User‘s Guide
24 Port Nway
Fast Ethernet Switch
Model
:065-7341
SIGNAMAX LLC • www.signamax.eu
FCC Warning
This device has been tested and found to comply with limits for a
Class B digital device, pursuant to Part 2 and 15 of FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates and
radiates radio frequency energy and, if not installed and used in
accordance with the user’s manual, it may cause interference in
which case users will be required to correct interference at their
own expenses.
CE Warning
This is a Class B product. In a domestic environment, this
product may cause radio interference in which case the user may
be required to take adequate measures.
SIGNAMAX LLC • www.signamax.eu
Introduction
065-7341 switch provides 24 10/100M ports. 065-7341 switch
was designed for easy installation and high performance in an
environment where traffic is on the network and the number of
users increases continuously.
The compact rigid desktop size was specifically designed for
small to medium workgroups. 065-7341 switch can be installed
where space is limited; moreover, it provides smooth network
migration and easy upgrade to network capacity.
SIGNAMAX LLC • www.signamax.eu
Package Contents
Before you start to install this switch, please verify your package
that contains the following items:
One 065-7341 Fast Ethernet Switch
One Power Cord
One CD with User’s Manual
Note: If any of these items is found missing or damaged, please
contact your local supplier for replacement.
SIGNAMAX LLC • www.signamax.eu
Key Features
24 Port 10/100M Nway (Auto-negotiation) Switch
11” Desktop size with metal case
Can be installed in a 19” cabinet by rack-mount kits
Auto-learn of networking configurations
Auto-detect full/half-duplex modes for any port
Dedicated full-duplex 200Mbps bandwidth
Store-and-Forward switching methods
IEEE 802.3x flow control for full-duplex and back-pressure
flow control for half-duplex
Non-blocking & Non-head-of-line blocking full wire speed
forwarding
Auto-MDI/MDI-X function for any port
Smart plug & play
Front Panel (LEDs)
LED Indicators of 24 Port 10/100M Switch
LED Status Description
On Power is on.Power
Off Power is off.
On Port is for
connection.
Off No connection.
LINK/ACT
Flashing
Data is transmitting or
receiving
On Port is on 100M status
10/100M
Off Port is on 10M status.
SIGNAMAX LLC • www.signamax.eu
Connections
Switch/Hub to 065-7341 Fast Ethernet Switch
065-7341 switch provides automatic crossover detection
functionality for any port. It is simple and friendly to up-link to
another switch without crossover cable.
PC/Other devices to 065-7341 Fast Ethernet Switch
Via a twisted pair cable straight through, 065-7341 switch can be
connected to PCs, servers and other network devices.
SIGNAMAX LLC • www.signamax.eu
Rear Panel (Power)
AC input
AC input (100~240V/AC, 50~60Hz) UL Safety
Technical Specifications
Standards
IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3x Flow control
Features
Number of Ports: 24
MAC Address: 4K
Buffer Memory: 1.5 MB
Method: Store and Forward
Filtering/
Forwarding Rates
100Mbps port – 148,800pps
10Mbps – 14,880pps
Transmission Media
10BaseT Cat. 3, 4, 5
UTP/STP
100BaseTX Cat. 5 UTP/STP
LED Indicators
Per Port: LINK/ACT,
10/100M
Per Unit: Power
Power Requirement 100~240V/AC, 50~60Hz
Power Consumption 12 Watts (Max)
Dimensions 266 × 160 × 44 mm
(L x W x H)
Weight 1.7 kg
Operating
Temperature 0 to 55℃
SIGNAMAX LLC • www.signamax.eu
Storage
Temperature -20 to 90℃
Humidity 10 to 90% RH
(non-condensing)
Certifications FCC Class B, CE
