SJ LTS Manuale utente

Product Description

Model: LTS

Product Specification

1/4

Touchscreen Digital Pressure Gauge

Digital Pressure Gauge

Touch screen buttons are more durable

and easier to operate than traditional

buttons

Circular arc percentage chart can simu-

late pressure values, helping prevent

overpressure

Connection location

Bottom mount

Nominal size

Scale ranges

0 ... 5 kPa to 0 ... 100 MPa, or other

equivalent units of pressure, vacuum

or compound

Pressure units

MPa, kg/cm2, bar, psi, mmH2O, kPa,

Pa, inWC, mbar, mH2O, inHg, mmHg,

Torr (Up to 8 units can be switched,

if not specified, the engineer will

select it according to the pressure

range)

Voltage supply

AA battery*3

Optional external power supply:

DC24V, DC5V, or with other trans-

formers such as AC110V.

Protection level

IP 40

Medium temperature

-35℃ ... 60℃

Display

5.5 digits

LCD, switchable backlight button

Response time

18 times/sec

Accuracy

±0.4% F.S. (standard), ±0.2% F.S.

Process connection

304 SS

PT: 1/4", 1/2"

G: 1/8", 1/4", 3/8", 1/2", 7/8"

NPT: 1/4", 1/2"

M: 12*1.5, 10*1.0, 10*1.5, 14*1.5,

20*1.5

Case/Ring

304 SS

Sensor element

316 SS

Product Specification

2/4

Connection location

Bottom mount

Nominal size

Scale ranges

0 ... 5 kPa to 0 ... 100 MPa, or other

equivalent units of pressure, vacuum

or compound

Pressure units

MPa, kg/cm2, bar, psi, mmH2O, kPa,

Pa, inWC, mbar, mH2O, inHg, mmHg,

Torr (Up to 8 units can be switched,

if not specified, the engineer will

select it according to the pressure

range)

Voltage supply

AA battery*3

Optional external power supply:

DC24V, DC5V, or with other trans-

formers such as AC110V.

Protection level

IP 40

Medium temperature

-35℃ ... 60℃

Display

5.5 digits

LCD, switchable backlight button

Response time

18 times/sec

Accuracy

±0.4% F.S. (standard), ±0.2% F.S.

Process connection

304 SS

PT: 1/4", 1/2"

G: 1/8", 1/4", 3/8", 1/2", 7/8"

NPT: 1/4", 1/2"

M: 12*1.5, 10*1.0, 10*1.5, 14*1.5,

20*1.5

Case/Ring

304 SS

Sensor element

316 SS

Dimensions

Interface Description

3/4

Battery status

Peak value

Bar graph

Current

pressure

Pressure unit

1/4"PT

SW 24

48.7

46.5 100

52.5

71.5

Unit: mm

4/4

※ Ordering information

Model / Scale range / Accuracy / Process connection / Options

SIN JIA ENTERPRISE COMPANY LIMITED

TEL: +886-2-2550-4512

FAX: +886-2-2550-4510

[email protected]

www.sj-gauge.com

No.3, Ln. 71, Chifeng St., Datong Dist., Taipei City 103, Taiwan

For any changes to the specifications of this catalogue，the latest version shall prevail.

Operation Manual

Key functions

Touchscreen Type

Model: LTS

1/2

(3) PEAK

Press and hold to clear value

Press to switch to highest or

lowest peak

(1) Power

Press and hold to

turn on or turn off

(2) UNIT/ZERO

Press to switch the unit

Press and hold to zeroing

(4) BACKLIGHT

Press to turn on light

Press and hold to set the

constant time

Display

Font size:

H: 16 mm * W: 9 mm

How to set constant backlight?

How to reset?

1. Turn on.

2. Press and hold (4) BACKLIGHT to enter the menu.

3. Press (4) BACKLIGHT to change the ones digit to 0.

4. Press (2) ZERO/UNIT to switch to the tens digit, and press (4) BACKLIGHT to set the value to 0.

※ Do not set numbers other than 00, otherwise it will affect the factory settings and cause program confusion。

5. And press (3) PEAK again to complete the constant backlight setting.

1. Turn on.

2. Press and hold (4) BACKLIGHT to enter the menu.

3. Press (4) BACKLIGHT to change the ones digit to 9.

4. Press (2) ZERO/UNIT to switch to the tens digit, and press (4) BACKLIGHT to set the value to 9.

5. And press (3) PEAK to complete resetting.

Touchscreen Type

Model: LTS Operation Manual

2/2

How to adjust the update frequency?

How to set automatic shutdown time?

[Enter the menu]

1. Turn on.

2. Long press (4) BACKLIGHT to enter the first level menu.

3. Press (4) BACKLIGHT to toggle the ones digit to 6.

4. Press (2) ZERO/UNIT to switch to the tens digit, then press (4) BACKLIGHT to set the value to 9.

5. Press (3) PEAK to confirm to enter the second level menu.

[Setting]

6. Press (2) ZERO/UNIT or (4) BACKLIGHT to switch the screen to "SEF9", then press (3) PEAK to enter the

frequency setting.

7. The default value is "01", press (4) BACKLIGHT to adjust the value. (The larger the number, the lower the

update frequency and the more stable the display.)

[Exit the menu]

8. Press (3) PEAK to return to the second level menu.

9. Press (2) ZERO/UNIT or (4) BACKLIGHT to switch the screen to "SOUt", then press (3) PEAK to complete the

frequency setting.

[Enter the menu]

1. Turn on.

2. Long press (4) BACKLIGHT to enter the first level menu.

3. Press (4) BACKLIGHT to toggle the ones digit to 6.

4. Press (2) ZERO/UNIT to switch to the tens digit, then press (4) BACKLIGHT to set the value to 9.

5. Press (3) PEAK to confirm to enter the second level menu.

[Setting]

6. Press (2) ZERO/UNIT or (4) BACKLIGHT to switch the screen to "CLtt", then press (3) PEAK to enter the shut-

down setting.

7. The default value is "00", press (4) BACKLIGHT to adjust the value. (Number 01 is 1 minute, number 02 is 2

minutes, etc.)

[Exit the menu]

8. Press (3) PEAK to return to the second level menu.

9. Press (2) ZERO/UNIT or (4) BACKLIGHT to switch the screen to "SOUt", then press (3) PEAK to complete the

shutdown setting.
