Pyle Pro PSS1542 Manuale utente













 





Introduction

Thank you for purchasing this Pyle Pro PSS series speaker. The

loudspeaker is designed to provide you years of high performance in any

application that you require. Please read this manual carefully to fully

maximize the performance of the speaker.

Maintenance and Safety

• Do not expose the speaker to moisture.

• Avoid hot and cold temperature extremes.

• Clean using a damp cloth. Make sure that no moisture contacts the

drivers. You can use a hand vacuum to clean the carpet.

• Do not attempt to service the unit. Refer service to a certified Pyle Pro

technician.

• This loudspeaker is capable of producing extremely high SPL levels.

Use earplugs when necessary.

Features

The PSS series features high-level

drivers and rugged components and is designed

for high-performance applications.

The cabinet features heavy-duty

construction with reinforced corners. It is

covered with a black-carpeted finish that will

stand up to years of tour duty. The integrated

handles have been carefully selected for their

ergonomic design and durability. There are

heavy-duty caster wheels for easy mobility.

Both models are loaded with two (2)

premium Kapton voice coil woofers and exhibit

excellent bass response. The compression

driver provides warm midrange reproduction

and crystal clear highs and is complemented by

two piezo tweeters.

The integrated passive crossover network



is assembled using quality components and efficiently directs the

frequencies to the proper drivers.

Connections

Your PSS series

speaker has an extremely

flexible connection panel.

There are two Speakon jacks

as well as two ¼” jacks. You

can also hookup your speaker

cabinet using the “Quick

Connect” speaker terminals,

which accommodate either

wire leads or a banana plug.

The jacks are wired in

parallel, which allows you to

daisy chain additional

speakers. Thus you can use one amplifier channel to power multiple

speakers.

Make certain that the wires you are using are at least 12 gauge

unshielded speaker cable (the lower the number, the thicker the wire). Do

not use shielded “instrument” cables.

Hooking speakers up in parallel decreases the overall

impedance, placing a greater load on the amplifier. Check your

amplifier’s specifications to ensure that you are not overloading

the channel.

CAUTION: DO NOT USE MORE THAN ONE JACK AS AN

AMPLIFIER INPUT. DOING S O WILL DAMAGE THE S PEAKER!

Amplifier Requirements

Check the product specifications (page 5) to see the power handling

for your model. There are a couple of considerations to keep in mind when

choosing an amplifier to drive your PSS series speaker. While it is true that

an amplifier with a higher power rating can damage the drivers, under-



powering can be even more dangerous. When an amplifier is overdriven and

starts distorting, it generates transient frequencies that are much louder than

the program material. These wayward frequencies could damage your

speaker. A proper match is an amplifier which could drive the speaker up to

the cabinet’s RMS rating, without exceeding the amplifier’s own RMS level.

Operation

When powering on your equipment, make sure the volume level on

the amplifier is turned all the way down. This is to avoid the “popping”

noise, which could damage your speaker.

The placement of speakers can be a bit tricky. Besides for the

practical considerations, there are acoustic issues as well. Avoid placing the

speaker in a corner, as this will cause the low frequencies to sound “muddy”.

Similarly, but to a lesser degree, placing the speaker directly against the wall

will exaggerate the low frequencies. You should therefore try to place your

speaker so that it is a few feet away from the wall.

High frequencies are unidirectional while low frequencies are omni

directional. Being that this is a full range enclosure, it is important that the

speaker be placed so that the high frequencies reach the intended listeners

properly. Make certain that no person or object could come to interrupt the

line-of-site between the loudspeaker and the audience.

When using more than one loudspeaker, you have to account for

phase alignment. When the speakers are close together this is not usually an

issue. However, when they are far apart, the sound from one speaker may

reach the ear a fraction of a second before the other. This will cause certain

frequencies to cancel out, resulting in a hollow sound. To avoid this, you

may have to use a delay processor to align the sound from the speakers.



Troubleshooting

No Sound:

Check connections

Try a different speaker cable

Check levels on amplifier

Confirm amplifier is getting a signal (check signal LED, or use

headphone output)

Intermittent Output:

Check connections

Try a different speaker cable

Weak Bass:

Check the polarity of the speaker connection. It may be reversed.

Listen with headphones to confirm the amplifier is being sent a good

signal.

Distorted Sound:

Check if the amplifier is overdriven. If it is, you will have to turn the

level down.

Make sure you are not exceeding the RMS rating of your speaker.

Specifications

  











   ! 



"#$#%  Ω 



&

 #'()

")%

#'*

+

,



(*-#.*



/

$



")%

0*





)'1).!/



2..



#(..



#.03

!")%

4″")%

56!*

"783%



8Ω



9).*

9#:;*

/9(0'*

<'=

 #<()



")%#<*

+

,



'*-#'*



/

$



")%

0*





).1).!/



:..



#<..



#.'3

!")%

4″")%

56!*

"783%



8Ω

9)(<*

9)0;*

/9'.;*

#..=



Parallel Setup

Typical Setup



Recommended Accessories









  





    ! "



  





 





    ! "





 



 





    ! "





  

  

   #$%   

 &' $  

 (  %   

)*+ 









 

   #$%   

 ' $  

 (  %   

)*+ 









Check out these and other accesso

ries at www.pyleaudio.com
