OWNER’S MANUAL

3-in-One Pocket Remote Control

Please read before using this equipment.

15-1990.fm Page 1 Tuesday, December 14, 1999 12:45 PM

FEATURES

Your RadioShack 3-in-One Pocket Remote Control

can replace up to three infrared remote controls.

You can use it to control your TV, VCR, TV/VCR

combination, and cable converter.

Unlike some universal remote controls, the 3-in-One

is preprogrammed with the most commonly used

commands and does not have to learn its commands

from the original remote controls. All you have to do

is tell it which TV, VCR, TV/VCR combination, or ca-

ble converter’s remote controls you want to replace

(by entering 4-digit codes).

This manual includes a list of many manufacturers’

4-digit codes for TVs, VCRs, and cable converters.

Your remote control’s features include:

Powerful Infrared Beam — so you can operate your

remote-controlled devices from a greater distance

than with many of the original remote controls.

Handy Reference Label — provides a convenient

place for you to write down the manufacturers’ codes

for your devices.

Convenient Keypad Design — each key is posi-

tioned for easy operation.

Toll Free Support — you can get expert help for

your remote control by calling 1-888-284-8735.

Note: You need two AAA batteries (not supplied) to

power your 3-in-One Pocket Remote Control.

Plug ’n Power and RadioShack are registered trademarks

used by Tandy Corporation.

15-1990.fm Page 2 Tuesday, December 14, 1999 12:45 PM

CONTENTS

Introduction .................................................................. 4

Preparation ................................................................... 5

Installing Batteries ................................................... 5

Device Types ........................................................... 6

Setting Up Your Remote Control .............................. 6

To Operate your TV/VCR Combination .................... 8

Operation ...................................................................... 9

Punch-Through ........................................................ 9

Turning Punch-Through Off/On ..................... 10

Manufacturers’ Codes ............................................... 11

Cable Converters ................................................... 11

Televisions ............................................................. 13

VCRs ..................................................................... 19

TV/VCR Combinations .......................................... 25

If You Have Problems ................................................. 27

Manual Code Search ............................................. 27

Determining the 4-Digit Code ........................ 28

Troubleshooting ..................................................... 29

Care ............................................................................. 30

Specifications ............................................................ 31

15-1990.fm Page 3 Tuesday, December 14, 1999 12:45 PM

INTRODUCTION

Your RadioShack 3-in-One Pocket Remote Control

was designed to control the most commonly used

functions on your TV, VCR, TV/VCR combination,

and cable converter.

When you set up the remote control, its command

keys work like the keys on your original remote con-

trols. For example, the remote control’s POWER key

works like a key on your original remote control

which might be labeled POWER ON/OFF.

Notes:

• Whenever you use REC on the remote con-

trol, you must press it twice. This safety feature

helps you avoid accidentally recording over

tapes.

• The remote control might not be able to dupli-

cate some of your original remote control’s

seldom-used functions.

Key Function

PUsed in setting up your devices.

POWER, CH +,

CH –, VOL +,

VOL –, MUTE

Operate the same as the corre-

sponding keys on your original

remote control.

CBL, VCR, TV Used when you set up the remote

control to replace your original

remote controls. Also used during

normal operation to tell the

remote control which device you

want to control.

REW , STOP

, FFWD ,

REC , PLAY ,

PAUSE

Control VCR functions.

15-1990.fm Page 4 Tuesday, December 14, 1999 12:45 PM

PREPARATION

INSTALLING BATTERIES

Your remote control requires two AAA batteries (not

supplied) for power. For the best performance and

longest life, we recommend RadioShack alkaline

batteries.

Cautions:

• Use only fresh batteries of the required size and

recommended type.

• Do not mix old and new batteries or different

types of batteries.

• Do not press any of the remote control’s keys

while installing batteries.

Note: The remote control’s built-in memory backup

saves any programmed codes for about 10 minutes

after the batteries have been removed. We recom-

mend you have fresh batteries ready to install as

soon as you remove the old ones.

1. Press the battery compartment cover’s tab and

lift off the cover.

2. Place the batteries in the compartment as indi-

cated by the polarity symbols (+ and –) marked

inside.

3. Replace the cover.

When the remote control’s range decreases or it

stops operating properly, replace the batteries.

Caution: Always remove old or weak batteries. Bat-

teries can leak chemicals that can destroy electronic

parts.

15-1990.fm Page 5 Tuesday, December 14, 1999 12:45 PM

Warning: Dispose of old batteries promptly and

properly. Do not burn or bury them.

Note: Do not place objects on top of the remote con-

trol after you have installed the batteries. This can

press keys for an extended period of time and reduce

battery life.

DEVICE TYPES

You can use the remote control’s device keys to con-

trol the following general types of devices:

TV — TVs

VCR — VCRs and TV/VCR combinations

CBL — Cable converters

SETTING UP YOUR REMOTE

CONTROL

1. Refer to “Manufacturers’ Codes” on Page 11 and

write down the codes for your brand of device on

the 3-in-One’s label.

Note: Some manufacturers have several codes

listed. Try each until you find the right one. See

“If You Have Problems” on Page 27 if you cannot

find the correct code.

2. Press the device key for the type of remote you

are replacing (TV, VCR, or CBL). The red light

blinks.

15-1990.fm Page 6 Tuesday, December 14, 1999 12:45 PM

3. Hold down Puntil the red light blinks twice, then

enter the 4-digit code you wrote down in Step 1

using these keys:

For example, to replace a TV’s remote control

(manufacturer’s code 1432), press TV, hold

down

Puntil the red light blinks twice, then press

VOL +, CH –, CH +, and VOL –.

When the red light blinks twice, the remote con-

trol has accepted the code.

Note: If the code you entered is invalid, the red

light blinks.

4. Point the remote control at your device and

press POWER.Your device should turn off (or

on, if it was off).

If the remote does not operate your device, try

the other codes listed in “Manufacturers’ Codes”

on Page 11 for your brand of TV, VCR, TV/VCR

combination, or cable converter.

5. Repeat Steps 2–4 for additional devices.

Press To Enter

This Number

VOL + 1

VOL – 2

CH + 3

CH – 4

MUTE 5

15-1990.fm Page 7 Tuesday, December 14, 1999 12:45 PM

TO OPERATE YOUR TV/VCR

COMBINATION

1. Locate the codes for your TV/VCR combination

in “TV/VCR Combinations” on Page 25 and

write down the codes for your brand of device on

the 3-in-One’s label.

2. Press VCR. The red light blinks.

3. Hold down Puntil the red light blinks twice, then

enter the 4-digit code you wrote down in Step 1

using these keys:

When the red light blinks twice, the remote con-

trol has accepted the code.

Note: If the code you entered is invalid, the red

light blinks.

4. Point the remote control at your TV/VCR combi-

nation and press POWER. Your device should

turn off (or on, if it was off).

If the remote does not operate your device, try

the other codes listed in “TV/VCR Combina-

tions” on Page 25 for your TV/VCR combination.

Note: Some TV/VCR combinations require a

second code to control volume. If you cannot

get the volume to work, use the TV code listed

in “TV VCR Combinations.” If no TV code is

listed, follow the instructions in “Punch-Through”

on Page 9 to control volume.

Press To Enter

This Number

VOL + 1

VOL – 2

CH + 3

CH – 4

MUTE 5

15-1990.fm Page 8 Tuesday, December 14, 1999 12:45 PM

OPERATION

1. Press the device key for the device you want to

control.

2. Point the remote control toward the device you

want to control, then press the desired com-

mand keys.

3. Repeat Steps 1 and 2 for all other devices you

want to operate.

Note: The command keys on the remote control

work the same as the keys on the original

remote control; however, the labeling might dif-

fer slightly.

4. To turn off the last device you selected, press

POWER. To turn off other devices, press the

device key for the device you want to turn off,

then press POWER.

PUNCH-THROUGH

The punch-through feature lets you alternately con-

trol two different devices without pressing the device

keys for each one.

A TV is often the only device that uses the volume

keys. Punch-through allows you to control the TV’s

volume while the 3-in-One is in any device mode.

With punch-through on, if you press VCR and use

your volume keys, the 3-in-One will control the TV’s

volume instead of the VCR’s volume.

15-1990.fm Page 9 Tuesday, December 14, 1999 12:45 PM

Turning Punch-Through Off/On

If your cable converter or VCR has a volume control,

you might want to turn off punch-through so you can

use the cable converter or VCR’s volume control to

adjust the sound. To turn off punch-through, hold

down Puntil the red light blinks twice, then press

MUTE, MUTE, and CH –. The red light blinks four

times.

Now, when you want to control the volume through

your cable converter, press CBL before using the vol-

ume controls. If you want to control the volume

through your VCR, press VCR before using the vol-

ume controls.

To turn punch-through back on, hold down Puntil the

red light blinks twice, then press MUTE, MUTE, and

CH –. The red light blinks twice.

15-1990.fm Page 10 Tuesday, December 14, 1999 12:45 PM

Indice

Altri manuali Radio Shack Telecomando

Radio Shack

Radio Shack 7-in-1 Remote Control with Lighted Keypad Manuale utente

Radio Shack

Radio Shack 8-IN-ONE REMOTE Manuale utente

Radio Shack

Radio Shack 150-2114 Manuale utente

Radio Shack

Radio Shack 15-303 Manuale utente

Radio Shack

Radio Shack 15-2147 - Universal Remote Manuale utente

Radio Shack

Radio Shack Light and Learn Remote Manuale utente

Radio Shack

Radio Shack 15-2146 - Voice Prompt Universal Remote Manuale utente

Radio Shack

Radio Shack Keychain Manuale utente

Radio Shack

Radio Shack 2-in-1 Remote Control Manuale utente

Radio Shack

Radio Shack Kameleon Manuale utente

Radio Shack

Radio Shack Kameleon 4-in-1 Manuale utente

Radio Shack

Radio Shack 7-in-One IR Manuale utente

Radio Shack

Radio Shack 6-IN-ONE TOUCHSCREEN REMOTE Manuale utente

Radio Shack

Radio Shack 15-1915B Manuale utente

Radio Shack

Radio Shack 7-in-One Home Theater Manuale utente

Radio Shack

Radio Shack Kameleon 4-in-1 Manuale utente

Radio Shack

Radio Shack Wireless Security Keychain Remote Manuale utente

Radio Shack

Radio Shack 15-1925 Manuale utente

Radio Shack

Radio Shack Audio/ Video Remote Control Manuale utente

Radio Shack

Radio Shack 15-1931 Manuale utente

Radio Shack

Radio Shack 63-1166 Manuale utente

Radio Shack

Radio Shack TOUCHSCREEN REMOTE Manuale utente

Radio Shack

Radio Shack 15-1995 Manuale utente

Radio Shack

Radio Shack Kameleon Manuale utente

Manuali Telecomando popolari di altre marche

Panasonic

Panasonic EUR7622KB0 Manuale utente

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione
