ROSE DISPLAYS GOTCHA WITH WINDOW MOUNTS Manuale utente

The Gotcha® is a registered trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #02INSGotchaWindowMounts

Incep 9/16/02

Parts

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Instructions for Hanging

Figure 1

Gotcha

Instruction Sheet

Window Mounts

20-0038

Step 1

Place poster on a flat surface. Snap the Gotcha

(top and bottom) open so hinge is turned up as

far as possible. Insert graphic completely into

holder until edge of graphic meets top of holder.

To close, snap the Gotcha shut. Fig. 1

Note: It is easier to open and close the Gotcha

by starting at one end and working your way

down the holder. With large or curling graphics,

it may be easier to insert graphic at one end and

slide into holder from one end to another.

Step 2

Attach the Window Mounts to the Gotcha. You

should hear a “Snap” when the clip is properly

seated. Fig. 2

Note: For best results, place the suction cup clips

1/3 of the way in from each end on the top

holder.

Step 3

Prepare the window and suction cups by making

sure they are clean and free of dust and dirt.

Press the suction cups firmly to the window.

Gotcha

12G100

Figure 2

Important Note:

For best performance when first applied

and occasionally thereafter, press the

middle of the cup (on the cap) to “burp”

Parts

The Gotcha® is a registered trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #02INSGotchaWindowMounts

Incep 9/16/02

Instructions for Hanging

Figure 1

Gotcha

Instruction Sheet

Window Mounts

20-0038

Gotcha

12G100

Figure 2

Important Note:

For best performance when first applied

and occasionally thereafter, press the

middle of the cup (on the cap) to “burp”

Step 1

Place poster on a flat surface. Snap the Gotcha

(top and bottom) open so hinge is turned up as

far as possible. Insert graphic completely into

holder until edge of graphic meets top of holder.

To close, snap the Gotcha shut. Fig. 1

Note: It is easier to open and close the Gotcha

by starting at one end and working your way

down the holder. With large or curling graphics,

it may be easier to insert graphic at one end and

slide into holder from one end to another.

Step 2

Attach the Window Mounts to the Gotcha. You

should hear a “Snap” when the clip is properly

seated. Fig. 2

Note: For best results, place the Window Mounts

1/3 of the way in from each end on the top

holder.

Step 3

Prepare the window and suction cups by making

sure they are clean and free of dust and dirt.

Press the suction cups firmly to the window.
