Set 860
Set 860
Instruction manual
Digital TV Listening System
2| Set 860
Contents
Contents
Important safety instructions ...................................................................... 3
Package contents ........................................................................................... 6
Product overview ........................................................................................... 7
Putting the Set 860 into operation ........................................................... 10
Setting up the transmitter ......................................................................... 10
Connecting the transmitter to an audio source .................................... 11
Connecting the transmitter to the power supply system ................... 15
Charging the stethoset receiver’s rechargeable battery ..................... 16
Displaying the remaining operating time of the rechargeable
battery ........................................................................................................... 17
Using the charging reminder function .................................................... 17
Selecting and replacing the ear pads ....................................................... 18
Using the Set 860 ........................................................................................ 19
Switching the wireless headphone system on ...................................... 19
Switching the wireless headphone system off ...................................... 20
Wearing the stethoset receiver ................................................................ 21
Adjusting the volume ................................................................................. 22
Adjusting the balance ................................................................................. 23
Selecting a hearing profile for sound enhancement ............................. 24
Activating/deactivating the speech intelligibility function ................ 26
Cleaning and maintaining the Set 860 ..................................................... 27
Replacing the stethoset receiver’s rechargeable battery .................... 28
Using additional functions ......................................................................... 29
Pairing one or several stethoset receivers with the transmitter ....... 29
Switching between stereo and mono operation ................................... 30
Advanced settings ....................................................................................... 31
Restoring the factory default settings .................................................... 34
Charging the rechargeable battery using the MCA 800 charging
adapter .......................................................................................................... 35
If a problem occurs ... .................................................................................. 36
Leaving the range of the transmitter ...................................................... 38
Specifications ............................................................................................... 39
Manufacturer Declarations ......................................................................... 41
Important safety instructions
Set 860 | 3
Important safety instructions
왘Read this instruction manual carefully and completely before
using the product.
왘Always include this instruction manual when passing the prod-
uct on to third parties.
왘Do not use an obviously defective product.
왘Only use the product in environments where wireless 2.4 GHz
transmission is permitted.
Preventing damage to health and accidents
왘These headphones allow you to set higher volumes than conven-
tional headphones. Protect your hearing from high volume lev-
els.
Permanent hearing damage may occur when headphones are
used at high volume levels for long periods of time. Sennheiser
headphones sound exceptionally good and provide clear speech
intelligibility at low and medium volume levels.
왘To prevent hearing damage, set the volume to a low level before
passing the product on to third parties.
왘Do not use the product in an environment that requires your spe-
cial attention (e.g. in traffic or when performing skilled jobs).
왘Always keep the headphones/MCA 800 charging adapter at
least 3.94" (10 cm) from cardiac pacemakers or implanted
defibrillators. The headphones/MCA 800 charging adapter con-
tain/s magnets that generate a magnetic field which could cause
interference with cardiac pacemakers and implanted defibrilla-
tors.
왘Do not use the product near water. To reduce the risk of fire or
electric shock, do not expose the product to rain or moisture.
왘Keep the product, accessories and packaging parts out of reach
of children and pets to prevent accidents and choking hazards.
왘Only use the power supply units supplied by Sennheiser.
Preventing damage to the product and malfunctions
왘Always keep the product dry and do not expose it to extreme
temperatures to avoid corrosion or deformation. The normal
operating temperature is from 5 to 40 °C/41 to 104 °F.
왘Use the product with care and store it in a clean, dust-free envi-
ronment.
왘Switch off the product after use to conserve battery power.
왘Unplug the power supply unit from the wall socket
– to completely disconnect the product from the power source,
– during lightning storms or
– when not using the product for long periods of time.
Important safety instructions
4 | Set 860
왘Always ensure that the power supply unit is
– in a safe operating condition and easily accessible,
– properly plugged into the wall socket,
– only operated within the permissible temperature range,
– not exposed to direct sunlight for longer periods of time in
order to prevent heat accumulation.
왘Varnish or furniture polish may degrade the feet of the transmit-
ter, which could stain your furniture. You should therefore place
the transmitter on a non-slip pad to avoid potential staining of
furniture.
왘Do not operate the product near heat sources.
왘Clean the product only with a soft, dry cloth.
왘Use only attachments/accessories/spare parts supplied or rec-
ommended by Sennheiser.
Safety instructions for lithium polymer
rechargeable batteries
WARNING
If abused or misused, the standard/rechargeable batteries may
leak. In extreme cases, they may even present a risk of
•explosion,
• fire development,
•heatgeneration,
• smoke or gas development.
Switch rechargeable battery-powered products off after
use.
Do not charge a product with a built-in rechargeable
battery if the product is obviously defective.
Only use rechargeable batteries and chargers
recommended by Sennheiser.
Only charge rechargeable batteries at ambient
temperatures between 5 to 40 °C/41 to 104 °F.
When not using rechargeable batteries for extended
periods of time, charge them regularly (about every three
months).
Do not heat above 70 °C/158 °F, e.g. do not expose to
sunlight or throw into a fire.
Dispose of batteries/rechargeable batteries at special
collection points or return them to your specialist dealer.
Important safety instructions
Set 860 | 5
Intended use/Liability
This wireless TV headphone system is suitable for use with TV sets,
hi-fi systems, and home cinema systems and can be connected to
analog and digital audio sources.
This product is intended for private domestic use only. It is not suit-
able for commercial use. This product is also not intended to be used
with portable audio devices.
It is considered improper use when the product is used for any appli-
cation not named in the corresponding product documentation.
Sennheiser does not accept liability for damage arising from abuse
or misuse of this product and its attachments/accessories.
Before putting into operation, please observe the respective coun-
try-specific regulations.
Package contents
6 | Set 860
Package contents
A list of accessories can be found on the Set 860 product page
at www.sennheiser.com. For information on suppliers, contact
your Sennheiser partner. To find a Sennheiser partner in your
country, search at www.sennheiser.com.
RR 800 stethoset receiver with
built-in rechargeable battery
TR 860 transmitter with charging station
NT 5-10AW power supply unit with
multi-country adapters (EU, UK, US, AU)
1 pair of ear pads for small ears
1 pair of ear pads for pressure-sensitive ears
Optical digital cable, 1.5 m
Stereo audio cable with 3.5 mm jack plugs, 1.5 m
Safety guide
Quick guide
Instruction manual in English, German, French, and
Spanish
The instruction manual in other languages can be
downloaded as a PDF file at
www.sennheiser.com/download.
Safety Guide
Quick Guide
Instruction
Manual
Product overview
Set 860 | 7
Product overview
Overview of the RR 800 stethoset receiver
2
1
3
6
7
5
4
On
Off
1Ear pads, replaceable
2Ear bows with
on/off function
3Volume buttons +and –
4
Speech intelligibility
button
5Rmarking for the right ear
and Lmarking for the left ear
6Built-in rechargeable battery
7Charging contacts
Product overview
8 | Set 860
Overview of the TR 860 transmitter
5
6
7
0
9
4
8
1
2
3
2
1A
1
Battery
LED ,
indicating the charging process/
remaining operating time of the
receiver (see page 16 and 17)
2Balance buttons
for right ear Rand left ear L
3
Hearing profile
button ,
for selecting the hearing profiles
(see page 24)
4
Hearing profile
LED,
indicating the activated hearing
profile (see page 24)
5Charging compartment for
stethoset receiver
6Charging contacts for stethoset
receiver with holding magnets
7
Transmitter status
LED
(see page 9)
8Digital Optical In audio input
(marked pink) for connecting a
digital audio source (optical)
95V DC 1A socket (marked yellow) for
connecting the power supply unit
0Analog 3.5 mm In audio input
(marked blue) for connecting an
analog audio source (3.5 mm jack
socket)
Product overview
Set 860 | 9
Overview of the
Transmitter status
LED
Overview of the acoustic signals/beeps
Transmitter status
LED The transmitter...
–... is in standby mode.
lights up white
... and the stethoset receiver are
connected. The speech intelligibility
function is deactivated (see page 26).
lights up blue
... and the stethoset receiver are
connected. The speech intelligibility
function is activated (see page 26).
flashes blue and white
... has detected an incompatible digital
audio signal (see page 12).
The LEDs on the transmitter indicate the current operating
state. If you are not pressing any button on the stethoset
receiver or the transmitter, the LEDs automatically dim after
approx. 30 seconds to not disturb you.
Beeps... Meaning
during operation,
2 beeps
The rechargeable battery is almost
empty, recharge the rechargeable
battery (see page 16).
during operation, no
audio transmission,
5 beeps
The receiver is outside the transmission
range (see page 38).
when changing the
volume
The maximum or minimum volume is
reached (see page 22).
when changing the
balance setting
The maximum or minimum balance
setting is reached (see page 23).
Putting the Set 860 into operation
10 | Set 860
Putting the Set 860 into operation
Setting up the transmitter
왘Choose a suitable place near your sound source.
왘Separate the transmitter from other wireless devices in the room
by at least 50 cm/20" to avoid interference.
왘Do not place the transmitter close to metal objects such as shelf
bars, reinforced concrete walls, etc. as this can decrease the
transmitter’s range.
Altri manuali per Set 860
1
Questo manuale è adatto per i seguenti modelli
6
Indice
Altri manuali Sennheiser Apparecchio acustico
Sennheiser
Sennheiser DSP 360 - SHORT Manuale utente
Sennheiser
Sennheiser Set 810 Manuale utente
Sennheiser
Sennheiser SET 900 - 07-08 Manuale utente
Sennheiser
Sennheiser ADC1 Manuale utente
Sennheiser
Sennheiser SET100 Dimensioni
Sennheiser
Sennheiser EZT 3011 Manuale utente
Sennheiser
Sennheiser RI 100 Manuale utente
Sennheiser
Sennheiser Quickguide RS 4200 Manuale utente
Sennheiser
Sennheiser AUDIOLINK PLS-100 Manuale utente
Sennheiser
Sennheiser SI 1015-12500 DUAL Dimensioni
Sennheiser
Sennheiser SI 1015-8000 SINGLE Dimensioni
Sennheiser
Sennheiser Set 820s Manuale utente
Sennheiser
Sennheiser SI 1015-8000 DUAL Dimensioni
Sennheiser
Sennheiser EZT 3012 Manuale utente
Sennheiser
Sennheiser Audiology SET 810 Infra-red Manuale dell'operatore
Sennheiser
Sennheiser Audiology SET 810 Infra-red Manuale utente
Sennheiser
Sennheiser SI 30-3000 SINGLE Dimensioni
Sennheiser
Sennheiser SI 1015-4000 SINGLE Dimensioni
Sennheiser
Sennheiser Audiology Set 810 S Infra-red Manuale utente
Sennheiser
Sennheiser Audiology SET 810 Infra-red Manuale utente
