USER MANUAL
Save the user manual for future reference
If you have any questions, please contact us to get suppo
Hose-end High
Precision Flow Meter
Model: ICS518
Email
seice@rainpointus.com
Website
www.rainpointonline.com
Free Hotline
US: +1 833-381-5659 (EN)
EU: +44 800-808-5337 (EN DE)
WhatsApp
+1 626-780-5952
WHAT IN THE BOX
A. ICS518 Hose-end High Precision Flow Meter
B. User Manual
C. Teon Sealing Tape
D. Batte Cover Opener
A
B
D
C
PRODUCT OVERVIEW
Hose Tap Connection
Main Unit
3/4" Faucet End Connector
NH Thread/ USA-type
3/4" Faucet End Connector
BSP Thread/ EU-type
1 X CR2032 batte( included)
SPECIFICATIONS
Waterproof
Water Flow Rate
IPX6
0.5~40L/min(0.13~10.6 GPM)
Max Water Consumption 9999.9L or 9999.9Gal
Working Pressure 0.5 ~ 8 bar (7.25 ~ 116 PSI)
Max Flow Rate 2400L/H (636GPH)
Measurement Tolerance
Powered by 1 x CR2032 Button Cell
±8%*
* The conclusion was drawn from using a tube 10 times the length of the
ow meter diameter in the front and a tube 5 times the diameter of the
ow meter in the back, and lling it with water.
QUICK INSTALLATION & PRECAUTIONS
BEFORE START
Inse the opener into the notch at the
back of the device and rotate the
batte coin to remove the batte
case.
Put a CR2032 batte into the batte
compament, and then rmly screw
the batte cover back on
INSTALLING YOUR FLOW METER
Precautions
1. Use the water ow meter in the Out-of-Box Pre-Assembled order to
avoid water leakage.
2. Follow the direction of water ow to install the product to ensure
accuracy.
3. Be sure to tighten all connectors before use.
4. If you have any questions, please feel free to contact us.
US Free Hotline(English):
+1 833-381-5659(MON-FRI 9:30 AM-5:30 PM PST)
EU Free Hotline(English Deutsch):
+44 800-808-5337(MON-FRI 9:00 AM-5:00 PM CET )
Email: seice@rainpointus.com
WhatsApp: +1 626-780-5952
GET STARTED
FOUR MEASUREMENT MODES
Press the button briey: the display switches to the next display mode.
1 FLOW MODE：Display the real-time water ow in GAL/Min or L/Min.
2 CONSUMPTION MODE：Measure the single water consumption.
The display will reset after 30sec without water ow or pressing the
button.
3 AVG MODE：Display the daily average water consumption for the
last 7 days.
4 TOTAL MODE：Measure the total water consumption up to the
reset
1. FLOW MODE 2. CONSUMPTION MODE 3. AVG MODE 4. TOTAL MODE
button button button button
2sec
Gal Liter Reset Consumption Reset Average Reset Total
2sec 2sec 2sec
SPECIAL FUNCTIONS
Energy saving Standby:
Displayer auto shut-o (longer than 1 min without ow or without
the pressing of a button)
Switch GAL & L Unit:
Hold the button pressed for 2 sec in FLOW MODE to switch the format
between gallon (GAL) and liter (L).
Reset to Zero:
Hold the button pressed in CONSUMPTION/AVG/TOTAL MODE for
2 sec，The display data will be reset to 0.
Low Batte Indicator:
Replace the batte when the low batte indicator appears on display.
TROUBLESHOOTING
Problem Check If
Flow Mode doesn't show
the real-time water ow
during watering
Inaccurate Measurement
The display installed tightly into the
ow meter body
The display installed correctly
The display installed tightly into the
ow meter body
The water ow direction goes correctly
There is no leakage
The inner pipeline of water meter is full
of water when using
Leakage The accessories are in the correct
position screwed with the correct thread
IF your Rainpoint product does not operate properly after ting the
troubleshooting steps, please contact us by phone or email:
US: +1 833-381-5659 (EN) EU: +44 800-808-5337 (EN DE)
seice@rainpointus.com
WARRANTY
CUSTOMER SERVICE
Rainpoint provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship.
1) Warranty seice can only be peormed by our authorized seice
center. The original dated bill of sale must be presented upon
request as proof of purchase to us, or our authorized seice center.
2) To receive warranty seice, the purchaser must contact with
Rainpoint nominated seice center for the problem determination
and seice procedure.
Thank you for your choice of Rainpoint products!
If you nd it dicult to set up and want to watch setting tutorial video,
please subscribe our channel: Rainpoint on YouTube.
If the user manual don’t have what you’re looking for, and you need
some help, please prepare the LOT.NO of your device and contact us
before and contact us before returning the Rainpoint to the store.
1-833-3815659(US Oce) or suppo@rainpointonline.com
LOT NO.:xxxxxxx(On the back of the product)
