ROMEO-X
COMPACT and PRO Open Reflex Sights
OPERATOR’S MANUAL
READ THE INSTRUCTIONS AND WARNINGS IN THIS MANUAL CAREFULLY BEFORE
USING THIS OPTIC; DO NOT DISCARD THIS MANUAL.
2
TABLE OF CONTENTS
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ROMEO-X Product Identification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Mounting the Sight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Sight Adjustments and Zeroing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
SIG SAUER Electro-Optics Infinite Guarantee ..............................18
SIG SAUER Electronic Component Limited 5-Year Warranty. . . . . . . . . . . . . . . . . . . 20
3
INTRODUCTION
Designed, developed, tested and assembled in the USA, the ROMEO-X open reex sights
are rugged pistol optics that are packed with features. The COMPACT model ts all Shield
RMS-c footprints and the PRO model ts all Delta Point PRO footprints.
The ROMEO-X features a high-eciency point source LED emitter and aspherical glass
lens, utilizing a high-performance red notch reector coating for excellent brightness and light
transmission with zero distortion. Either a circle/dot or a 6 MOA reticle with 15 brightness
settings ensures rapid target engagement with both eyes open, for maximum situational
awareness. D.A.R.C. (Dark Adaptive Reticles & Coatings) technology provides the ideal
reticle brightness and target clarity while using GEN3+ night vision devices. MOTAC (Motion
Activated Illumination) automatically shuts the optic o after 2 minutes of inactivity, then
automatically turns it back on when motion is detected. The common CR1632 battery is
accessed from the side of the optic, making battery changes easy, without the need to
remove the optic from the rearm.
The ROMEO-X is covered by the SIG SAUER Electro-Optics Innite Guarantee/Limited
Lifetime Warranty and the SIG SAUER Electronic Component Limited 5-Year Warranty.
WARNING:
CANCER AND REPRODUCTIVE HARM—www.P65warnings.ca.gov
4
CONTENTS
• ROMEO-X COMPACT or PRO 1x24mm Open Reflex Sight
• CR1632 Battery
• Mounting Screws
M3 & M4 Torx®Mounting Screws (COMPACT)
M4 Torx®Mounting Screws (PRO)
• T6 & T10 Torx Wrenches
• Operator’s Manual
Scan the QR code to visit sigsauer.com where you will nd additional information
about SIG SAUER products, SIG SAUER Academy and the SIG Experience Center,
Special Programs, and additional support.
5
KEY FEATURES
• 7075 Aluminum housing with integrated
rear sight notch (COMPACT Model
includes fiber optics).
• Extremely low deck height, allowing a
full sight picture and co-witness with
standard-height sights.
• High-efficiency point source LED emitter,
with 2 MOA dot/32 MOA circle (circle/dot),
or 6 MOA dot reticle.
• Independent brightness adjustment
buttons that are recessed within a
protective plate.
• 15 brightness settings (12 Daylight/3 NV).
• Side-mounted CR1632 battery
compartment with threaded cap for easy
battery changes without the need to
remove the optic from the firearm.
• Minimum continuous runtime of 20,000
hours, at medium brightness setting (dot
only).
• MOTAC (Motion Activated Illumination)
that powers up when it senses motion
and powers down when it does not.
• D.A.R.C. (Dark Adaptive Reticles &
Coatings) technology provides ideal
reticle brightness and target clarity while
using GEN3+ night vision devices.
• Dependable waterproof performance
(IPX-7 rated for complete water
submersion up to 1 meter).
• Designed, developed, tested and
assembled in the USA.
• SIG SAUER Electro-Optics Infinite
Guarantee and SIG SAUER Electronic
Component Limited 5-Year Warranty.
6
ROMEO-X PRODUCT IDENTIFICATION
(COMPACT Model Shown, PRO model is similar)
A – ▲ (Up) Brightness Adjustment (Press and Release),
and Power ON/OFF (Press and Hold)
B – ▼(Down) Brightness Adjustment (Press and Release),
and Reticle Change (Press and Hold)
C – Windage Adjustment Screw
D – Battery Cap
E – Mounting Screw Holes
F – Elevation Adjustment Screw
G – Rear Sight Notch
(COMPACT model includes
fiber optic rods)
H – Front Lens
I – Recoil Lug Witness Holes
AC
B
7
H
G
F
II
E
D
E
8
BEFORE WORKING ON YOUR ROMEO-X SIGHT, ALWAYS ENSURE THAT
THE FIREARM IS UNLOADED AND CLEARED WITH THE SAFETY ON AND
POINTED IN A SAFE DIRECTION. FAILURE TO COMPLY COULD RESULT IN
INJURY OR DEATH.
THIS PRODUCT CONTAINS A BUTTON BATTERY.
IF SWALLOWED, A LITHIUM BUTTON BATTERY CAN CAUSE SEVERE OR
FATAL INJURIES WITHIN 2 HOURS.
KEEP ALL BATTERIES OUT OF REACH OF CHILDREN.
IF YOU THINK BATTERIES MAY HAVE BEEN SWALLOWED OR PLACED
INSIDE ANY PART OF THE BODY, SEEK IMMEDIATE MEDICAL ATTENTION.
WARNING UNLOAD/CLEAR
WARNING BUTTON BATTERY
9
OPERATION
Installing the Battery
The battery cap is located on the right side of the optic and is threaded into the
housing.
1. Use a properly sized at blade tool in the slot, turn counterclockwise to remove.
2. Install a fresh CR1632 coin cell battery with the positive (+) side facing out.
3. Install battery cap by carefully threading it clockwise into the housing until it
is tight against housing. Periodically check cap during use to ensure it is fully
tightened.
BATTERY CAPCR1632 BATTERY
10
Turning Sight On and O
• Turn the sight ON by pressing and holding the ▲(UP) brightness button for over 1
second. Turn the sight OFF by repeating the same procedure.
• FOR CIRCLE/DOT MODELS ONLY - To cycle through the reticles (dot, circle, and
circle/dot combination) press and hold the ▼(DOWN) brightness button for over 1
second. Release the button when the desired reticle is being displayed.
• The ROMEO-X features MOTAC (Motion Activated Illumination System). If the
illuminated reticle does not detect motion for 2 minutes, it automatically shuts
off. The instant the optic detects motion, it powers on returning to the previous
brightness and reticle setting.
• The ROMEO-X has 15 brightness settings, 12 daylight and 3 night vision. While the
sight is ON, increase the brightness of the reticle by pressing and releasing the ▲
(UP) brightness button until the desired brightness level is reached. To decrease
the brightness, press and release the ▼(DOWN) brightness button. The reticle will
blink 5 times when the highest or lowest setting is reached.
