ROSE DISPLAYS QUICKGRIP WITH MULTICLIPS Manuale utente

35 Congress Street, Salem, MA 01970

Tel# 1- 800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Instructions for Hanging

Instruction Sheet

Step 1

For use with poster paper or thinner

substrates. Score and fold or staple poster

edge and slide into the QuickGrip Holder.

When using staples, place staples 1/4” from

top and bottom edges of poster. Fig. 1

For use with thicker graphics up to 2mm.

Starting at one corner push the QuickGrip

Holder onto the graphic. Work your way

down the holder tapping it firmly down to

seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig. 3

Align the bottom rail of the MultiClip with

the top channel of the plastic holder. Slide

MultiClip into rail. Fig. 4 Repeat step 3

for second MultiClip.

Step 4

Push end caps into place. Fig. 5

Step 5

Suspend poster. Fig. 6

Important note:

Please save and reuse the QuickGrip Holder,

End Caps and MultiClips for future projects.

End Caps

06-5525

MultiClips

1UP-0101

QuickGrip™

Incept-8.5.02

QuickGrip is a trademark of Rose Displays, Ltd. Neither the manufacturer

nor any sales agent may be held liable for injury, loss or damage resulting

from the use of these products. Part #02INSQuickGripMC

QuickGrip

12-0500

Figure 6Figure 5

Figure 3 Figure 4

Figure 2

Figure 1

35 Congress Street, Salem, MA 01970

Tel# 1- 800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Parts

Instructions for Hanging

Instruction Sheet

Step 1

For use with poster paper or thinner

substrates. Score and fold or staple poster

edge and slide into the QuickGrip Holder.

When using staples, place staples 1/4” from

top and bottom edges of poster. Fig. 1

For use with thicker graphics up to 2mm.

Starting at one corner push the QuickGrip

Holder onto the graphic. Work your way

down the holder tapping it firmly down to

seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig. 3

Align the bottom rail of the MultiClip with

the top channel of the plastic holder. Slide

MultiClip into rail. Fig. 4

Step 4

Push end caps into place. Fig. 5

Step 5

Suspend poster. Fig. 6

Important note:

Please save and reuse the QuickGrip Holder,

End Caps and MultiClips for future projects.

End Caps

06-5525

MultiClip

1UP-0101

QuickGrip™

Incept-8.5.02

QuickGrip is a trademark of Rose Displays, Ltd. Neither the manufacturer

nor any sales agent may be held liable for injury, loss or damage resulting

from the use of these products. Part #02INSQuickGripMC

QuickGrip

12-0500

Figure 6Figure 5

Figure 3 Figure 4

Figure 2

Figure 1

Parts

Instructions for Hanging

Instruction Sheet

Step 1

For use with poster paper or thinner

substrates. Score and fold or staple poster

edge and slide into the QuickGrip Holder.

When using staples, place staples 1/4” from

top and bottom edges of poster. Fig. 1

For use with thicker graphics up to 2mm.

Starting at one corner push the QuickGrip

Holder onto the graphic. Work your way

down the holder tapping it firmly down to

seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig. 3

Align the bottom rail of the MultiClip with

the top channel of the plastic holder. Slide

MultiClip into rail. Fig. 4 Repeat step 3

for second MultiClip.

Step 4

Push end caps into place. Fig. 5

Step 5

Suspend poster. Fig. 6

Important note:

Please save and reuse the QuickGrip Holder,

End Caps and MultiClips for future projects.

End Caps

06-5525

MultiClips

1UP-0101

QuickGrip™

Incept-8.5.02

QuickGrip is a trademark of Rose Displays, Ltd. Neither the manufacturer

nor any sales agent may be held liable for injury, loss or damage resulting

from the use of these products. Part #02INSQuickGripMC

QuickGrip

12-0500

Figure 6Figure 5

Figure 3 Figure 4

Figure 2

Figure 1

Parts

Instructions for Hanging

Instruction Sheet

Step 1

For use with poster paper or thinner

substrates. Score and fold or staple poster

edge and slide into the QuickGrip Holder.

When using staples, place staples 1/4” from

top and bottom edges of poster. Fig. 1

For use with thicker graphics up to 2mm.

Starting at one corner push the QuickGrip

Holder onto the graphic. Work your way

down the holder tapping it firmly down to

seat the graphic fully. Fig. 2

Step 3

Squeeze sides of MultiClip together. Fig. 3

Align the bottom rail of the MultiClip with

the top channel of the plastic holder. Slide

MultiClip into rail. Fig. 4

Step 4

Push end caps into place. Fig. 5

Step 5

Suspend poster. Fig. 6

Important note:

Please save and reuse the QuickGrip Holder,

End Caps and MultiClips for future projects.

End Caps

06-5525

MultiClip

1UP-0101

QuickGrip™

Incept-8.5.02

QuickGrip is a trademark of Rose Displays, Ltd. Neither the manufacturer

nor any sales agent may be held liable for injury, loss or damage resulting

from the use of these products. Part #02INSQuickGripMC

QuickGrip

12-0500

Figure 6Figure 5

Figure 3 Figure 4

Figure 2

Figure 1
