-JECT turntables are manufactured to the highest standards and undergo strict quality controls before

leaving the factory. Faults that may possibly occur are not necessarily due to material or production faults but

can sometimes be caused by incorrect use or unfortunate circumstances. Therefore the following list of common

fault symptoms is included.

The platter doesn't turn although the unit is switched on:

The unit is not connected to the mains power supply.

No mains at the socket.

Drive belt is not fitted or has slipped off.

No signal through one or other channel or both channels:

No signal contact from the cartridge to the internal tonearm wiring or from that to the arm lead or

from that to the phono box or between that and the amplifier. This could be due to a faulty plug,

broken wire or solder joint or simply loose plug/socket connection.

Phono input not selected at amplifier.

Amplifier not switched on.

Amplifier or speakers defective or muted.

No connection to the loudspeakers.

Strong hum on phono input:

No earth connection from cartridge or arm or arm cable to amplifier, or earth loop.

Distorted or inconsistent sound from one or both channels:

Record player is connected to wrong input of amplifier, or MM/MC switch incorrectly set.

Needle or cantilever damaged.

Wrong r.p.m., drive belt overstretched or dirty, platter bearing without oil, dirty or damaged.

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,

please contact your dealer for further advice. Only when the problem cannot be resolved there should the

unit be sent to the responsible distributor in your country.

Guarantee repairs will only be effected if the unit is returned correctly packaged. For this reason we recommend

keeping the original packaging.

Never return a record player without making sure that is it safely disassembled and correctly packaged in the

original packaging according to the supplied diagram. Please remove these parts and pack them separately:

feet, counterweight, platter, cartridge and belt. Fit the cartridge protection cap. Insert the transport lock for

the tonearm prior to carefully packaging the record player.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions

for use and/or by transportation without the original packaging. Modification or change to any part

of the product by unauthorized persons release the manufacturer from any liability over and above

the lawful rights of the customer.

PRO-JECT is a Registered Trademark of H. Lichtenegger.

This guide was produced by: Audio Trade GmbH

The information was correct at the time of going to

press. The manufacturer reserves the right to make

changes to the technical specification without prior

notice as deemed necessary to uphold the ongoing

process of technical development.

Altri manuali per Xtension

Indice

Altri manuali Pro-Ject Audio Systems Giradischi

Pro-Ject Audio Systems

Pro-Ject Audio Systems Xtension 10 Evolution Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems SIGNATURE 10 Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems 1 Xpression Carbon Classic Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems 2 Xperience Basic + Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Elemental Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems 2 xperience sb s Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject DEBUT III PHONO SB Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Essential II Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Essential II DIGITAL Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut PRO Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems T1 Phono SB Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems 1 Xpression III Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Juke Box Series Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut III Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut Carbon Esprit SB Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 10.1 Evolution Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 9.1 Acryl Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject RPM 1.3 Genie Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Primary E Phono Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems 2 Xperience Basic + Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems ESSENTIAL III Guida alla risoluzione dei problemi

Pro-Ject Audio Systems

Pro-Ject Audio Systems Xtension Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems Speed Box MK II Manuale utente

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 5.1 Manuale utente

Manuali Giradischi popolari di altre marche

Gemini

Gemini CDT-05 MKII Manuale utente

Rotel

Rotel RP-820 Manuale utente

Shuman

Shuman MC-250BT Manuale utente

Stanton

Stanton STR8-150 Manuale utente

Audio Technica

Audio Technica AT-LPW40WN Manuale utente

Crosley

Crosley McQueen CR7011-GY Manuale utente

Reloop

Reloop SMP-1 Manuale utente

auna

auna TT-Classic Plus Manuale utente

COMO AUDIO

COMO AUDIO Turntable Analog Manuale utente

Dual

Dual 1009 F Manuale utente

REED

REED Muse3C Manuale utente

AXIOMTEK

AXIOMTEK OPS883-H Series Manuale utente

Pioneer

Pioneer PL-71 Manuale utente

Vestax

Vestax PDX-a1 Manuale utente

Denon

Denon DP-400 Manuale utente

Dual

Dual 504 Manuale utente

Audio-Techica

Audio-Techica AT-LP60XBT Manuale utente

Goldring

Goldring G99 Manuale utente
