Quinny Moodd CV078 Manuale utente

French Guide Included

Guide français inclus

CV078

User Guide

Guide d’utilisation

Parts List Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly To Use

To Use

Warnings 1

Parts List 2

Assembly 3-5

To Use 6-7

Install Infant Car Seat 8

To Remove Seat Pad 9

Stroller Care and Maintenance 10

Replaceable Parts 10

Warranty 10

Guide d’utilisation français: 10

English User Guide:

Avertissements 1

Liste de pièces 2

Assemblage 3-5

Utilisation 6-7

Installation du Siège d’auto pour bébé 8

Enlever la housse du siège 9

Pièces de remplacement 10

Soin et Entretien de la poussette 10

Garantie 10

Guide d’utilisation français

Parts List

Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly To Use

To Use

FOR THE SAFETY OF YOUR CHILD, PLEASE READ THE FOLLOWING WARNINGS AND ASSEMBLY

INSTRUCTIONS AND KEEP FOR FUTURE REFERENCE.

• Adult assembly required.

• CAUTION: Keep small parts away from children during assembly.

• NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when in stroller.

• AVOID SERIOUS INJURY from falling or sliding out. ALWAYS use seat belt. Check frequently to make sure it is secure.

• ALWAYS keep fingers away from moving parts, when folding, unfolding or adjusting stroller to prevent

finger entrapment.

• ALWAYS make sure stroller is FULLY OPEN AND LOCKED before using.

• ALWAYS use the brakes when stroller is stopped.

• ALWAYS remove protective material and poly bags and dispose before assembly.

• NEVER use stroller on stairs or escalators.

• NEVER rollerblade with stroller.

• NEVER allow children to play with or hang onto the stroller.

• NEVER allow children to climb into the stroller unassisted. Stroller may tip over and injure child.

• NEVER place or hang parcels, bags or accessories on the handle or canopy. The stroller may tip over or the

canopy may collapse.

• This product will become unstable if a parcel bag or rack is used when there is no provision for one.

• This product may become unstable if a parcel bag, other than the one recommended by the manufacturer is used.

• This product will become unstable if the manufacturer’s recommended load is exceeded.

• DO NOT carry additional children, goods or accessories in or on this product except as recommended in the

manufacturer’s instructions.

• NEVER place more than 11-LBS. (5-kg) in the storage basket. If weight is exceeded, hazardous unstable

conditions may exist.

• STROLLER is only for use with children up to 50-LBS. (22.73-kg), and WHEN SEATED, the midpoint of the

child’s head is at or below the top of the stroller seat.

• ONLY use this stroller with ONE child at a time.

• STROLLER is for use with children who can sit up unassisted, and is NOT recommended for newborns.

WARNING

Parts List

Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly To Use

To Use

Adjustable height handle

Seat

Canopy

Canopy inserts (2)

Front bar

Front bar insert plate

Rear wheels (2)

Front wheel unit

Transport strap

Shopping basket

Maxi-Cosi Mico

car seats and

Quinny Dreami

bassinet adapters* (2)

* Maxi-Cosi Mico

Infant Car Seats and Quinny

Dreami

bassinet sold separately.

• Keep these instructions for future use.

• Lay out and identify all parts.

• Do not return this product to the place of purchase.

If any parts are missing, call Consumer Relations at

(800) 951-4113. Or visit our website at

www.quinny.com.

• Include the model number and manufacture date

(found on the bottom rail of stroller).

Parts List Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly To Use

To Use

1 Install Rear Wheels

Slide the rear wheel axle into

the frame until you hear a “click”

(Figure 1). Repeat for other rear

wheel. Pull to confirm each is

assembled securely.

3 Install Front Wheel Unit

Squeeze the front wheel fork

while inserting it into the frame

tube. Push front wheel into frame

tube until you hear a “click”

(Figure 3).

Pull to confirm it is assembled

securely.

2 Attach Shopping Basket

Slide basket onto frame tube

through opening (Figure 2) then

slide tab into tube at the front

center (Figure 2a).

Secure hook-and-loop strap

around frame above each rear

wheel (Figure 2b).

4 Unfold Stroller

Unfasten transport strap

(Figure 4).

Push back on frame lock to

release and gently pull up on

frame from handlebar (Figure 4a).

Frame will begin to unfold

automatically and click into place

(Figure 4b).

5 Adjust Handlebar Height

Squeeze the adjustment button

and slide the handlebar to desired

height (Figure 5). The handlebar

will click into place.

6 Parking Brake

Always use the parking brake,

even when standing still for only a

few moments! Push firmly down

on the red pedal (P) behind the

rear wheel to set the parking

brake (Figure 6). Push the

opposite pedal to release the

parking brake.

NOTE: The Moodd stroller frame has

a unique mechanism that enables the

automatic unfolding of the frame. The

temperature can affect the functioning

of this mechanism. In cold or frosty

weather, the stroller may unfold

more slowly than usual (at room

temperature).

Parts List Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly

To Use

7 Attach Seat Facing Handlebar or Forward

Slide both sides of the seat into the frame until you hear each side

click.

To Recline Seat Facing Handlebar or Forward

To recline the seat use recline mechanism located behind seat. Recline

to desired position, seat will click into place (Figure 7). There are only

THREE positions in each orientation.

NOTES: The seat can be positioned facing the handlebar or forward. The

Moodd stroller seat is suitable for children from 6 months (maximum

50-LBS. / 22.73-kg).

8 To Remove Seat

Squeeze up on the buttons on both sides (Figure 8) and lift the seat

from the frame (Figure 8a).

NOTE: When buttons are depressed they stay depressed until the

seat is locked into the stroller.

88a

Parts List Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly To Use

To Use

10 Front Bar

Remove insert on seat from underneath as shown by pushing on

depression underneath (Figure 10). Slide front bar into place until it clicks.

Attach elastic underneath seat as shown (Figure 10a).

To Remove Front Bar

Unhook elastic under seat. Push depression under seat and slide front bar

out (Figure 10b). Replace with front insert (Figure 10c).

10b

10a

10c

9 Canopy

Remove inserts before

installing canopy (Figure 9).

Align tabs to rails on each side

of seat and slide down into

place (Figure 9a).

Unsnap and pull back top of

seat fabric. Line up tab on top

of canopy with top of seat

and slide into place until it

clicks (Figure 9b).

NOTE: Once canopy is fully

attached re-attach the seat

pad.

Parts List Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly

To Use

11 Footrest

To adjust the footrest up, pull

footrest up. To adjust down,

press the buttons on both sides

and push down (Figure 11). 2x

12 Swivel Wheel

Lock the swivel wheel when using

the stroller in a straight direction

for a long period. To lock, push

the lock lever downward and

rotate wheel until it locks into

place (Figure 12). To unlock,

push the lock lever upward.

13 To Use Restraint

System

Unbuckle restraint system by

pressing center button. Place

child in seat. Fit clips together.

Slide clips into buckle until you

hear a “click” (Figure 13).

To tighten strap, pull strap end

down (Figure 13a).

To loosen strap, back strap

back through loops (Figure

13b).

Adjust straps snugly around

your child (Figure 13a).

WARNING

• NEVER LEAVE CHILD UNATTENDED. ALWAYS keep

child in view when in stroller.

• AVOID SERIOUS INJURY from falling or sliding out.

ALWAYS use seat belt. Check frequently to make sure it is

secure. Belts must be threaded exactly as shown (Fig. 13b).

• Failure to follow these instructions could result in the

serious injury or death of your child.

13a

13b

14 Adjust Restraint Height

The shoulder straps have

three height positions for

your growing child. Unsnap

shoulder cushions from harness.

Unthread shoulder straps

(Figure 14). Push shoulder

straps through back of the seat

pad into the desired slot (Figure

14a). Thread straps as shown

(Figure 14b). Secure restaint

covers with snaps.

14a

14b

TIRE PRESSURE NOTE: Maximum tire pressure is 25-psi. Use a manual

bike pump to inflate tires. NEVER use an air compressor to fill tires

with air (like those used at gas stations).

Parts List Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly To Use

To Use

15 Fold Stroller

NOTE: You have the option of

removing the seat before folding.



Seat must be in forward facing

and upright position. Before

folding stroller we suggest that

you fold back the canopy, lower

handlebar and lock the wheels.

15a

15b

15d

15e

To make the stroller more

compact, you may remove the

wheels. Press the rear wheel

release button to pull each rear

wheel out (Figure 15d).

Stand behind stroller, slide up

tabs on inside of stroller frame

(Figure 15).

Push down on stroller towards

front wheels (Figure 15a).

Continue to fold until stroller

locks into place (Figure 15b).

Press both front wheel release

buttons to pull the front wheel

out of the frame tube (Figure

15e).

With stroller locked and

handlebar adjusted to lowest

position, wrap transport strap

around handlebar and secure

buckle (Figure 15c). Pull strap

to confirm it is assembled

securely.

NOTE: When stroller is in use,

attach buckle to prevent from

dragging.

15c

Parts List Warnings

Assembly

Care & Maintenance

Replaceable Parts

Warranty

To Use

Contents

Assembly

To Use

To avoid serious injury:

• Use ONLY Maxi-Cosi Mico® infant car seat and

Quinny Dreami™ Bassinet with adapters included

with this stroller.

• Please refer to the manufacturer’s instructions

for the use of your infant car seat.

• ALWAYS install car seat facing to the rear of

the stroller.

• ALWAYS use the restraint system in the car

seat.

WARNING

16a 16c

16b

16e

16d

16 Install Maxi-Cosi Mico® Infant Car Seats or Quinny

DreamiTM Bassinet

Push the parking brake pedal down. Remove the seat.

Insert the adapters into the frame hubs until you hear a “click” (Figure 16).

Each adapter is designed to fit into appropriate side. If adapter does not

fit, try other side.

Car seat and bassinet must be positioned so

that child faces the stroller handle (Figure 16a).

Lower car seat or bassinet into car seat adapters until both sides “click”

(Figure 16b).

Pull up on car seat or bassinet to ensure that it is locked into place

(Figure 16c).

To remove car seat, press both buttons on car seat while lifting car seat

up (Figure 16d). To remove bassinet, press both buttons on bassinet

while lifting bassinet up (Figure 16d).

To remove car seat adapters, press release button and slide adapter off

the frame hubs (Figure 16e).

CAR SEAT

BASSINET

Indice

Lingue:

Altri manuali Quinny Passeggino

Quinny

Quinny speedi Guida alla risoluzione dei problemi

Quinny

Quinny Moodd Manuale utente

Quinny

Quinny Buzz Stroller Manuale utente

Quinny

Quinny speedi Guida alla risoluzione dei problemi

Quinny

Quinny ZAPP Guida alla risoluzione dei problemi

Quinny

Quinny ZAPP Manuale utente

Quinny

Quinny ZAPP Manuale utente

Quinny

Quinny yezz Guida alla risoluzione dei problemi

Quinny

Quinny VNC Manuale utente

Quinny

Quinny zapp xtra Cv217 Manuale utente

Quinny

Quinny speedi Guida alla risoluzione dei problemi

Quinny

Quinny Buzz Dreami Manuale utente

Quinny

Quinny ZAPP Guida alla risoluzione dei problemi

Quinny

Quinny SPPEDI Guida alla risoluzione dei problemi

Quinny

Quinny zapp xtra Guida alla risoluzione dei problemi

Quinny

Quinny Buzz Xtra Manuale utente

Quinny

Quinny Yezz CV298 Manuale utente

Quinny

Quinny SENZZ CV061 Manuale utente

Quinny

Quinny Hubb Manuale utente

Quinny

Quinny zapp xtra Manuale utente

Quinny

Quinny BUZZ Guida alla risoluzione dei problemi

Quinny

Quinny yezz Guida alla risoluzione dei problemi

Quinny

Quinny Freestyle 3 XL Comfort Guida alla risoluzione dei problemi

Quinny

Quinny yezz Guida alla risoluzione dei problemi

Manuali Passeggino popolari di altre marche

Hauck

Hauck Priya Trioset Manuale utente

CHILDHOME

CHILDHOME CWQDN Manuale utente

Dreamer Design

Dreamer Design Rebound GST Manuale utente

Britax

Britax STEELCRAFT AGILE Manuale utente

Graco

Graco 7427 Manuale utente

Comfort

Comfort COMPASS Manuale utente

OBaby

OBaby Aura Manuale utente

Tutek

Tutek Tirso Manuale utente

Babify

Babify Dual Plus Manuale utente

Graco

Graco Stroller Manuale utente

Special Tomato

Special Tomato Jogger Manuale utente

Chicco

Chicco CORTINA TOGETHER TWO-PASSENGER STROLLER Manuale utente

Otto Bock

Otto Bock Kimba neo Manuale utente

Milly Mally

Milly Mally ROYAL Guida rapida

Hauck

Hauck DUETT 3 PRAM Manuale utente

BOB

BOB DUALLIE Manuale utente

Nuna

Nuna Pepp Manuale utente

Britax

Britax B2 Manuale utente

Quinny moodd CV078 Manuale utente

Manuali Passeggino popolari di altre marche
