MICROWAVE CONCENTRATION

MEASUREMENT

µ-ICC 2.45 compact

- MANUAL -

S/N: A01-PG10-MAE

Software version from V.0.21

Version No.: V3 2010-10-01

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

1Safety instructions .................................................................................................................... 3

1.1 Symbols and indices ........................................................................................................... 3

1.2 Conventional usage............................................................................................................. 3

1.3 General safety & warning notices ...................................................................................... 3

1.3.1 Environmental conditions........................................................................................... 4

1.3.2 Electrical treatments ................................................................................................... 4

2System description µ-ICC 2.45 compact ................................................................................ 5

2.1 Measuring principle............................................................................................................ 5

2.2 Components ........................................................................................................................ 7

2.2.1 Evaluation unit............................................................................................................ 7

2.2.2 Sensor with probes...................................................................................................... 8

2.2.3 Cables ......................................................................................................................... 8

2.3 Installation .......................................................................................................................... 9

2.3.1 Installation of the Evaluation unit .............................................................................. 9

2.3.2 Connections and dimensions of the evaluation unit ................................................... 9

2.4 Installation recommendations........................................................................................... 13

3Menu topology and operation handling................................................................................ 15

3.1 Standard operation of the compact device........................................................................ 15

3.2 Operation via PC Remote ................................................................................................. 16

4First Start Up .......................................................................................................................... 19

4.1 Language .......................................................................................................................... 19

4.2 Date and Time .................................................................................................................. 19

4.3 System Reset..................................................................................................................... 19

4.4 Locking Keyboard ............................................................................................................ 20

4.4.1 Changing PIN number .............................................................................................. 20

4.4.2 Keyboard locking ..................................................................................................... 20

4.4.3 Keyboard unlocking ................................................................................................. 20

5Initial Sensor Configuration .................................................................................................. 21

5.1 Measurement mode........................................................................................................... 21

5.2 Amplification.................................................................................................................... 21

5.3 Measurement .................................................................................................................... 22

5.3.1 Temperature compensation....................................................................................... 22

5.3.2 Start coefficients ....................................................................................................... 22

5.3.3 Reference Point......................................................................................................... 23

5.4 Other Settings ................................................................................................................... 24

5.4.1 Sensor Description.................................................................................................... 24

5.4.2 Current Interface....................................................................................................... 24

6Data logging............................................................................................................................. 25

6.1 SD Card ............................................................................................................................ 25

6.2 USB HID .......................................................................................................................... 26

7Calibrating .............................................................................................................................. 27

7.1 Sampling........................................................................................................................... 27

7.2 First calibrating................................................................................................................. 27

7.3 Phase correction with level............................................................................................... 28

8Sensor Settings: save and reload ........................................................................................... 29

8.1 Sensor: Save settings, Load settings, Factory settings ..................................................... 29

8.1.1 How to save configuration........................................................................................ 29

8.1.2 How to load previously saved configuration............................................................ 29

8.1.3 How to reload factory settings.................................................................................. 29

8.2 Memory allocation: Load and Delete Internal and External Memory.............................. 29

8.2.1 Copying of configuration.......................................................................................... 29

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

8.2.2 Deleting of configuration.......................................................................................... 30

8.2.3 Deleting of all memory............................................................................................. 30

9Moving of the measuring range............................................................................................. 31

10 Troubleshooting ...................................................................................................................... 32

10.1 PIN is not working............................................................................................................ 32

10.2 Constant offset.................................................................................................................. 32

11 Technical specifications.......................................................................................................... 33

12 Spare parts .............................................................................................................................. 34

13 Declaration of Conformity..................................................................................................... 35

14 Dimensional drawings ............................................................................................................ 36

14.1 Flat sensors with Inline-Gage DN 40 to 150 .................................................................... 36

14.2 Insertion sensor DN65 ...................................................................................................... 37

14.3 Rinsed insertion sensor DN65 .......................................................................................... 38

14.4 Insertion sensor DN80 ...................................................................................................... 39

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

1 Safety instructions

1.1 Symbols and indices

In this manual there are consecutive symbols used to indicate safety

instructions.

Warning

possibility of danger for life and health

Attention

possibility of danger with light personal damages

Notice

possibility of material damage

Information

appliance tips and information

1.2 Conventional usage

The µ-ICC 2.45 compact is a measuring system based on a microwave

transmission technology. Therefore the product is transmitted by a very low

capacity of microwave radiation. The microwaves are completely harmless for

human and the environment. So there is no change of product properties.

This measuring system is produced according the latest safety requirements

for microwave devices. If there are legal regulations regarding the use of

microwaves the user has the responsibility to observe it.

It is not allowed to change the frequency of the device. Furthermore other

manipulation within the device could involve criminally consequences.

1.3 General safety & warning notices

The µ-ICC 2.45 compact is build with all included components according to

the latest state of technology and approved safety standards.

The housing is IP 65 certified and dedicated for outdoor use. Factory-

provided it is proofed and will be delivered reliably.

The safety and warning notices have to be strictly adhered to guarantee a

safe operating. The operating is only allowed if the system is in good order

and condition. There are only those persons allowed to operate with this

system, who are briefed and qualified. Reconstructions or changes, which

may have an influence on a safety operating are prohibited specifically.

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

1.3.1 Environmental conditions

All components require non-corrosive environmental conditions while

transporting, stocking and operating.

1.3.2 Electrical treatments

The power supply must be interrupted during the installation and also for

technical service to avoid getting in contact with energized parts.

Before opening the evaluation unit the power supply must be interrupted! It’s

prohibited to work with opened device while it’s energized!

Spare part fuses must have the manufacturer specified values. To shorten

the circuit or any other manipulation are prohibited!

The evaluation unit must be earthed when it is mains-connected.

If there has gotten fluids into the device, it has to be interrupted the power

supply. Successive the device has to be controlled and cleaned by an

authorized person.

Without exact knowledge of this manual there must not be changes on the

installation or on any parameter settings. In addition there has to be known

the possible behaviour of the actuator and the influence on the

process.

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

2 System description µ-ICC 2.45 compact

The µ-ICC 2.45 compact is a measuring device which combines a compact

housing with the latest technical standards in microwave measurement. It is

based on the successful and long time proofed µ-ICC 2.45.

In addition to the compact housing, this device comes with a lot of new

features like higher class components, simplified handling (like USB plug-in

for connection with a PC or an additional sample push-button) and also an

improved memory mode. The device is placed nearby the measuring location,

where it’s directly connected to the microwave sensor probes.

This manual will give you an explanation of the very simple handling and

implementation of this system.

2.1 Measuring principle

Precondition for a successful measurement is the dielectricity of the medium.

Thus water contained products are in general good to measure, because the

microwaves are absorbed by free water molecules.

Another dependency is the distance between the sensor probes. Here it is

important that the signal strength is quite enough to get from the transmitter

to the receiver. Therefore proMtec offers the best fitting geometry for each

special application.

Reference signal

Phase shift

Attenuation

Transmitter

Receiver

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

•The microwave signal is conducted into the medium by the transmitter. The

receiver collects the alleviated microwaves.

•The reference signal has the typical propagation without any influences. It is

used as a comparison with the alleviated microwave signal, to calculate a

phase shift (decrease of propagation velocity) or an attenuation.

•The phase shift is a decrease of the propagation velocity

•With this information it is calculated a value for the water content, density or

total dry matter content.

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

2.2 Components

The measuring system is composed of two components – the evaluation unit

and the sensor probes. These probes are mounted into a pipe section (with

flat sensor probes) or into a vessel (insertion sensor probes) and are

connected via microwave cables with the evaluation unit.

The system is – like the standard version – temperature compensated.

Therefore it has to be connected to a temperature sensor, which is also

included within the system.

2.2.1 Evaluation unit

The evaluation unit is available in different types. As standard there is the

complete version with all features, alternatively it is also a version available

which is delivered without the display. Therefore it must be operated with a

PC via USB connection.

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

2.2.2 Sensor with probes

proMtec offers a great variety of sensor types. Depending on the several

application proMtec designs the best fitting sensor type for implementing in

your process without complexity.

Standard versions are on the one hand inline pipe sections, where flat sensor

probes are fitted onto the pipe. On the other hand there are insertion sensors

with two probes used in a special flange for installation in vessels.

In each case the evaluation unit is directly connected with the sensor probes

via microwave cables.

2.2.3 Cables

The microwave cables attend to carry the signal directly to the measuring

point and backwards to the evaluation unit. These cables are produced in

accordance to the newest technology and with the best available shielding

and assure a low-loss propagation.

The cables are delivered with a length of one to three meters (depending on

the requirements). Despite the high shielding the cables should be as short

as possible to avoid too much power loss.

The temperature sensor itself is already mounted into the pipeline

respectively the insertion sensor tube. So you’ve just to connect the cable

with the sensor and on the other side with the connectors inside the device

(read chapter 2.3.2).

Erro! Use a guia Início para aplicar Überschrift 1 ao texto que deverá aparecer aqui.

2.3 Installation

2.3.1 Installation of the Evaluation unit

The device is delivered with a sub plate with four holding flaps (H x B = 120 x

180 mm for Ø 6 mm).

In cause of the limitation of microwave cables you should find a place nearby

the measuring location, where you can also operate comfortably. If there is no

adequate place for a comfortable operation, there is also the option to

operate with your PC via integrated USB port.

2.3.2 Connections and dimensions of the evaluation unit

To get an overview about the circuit points and the way how to connect

them, there is following connection list.

Before opening the evaluation unit and for connecting of any cable the power

supply must be interrupted!

Choose a dedicated mounting location that the cables are strain-relieved!

Do not snap the microwave cables!

With connecting of the signal output mind the polarity! This signal output is an

active current output.

Do not torque down the coupling nuts onto the evaluation unit too much!

Indice

Manuali Strumento di misura popolari di altre marche

Suaoki

Suaoki D40 Manuale utente

Elster

Elster BK-G1.6 Manuale utente

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuale

Duratool

Duratool D03128 Manuale utente

Vega

Vega VEGAPULS 65 Manuale utente

Tonghui

Tonghui TH2618B Manuale utente

Tenmars

Tenmars TM-801 Manuale utente

MSR

MSR 145 Manuale utente

TPS

TPS WP-82 Manuale utente

ELMETRON

ELMETRON CP-511 Manuale utente

PCB Piezotronics

PCB Piezotronics 003C30 Manuale utente

Tenma

Tenma 72-10465 Manuale utente

Endress+Hauser

Endress+Hauser Proline Promag 50 Specifiche tecniche

Siemens

Siemens SITRANS F Coriolis FCT030 Manuale elenco delle parti

KLINGER

KLINGER CMF V Series Manuale utente

EXFO

EXFO FTB-2 Manuale operativo e di manutenzione

Keysight

Keysight M8290A Manuale utente

ADTEK

ADTEK MW-5 Manuale utente

proMtec u-ICC 2.45 compact Manuale utente

Manuali Strumento di misura popolari di altre marche
