SAFARI Montage WAN-1212X Manuale utente
Visual Learning Served On Demand™
WAN-1212X / RM–126X Rack-Mount Server
Installation Guide
2
Welcome to SAFARI Montage®!
Thank you for choosing the SAFARI Montage Video-On-Demand and Digital Media Management system.
In just a few steps, you’ll have access to fully segmented programs from the finest educational publishers –
from anywhere on your network. This setup guide covers the following SAFARI Montage server models:
WAN-1212X /RM-126X
3
Step 1
Step 2
Power Cord Keys (2)
(Styles may vary)
Ethernet Cable
Mounting Kit (Mounting Brackets Shown)
Positioning the SAFARI Montage Server
Install the server in a rack mount enclosure, using the supplied mounting brackets
or rails and screws. There should be adequate airflow around the server, with
temperatures not exceeding 95ºF.
Unpacking the Hardware
Carefully remove the SAFARI Montage server and the following items from the box,
and place them on a flat surface. If you are missing any of the items below, please
call 1.800.843.4549.
4
Step 3
Rear View of the WAN-1212X
Rear View of the RM-126X
Connecting Your SAFARI Montage Server
a. Using the image below as a guide, first connect the server to the network by
plugging an Ethernet cable into any active Ethernet port on your network.
b. Connect a monitor and keyboard to the server.
c. Connect the power cord from the back of the server into a grounded outlet. We
highly recommend connecting it to an uninterrupted power supply (UPS).
Note: Please see your hardware warranty for terms related to your server’s
environmental conditions and electrical power.
Keyboard
Monitor
Network
Power Power
Monitor
Network
Keyboard
Power
5
Step 4
Step 5 Networking Your SAFARI Montage Server
Access the SAFARI Montage console via the monitor and keyboard that you
connected in Step 3.
1. Choose Option 1, “Networks Settings...”
2. Choose Option 2, Network Cards (IP Address)...
3. Choose the option number associated to the active NIC card.
Once the unit’s boot sequence has completed, the SAFARI Montage console
menu will appear.
Powering Up Your SAFARI Montage Server
Now that the cables have been connected, you can power up the server.
Press the power button located on the front of the rack-mount server.
Power
6
3. If you chose option 2, enter the appropriate network settings for this device. If you
are assigning SAFARI Montage a static IP, that IP must not be in use by any other
device on your network. You must also ensure that SAFARI Montage has valid DNS
addresses, or the server will not be able to activate.
Assigning an IP address:
1. To assign SAFARI Montage a static IP address, choose option 1, “IP Address (Static)”
and skip to (3).
2. To have SAFARI Montage acquire an IP address automatically, choose option 2, “IP
Address (DHCP).” SAFARI Montage will acquire the required network settings from
your DHCP host. Skip to step 6 on the next page.
7
Username: admin Password: admin
Step 6
Log in as Administrator by using the default administrative account, and click
on ”Log in”:
We recommend that you change your administrative account password after the
initial sign on.
Congratulations!
You have completed the basic installation. Your digital content has been pre-
activated and is ready to access.
Now that you are logged in, a great place to get started
is with the Interactive Video Tutorial. The User’s Guide and
the Administrator’s Guide are accessible through the SAFARI
Montage “Help” section, and in the Support section at www.SAFARIMontage.com.
Accessing the SAFARI Montage User Interface
Launch a web browser (e.g., Internet Explorer) from any workstation on
your network.
Enter the URL for your SAFARI Montage server into the address bar, and hit ”enter”
(or ”return” if you are using a Mac). Obtain this URL from your
Network Administrator if necessary.
© 2015 Library Video Company. All Rights Reserved.
800.843.4549 • SAFARIMontage.com
Five Tower Bridge, 300 Barr Harbor Drive, Suite 700
West Conshohocken, PA 19428
Troubleshooting
If you have any difficulties with installation or need further information, please visit
www.SAFARIMontage.com/support or call a support representative at 800.782.7230.
When calling, please have your server’s serial number available. Your serial
number can be found in the Help > About section of the SAFARI Montage
application and on the back of your server.
Serial Number:
Hostname/URL:
Date Installed:
Additional Content
If you are interested in purchasing additional SAFARI Montage
products or digital content packages, please visit
www.SAFARIMontage.com or contact your sales representative.
NOTICE:
The information in this installation guide is subject to change without notice.
Library Video Company reserves the right to modify the design of its products
and change the information in this installation guide.
