Seltron T1 Manuale utente
Room thermostat T1
Raumthermostat T1
Thermostat d'ambiance T1
Thermostato ambiente
T1
Chronotermostato de ambiente T1
Mode d’emploi
Anleitungen
D
GB
Instructions
I
struzioni
I
F
E
Manual
D Bedienungsanleitungen...................................23
Betriebsanleitungen ........................................32
Montageanleitungen .......................................36
Technische Daten, Stellungsnahme................39
F Mode d'emploi................................................61
Réglage...........................................................70
Montage..........................................................74
Les données techniques, les declarations .......77
Istruzioni per l’uso..........................................42
Istruzioni per l’impostazione ..........................51
Istruzioni per il collegamento.........................55
Dati tecnici, dichiarazioni...............................58
I
User manual....................................................4
Setting manual................................................13
Installation manual..........................................17
Technical data, statements..............................20
GB
E Manual de usuario...........................................80
Manual de ajustes ...........................................90
Manual de instalación.....................................94
Datos técnicos, declaraciónes ........................97
DF I GBE
USER MANUAL
T1 is a powerful, modern designed room thermostat with weekly
program timer. On T1 is possible to set four temperature levels,
which ensures maximal comfort and energy saving. T1 is simple to
use and very practical with help of the Party and Eco keys. Every
key press or command activation is signalised with a beep sound.
Room thermostat T1 also enables remote activation and selection
between heating / cooling mode.
LEGEND
Hold key while pressing other keys.
Hold key until you hear a beep sound.
Press and release key.
Press key to increase or decrease value.
4
Appearance and description of T1
GB
Operating mode
USER MANUAL 5
Controlled object
- boiler
- actuator
- pump
Day and time
Knob for day
temperature
setting
Picture 1
PARTY -
day
tempera-
ture mode
Stand-by Night
temperature
setting
Operation
according to
the
program
timer
Relay output
ON - active
OFF - inactive
Program timer
- day temperature
- night temperature
ECO - saving
temperature mode
- stand-by
- heating
- cooling
PARTY
ECO
Temperature
display
GB
USER MANUAL
Operating mode selection
Operation
Press key (Picture 2). On the
display appears symbol , when
heating or symbol when cooling.
Thermostat operates according to
the program timer.
Stand-by
Press key (Picture 3). On the
display appears symbol .
Frost protection remains active.
Picture 2
6
Day temperature
Turn knob to set the desired
day temperature between 10 °C
and 30 °C (Picture 4).
Setting the day and night temperature
Picture 4
Picture 3
Night temperature
Hold key ( ) for approx. 5 seconds (Picture 5). Release key
after you hear a beep. Now press key ( ) or ( ) to set the
desired night temperature (Picture 6). To save and quit set-up,
press key ( ) once again .
GB
USER MANUAL 7
Picture 6
Picture 5
PARTY and ECO operating mode
PARTY - day temperature operation
Press key . Use key ( ) or ( ) to set duration of the
PARTY mode between 1 and 24 hours. For permanent PARTY
mode, select on.
To stop PARTY mode at anytime, press key .
ECO - night temperature operation
Press key . Use key ( ) or ( ) to set duration of the
ECO mode between 1 and 24 hours. For permanent ECO mode,
select on.
To stop ECO mode at anytime, press key .
Hold key for approximately 15 seconds. Release the key after
you hear a beep sound. Use key ( ) or ( ) to set duration
of the HOLIDAY mode between 1 and 99 days.
To stop HOLIDAY mode at anytime, again hold the key for 15
seconds.
Holiday mode
The ECO temperature reduction is setted in program group P1.2 (page 15).
i
GB
Day
Hold both keys and , then
press key ( ) or ( ) to set
the day (Picture 9). The days are
marked from 1 to 7. Monday is
marked as 1and Sunday as 7.
i If the battery exchange isn't completed within 20 s, the time is set to
Monday, 20:00.
Picture 9
Setting the accurate time
Hours
Hold key and press key ( )
or ( ) to set the hours (Picture
7).
Minutes
Hold key and press key
( ) or ( ) to set the
minutes (Picture 8).
Picture 8
Picture 7
USER MANUAL
8
The HOLIDAY mode temperature is setted in program group P1.4 (page 15).
Factory default HOLIDAY temperature is 12 °C.
i
GB
USER MANUAL 9
Pre-setted time programs
Program selection
Hold key and by pressing key select the suitable time
program (Picture 10). Select between Pr1, Pr2, Pr3, Pr4 and- - -.
The selected time program always overwrites the previous one. To
keep the current time program active, select - - -.
Table of pre-setted time programs
Picture 10
Day TimeDay Time
Day TimeDay Time
GB
Time
command
USER MANUAL
Modifying the time program
10
The selected time program can be modified. In that way you can
make your own time program.
Hold key and press key (Picture 11). Release both keys
after you hear a beep. The display shows CH1 (Picture 12).
Picture 11 Picture 12
Press key ( ) or ( ) to select the program space that you
want to modify. The display simultaneously shows the time
command and the successive number of the program space
(Picture 13).
Picture 13
Successive number of the
program space
Program timer
- night temperature
- day temperature
GB
