SC&T SP009P Manuale utente
Smart Cabling & Transmission V1.0
Surge Protector
User Manual
Item No.：SP009P
HD-TVI/AHD/HDCVI/CVBS POC (Power over Coax) Surge
Protector
1
User Manual
SP009P
Introduction
SP009P is a surge protector designed to protect HD-TVI, AHD, HDCVI, CVBS, and PoC (Power over Coaxial)
device from high voltage spikes without compromising the performance of network bandwidth and
power transfer.
Features
Supports HD-TVI, AHD, HDCVI, CVBS, and PoC devices.
Resolution up to 8MP (4K).
Supports 20kA (8/20 us) lighting protection, up to 25kA (8/20us) per strike.
Supports PoC (Power over Coaxial).
Network bandwidth up to 100Mbps at 450M.
Compliant with IEC 61000-4-5.
Diagram
Connect a HD Camera (Must connect to the earth ground)
Connect a PoC Device (Must connect to the earth ground)
2
User Manual
SP009P
Panel View
No
Interface
Function
1
Equipment End
To connect a video source.
2
Cable End
To connect a coaxial cable.
3
Ground Wire
To connect the ground.
Caution
1. We recommend using a RG-coaxial cable, such as RG59/ RG6U.
2. To effectively protect your device, please ensure to connect the ground wire to the earth ground
(Impedance < 100Ω).
3. Do NOT connect the ground wire to an electrical wire.
4. We recommend using SP009P with IP09CP (PoE over coaxial extender).
※IP09CP has built-in ESD protection, you can use it with SP009P to improve the protection.
※SP009P might shorten the transmission distance by up to 50M.
3
User Manual
SP009P
Specification
Item No.
SP009P
Support
Compliant
IEC 61000-4-5
Bandwidth
0 to 1000Mhz
Response Time
<1ns
Insertion Loss
0.8db@42 MHz
Max. Discharge Current
25kA (8/20 us)
Ports & Interfaces
Input (Equipment End)
1 x BNC (Male)
Output (Cable End)
1 x BNC (Female)
Ground
1 x U-type Terminal
Ambient temperature
Operation
-40 to 90℃
Storage
-40 to 90℃
Humidity
Up to 95%
Operating Altitude
2000M
Physical Characteristics
Mounting
Rack-Mount / Wall-Mount
Dimension
112.65 x 25.4 x 25.4mm
Weight
85g
