Shure Sound Isolating Manuale utente
Sound Isolating™ Earphones
Shure Sound Isolating™ Earphones, built
with balanced armature speakers, deliver
a detailed soundstage free from outside
noise. The powerful and stylish Shure SE
earphones come with a detachable cable,
adapters, a durable carrying case, and in-
terchangeable Sound Isolating sleeves for a
comfortable and personalized fit.
©2012 Shure Incorporated
27C21352 (Rev. 1) Printed in China
new drawing.
english
45
Over the ear in back
Wearing the Earphones
The following are some suggested ways of wearing the earphones.
Wear the cable over the ear and secure it behind the head to help keep the
earphones in place during physical activity.
Tighten the cable and take up slack by raising the cable cinch.
Detachable Cable
You may need to detach the cable from the earphones to attach optional components
or to replace the cable if it becomes damaged. To prevent accidental separation, the
connector has a snug fit. Take special care to prevent damage to the earphone and
connector.
• Do not use pliers or other tools.
• Grasp the connector and the earphone as close as possible to where they join.
• Pull straight apart—do not twist. Cable is a snap fit, not threaded.
Note: If you pull at an angle, the connector will not detach.
• Do not pull on the cable or put any pressure on the earphone nozzle.
• Listen for a click when connecting.
• When reattaching the cable, match the "L" and "R" markings. For clear cables and
earphones, match the color dots (Red=Right, Blue=Left).
Audible click when properly connected
english
67
Changing Sleeves
Twist and pull to remove the sleeve from the nozzle.
Slide on a new sleeve so that it completely covers
the barb and the nozzle.
Caution: If the barb or any of the nozzle is exposed, the sleeve is not properly installed.
Replace sleeves if they do not tightly grip the nozzle. To ensure proper fit and perfor-
mance, use only sleeves supplied by Shure (unless using custom molded sleeves).
Inserting the Earphones
Insert the earphones so they form
a tight seal. The fit of the earphone
can greatly affect sound quality.
Important: If there seems to
be a lack of low frequency
response (bass), this means
that the earphone sleeve
is not forming a tight seal.
Gently push the earphone
deeper into the ear canal or
try a different sleeve.
Warning: Do not push the earphone sleeve beyond the ear canal opening.
english
89
Choosing a Sleeve
Select an earphone sleeve that provides the best fit and sound isolation. It
should be easy to insert, fit comfortably, and easy to remove.
Soft Flex Sleeves: In small, medium, and
large sizes. Made from pliable rubber.
Soft Foam Sleeves: Compress the foam
sleeve between your fingers and insert
into the ear canal. Hold in place for about
ten seconds while the foam expands.
Triple-Flange Sleeves: If desired, use
scissors to trim the stem on the sleeve.
Removing the Earphones
Grasp the body of earphone and gently twist to remove.
Note: Do not pull on cable to remove earphone.
english
10 11
Maintenance and Cleaning
Careful maintenance ensures a tight seal between the sleeve and nozzle, im-
proving sound quality and product safety.
• Keep the earphones and sleeves as clean and dry as possible.
• To clean sleeves, remove them from earphones, gently rinse in warm
water and air dry. Foam sleeves require a longer drying time. Inspect for
damage and replace if necessary. Ear sleeves must be completely dry
before reusing.
• Wipe the earphones and sleeves with mild antiseptic to avoid infections.
Do not use alcohol-based disinfectants.
• Do not expose earphones to extreme temperatures.
• Replace sleeves if they do not fit properly.
• Do not attempt to modify this product. Doing so will void the warranty and
could result in personal injury and/or product failure.
Cleaning the Earphone Nozzle
If you notice a change in sound quality, remove the sleeve and check the nozzle of your ear-
phone. If nozzle is blocked, clear obstruction by using wire loop end of cleaning tool.
If no obstruction is found or if sound quality does not improve, replace the sleeve with a new
sleeve.
Cleaning
Tool
Wire Loop
Caution: When cleaning, do not force any object through the earphone nozzle! This
will damage the earphone sound filter.
Warning: The cleaning tool is only to be used to clean the earphones. Any other
use, such as using the tool to clean ears or foam sleeve, could result in injury.
The cable connectors to the earphones may collect debris or other deposits that can
affect audio quality. If this happens, disconnect the cables and clean them using a
dry cotton swab.
english
12 13
Included Accessories
• Fit Kit with assorted sleeves
• Nozzle cleaning tool
• Water resistant, crush proof road case
• Soft zippered carrying pouch
• 60-inch and 46-inch detachable cables
• Airline adapter
• ¼ inch adapter
• Inline attenuator
For optional accessories, visit www.shure.com.
WARNING: This product contains a chemical known to the State of California to cause
cancer and birth defects or other reproductive harm.
Technical Specifications
SE535LTD – Red
Transducer type Triple balanced-armature drivers
Sensitivity (at 1khz) 119 dB SPL/mW
Impedance (at 1kHz) 36 W
Frequency Range 18 Hz - 19.5 kHz
Input connector 3.5mm (1/8 in.) gold-plated stereo plug
Net weight 30 g (1 oz.)
Operational
temperature
-18° C to 57° C (0° F to 135° F)
Storage temperature -29° C to 74° C (-20° F to 165° F)
14
CERTIFICATION
Eligible to bear CE Marking. Conforms to EMC Directive 2004/108/EC. Meets applicable
tests and performance criteria in European Standard EN55103 (1996) parts 1 and 2, for
residential (E1) and light industrial (E2) environments. The Declaration of Conformity can
be obtained from the address below.
Shure Europe GmbH
Authorized European representative:
Shure Europe GmbH
Headquarters Europe, Middle East & Africa
Department: EMEA Approval
Jakob-Dieffenbacher-Str. 12,
75031 Eppingen, Germany
Phone: +49-7262-92490
Fax: +49-7262-9249114
Email: [email protected]
高遮音性イヤホン
バランスド・アーマチュア型ドライバーを搭
載したShure Sound Isolating™イヤホンは、
周囲のノイズの侵入のない音本来のディテー
ルを再現できます。 パワフルでスタイリッ
シュな外観のShure SEイヤホンには、取り
外し式ケーブル、アダプター、耐久性を備え
たキャリングポーチ、及び快適性とフィット
性の高い交換式のサウンド分離イヤパッドが
付属しています。
©2012 Shure Incorporated
27C21352 (Rev. 1) Printed in China
new drawing.
