Surge Protector Series
User Manual
Model : SP006PHO
High Performance Outdoor 1G PoE Surge Protector
1
User Manual
SP006PHO
Introduction
SP006PHO is an in-line surge protector designed to protect a valuable outdoor PoE (Power over Ethernet)
device from high voltage surges, with network bandwidth up to 1000Mbps.
Features
Supports bandwidth up to 1000 Mbps.
Supports IEEE 802.3 af, 802.3 at, 802.3bt PoE standard.
Supports Mid-Span and End Span PoE.
IP66 Waterproof rating.
Response time less than 1 ns.
Installation View
Application:
Outdoor PoE Cameras
Outdoor APs
Outdoor Network device
Computer Control Rooms
Server Farms
Manufacturing Facilities
Transmitter and Receiver Stations
Note:
To effectively protect the PoE
device, ensure to connect the
grounding wire to the ground.
2
User Manual
SP006PHO
Installation Guide:
IP66 Waterproof Accessories
#1
x 2
#2
x 2
#3
x 2
#4
x 2
#5
x 2
#6
x 1
1. Assemble the waterproof connector.
2. Put a network cable and grounding wire through the connector.
3
User Manual
SP006PHO
3. Put the cable set into the waterproof case and use the screw nut (#5) to fix it from inside.
4. Use TIA/ EIA-568-B standard to make a RJ45 connector.
5. Connect the network cables to RJ45 connectors.
6. Fix the grounding wire.
2
3
Note：
The position of grounding cable must
be same as the left diagram.
4
User Manual
SP006PHO
7. Put on the cover and screws to firmly fix the waterproof case.
Note:
Make sure the notch is matched.
5
User Manual
SP006PHO
Specification
ITEM NO.
SP006PHO
Support
Compliance
IEEE 802.3 af, 802.3 at, 802.3bt
IEC 61000-4-5, IEC 61000-4-2, EN61000-4-5
Network Bandwidth
10/100/1000 Mbps
Response Time
Less than 0.7nS
ESD Protection
30KV (Air)/ 30KV( Contact)
Lightning Protection
10KA (8/20 us), 20KV (8/20 us)
Waterproof Rating
IP66
Ports & Interfaces
Equipment End
1 x RJ45
Cable End
1 x RJ45
Ambient Temperature
Operation
-40 to 70℃
Storage
-40 to 90℃
Humidity
Up to 95%
Physical Characteristics
Dimensions
80 x 166 x 70mm
Weight
230g
