Santec PLS-100 Manuale utente
Polarized Light Source
Operation Manual
PLS-100
PLS-100 Operation Manual
Trademarks
Notes to Users
1) Copyright 2016, Santec Corporation. All rights reserved. No part of this Operation
Manual may be reproduced or transmitted in any form or by any means, electronic or
mechanical, for any purpose, without the prior written permission of Santec.
2) Information in this Operation Manual is subject to change without notice.
3) Information of this Operation Manual is prepared with careful examination, however,
in the event of any mistake, please contact us.
Notes in Bringing This Product Out of Japan
1) When this product is brought out of Japan, some laws or regulations of a destination
country may prohibit this product from being used there. In such countries, the use
of this product may lead to punishment. Please note, that in such cases Santec
Corporation shall not be held responsible in anyway.
2) When this product is exported (or brought out of Japan), and this product is
applicable to a strategic material specified in the “Foreign Exchange and Foreign
Trade Control Law”, then under law of the Japanese Government, an export permit is
required.
is a trademark of Santec Corporation.
PLS-100 is a trademark of Santec Corporation.
Polarized Light Source PLS-100
Introduction
Thank you very much for purchasing our product, the Santec Polarized Light Source
PLS Series. This Operation Manual contains the necessary information for proper
operation of the PLS-100, and it is intended for those with sufcient knowledge about
the dangers of lasers and their safe control. Before operating the PLS-100, you should
first read thoroughly through this Operation Manual and become familiar with its
contents. After reading this Operation Manual, keep it close by for an easy reference
anytime.
The packing materials and box of this product are needed for long-term storage or
transportation; keep them in a safe place after unpacking the product.
PLS-100 Operation Manual
Before using this product, please carefully read this Operation Manual.
How to Read the Manual
Before operating the PLS-100, please read this instruction manual carefully.
This Operation Manual consists of 11 Chapters:
Chapters 1 to 4 illustrate the safety notes, the product composition, the panel
description and the installation.
Chapters 5 to 6 describe how to operate the product. Santec recommends that
Chapter 1 to 4 be read carefully before proceeding to this chapter.
Chapter 7 describes the operating principles.
Chapter 8 explains the specications.
Chapter 9 describes the maintenance and storage methods of the product.
Chapter 10 explains the packing instructions and shipping.
Chapter 11 describes the troubleshooting.
Polarized Light Source PLS-100
Explanation of Terms
The meanings of the following terms used in this Operation Manual are defined as
below:
(1) Meaning
This indicates pressing DANGER, and if it
is not avoided, personnel death or serious
injury may result; therefore, it is the most
emphasized special information.
This indicates potential danger, and if it is
not avoided, personnel death or serious
injury may result; therefore, it is special
information.
This indicates potential danger, and if it is
not avoided, mild or slight injury may result;
therefore, it is special information. It also
indicates potential danger leading to only
physical damage.
This section only indicates supplementary
explanations of the text and thus other than
DANGER, WARNING, and CAUTION.
(2) Importance of Information
From the above meanings, the priority of the terms here are as shown below:
DANGER > WARNING > CAUTION > NOTE
DANGER
WARNING
CAUTION
NOTE
Markings on the instrument
This mark is used on the equipment as warning of danger.
PLS-100 Operation Manual
1. Safety Information 1-1
1-1 Intended use 1-1
1-2 Safety Markings 1-1
1-3 Laser Class 1-2
2. Product Composition 2-1
3. Panel Description 3-1
3-1 Front Panel 3-1
3-2 Rear Panel 3-1
3-3 Bottom Panel 3-2
4. Installation 4-1
4-1 Operating Environments 4-1
4-2 Power Supply 4-1
5. Basic Operation 5-1
5-1 Turning on the Unit 5-1
5-2 Optical Fiber Connection 5-1
5-3 Optical output 5-2
5-4 Turning off the Unit 5-2
6. Detailed Operation 6-1
6-1 Polarization axis adjustment 6-1
7. Operating Principles
8. Specications 8-1
Contents
Introduction
How to Read the Manual
Instrument Markings
Explanation of Terms
Polarized Light Source PLS-100
9. Maintenance 9-1
9-1 Daily Maintenance
9-1
9-2 Cleaning the Optical Connector
9-1
9-3 Replacing Fuses
9-1
9-4 Inspection
9-1
9-5 Long-term Storage
9-2
10. Re-packing and Shipping 10-1
10-1 Re-packing 10-1
10-2 Shipping 10-1
11. Troubleshooting 11-1
PLS-100 Operation Manual
Polarized Light Source PLS-100
1-1
Safety Notes
1
This product is designed to measure the optical characteristics. Do not use this
product for anything other than as an optical measuring instrument. If this product is
used in a manner not specied in this manual, the protection provided by this product
may be impaired.
1-1 Intended use
1-2 Safety Markings
This product is marked with this warning symbol when it is necessary for
the user to refer to the instructions in the manual.
This warning symbol is marked on products which have a laser output.
1-2
PLS-100 Operation Manual
Laser Type : Superluminescent diode
Laser Class : 1M IEC60825-1(2014)
Output Power : < 50mW
Laser Diameter : 10μm
Numerical aperture : 0.1
Wavelength : 1200-1700nm
This product radiates class 1M invisible laser. Do not look at the tip of optical output
connector using optical instruments like magniers or microscopes. The laser radiation
can seriously damage your eyesight. Please pay attention to handling of laser.
Laser Safety Labels
This product is classied class 1M laser product according to IEC 60825-1 (2014).
1-3 Laser Class
