SMC2655W
11Mbps Wireless Access Point
Support for up to 64 Wireless Users
The SMC 11Mbps Wireless Access Point is designed for
both business and home users, with a maximum
operating range of 4 0metres. It acts as a bridge
between the wired network and the wireless clients. The
Wireless Access Point enables the desktop wireless PCI
card users and the laptop wireless PC card users to
obtain seamless network connection. This new Access
Point features support for up to 64 wireless users, and
simple plug-and-play installation.
Great for mobile users, temporary work sites, and a
range of other applications, wireless technology
provides optimal mobility, simple and flexible
installation options, and excellent salability in
supporting additional PCs. The technology is also ideal
for use with cable modems, xDSL, or SOHO applications.
In typical wireless configuration, an Access Point
connects to a wired network. The Access Point connects
to a wired network. Users access the LAN via SMC
wireless adapters in their notebooks or desktops. The
wireless LAN adapters interface between the client
Network Operating System and the Access Point.
Features and Benefits
High Performance & Functionality
●Up tp 11Mbps wireless LAN
●Up to 4 0metres operating range
●2.4GHz frequency band
●Direct Sequence Spread Spectrum (DSSS)
●64-bit or 128-bit encryption
●Supports up to 64 users
●MAC Address Filtering
●Power Over Ethernet*
●SNMP Management Utility
Flexible System Management
●Instant access to shared information without the
need to plug in
●Network managers can set up, move, or expand a
new LAN with no need for installation or moving wires
●11Mbps performance will meet most foreseeable
networking needs
●Wireless LANs are tremendously convenient, help to
enhance productivity, and provide a real cost benefit
over traditional wired networks (no installation or
maintenance expenses)
●Plug-and-play; no configuration needed
●64-bit/ 128-bit WEP encryption and MAC address
filtering ensure secure network connection
●Reduces installation cost by using Power over Ethernet
which provides power to Access Point via a
Category cable
Compatibility
●IEEE 802.3, 802.11b
●Windows 98/ Me/ NT/ 2000
EZ Connect™ Wireless Access Point
SMC2655W
Data Sheet
Product Model No. Description
EZ Connect™ SMC26 W EZ Connect 11Mbps Wireless
Wireless Access Point Access Point
SMC26 W KIT EZ Connect 11Mbps Wireless
Networking Starter Kit
(includes an Access Point and
a Wireless PC Card)
SMCPWR-INJ EZ Connect Power Injector
Macintosh®OS
COMPATIB E
Windows®OS
Specifications
Physical Characteristics
Data ates
●11, . , 2, 1Mbps
Maximum Channels
●U.S. & Canada: 11
●Europe: 13
●Japan: 14
Maximum Users
●64
Operating ange
●Up to 4 0metres
adio Signal Type
●Direct Sequence Spread Spectrum (DSSS)
Encryption
●64-bit or 128-bit
Operating Frequency
●U.S. & Canada: 2.400 - 2.483 GHz
●Europe & Japan: 2.400 - 2.497GHz
Sensitivity
●Min.-76dBm for 11Mbps @BER 10E- ;
●Min.-80dBm for . / 2/ 1Mbps @BER 10E-
Modulation
●QPSK, BPSK, CCK
Output Power
●+1 dBm (minimum)
●0 mW (maximum)
Operating Systems
●Windows 98/ Me/ NT/ 2000
Network Management
●Windows 98/ Me/ NT/ 2000 SNMP utility
Size
●13.6 x 10.8 x 2.8 cm
Weight
●199.6gm
Current Consumption
●V, 7 0mA max
Temperature
●Operating: 32º - 122ºF
SMC Networks Europe
Head Office
Edificio Conata II
Fructuós Gelabert 6-8 20,4a
08970 - Sant Joan Despi
Barcelona
Spain
Telephone
+34 93 477 4920
Facsimile
+34 93 477 3774
SMC Networks
Spain
Calle Josefa Valcarcel, 8
28027 - Madrid
Spain
Telephone
+34 91 320 2884
Facsimile
+34 91 320 8438
SMC Networks
Northern Europe
Ground Floor, Exa House
Alexandra Court
Denmark Street
Wokingham
Berkshire, RG40 2SL
United Kingdom
Telephone
+44 (0)118 974 8700
Facsimile
+44 (0)118 974 8701
SMC Networks
Nordic
Vallingbyplan 26, 2 tr
SE-162 6 Vallingby
Sweden
Telephone
+46 (0) 8 687 0700
Facsimile
+46 (0) 8 87 62 62
SMC Networks
South Africa
Zonneblom Building
16th Road
Constantia Square
Midrand
South Africa
Telephone
+27 (0) 83 292 40 43
Facsimile
+27 (0) 11 80 80 60
SMC Networks
Southern Europe
2 - 8 rue des Bourets
921 0 Suresnes
France
Telephone
+33 (0) 1 41 38 32 32
Facsimile
+33 (0) 1 41 38 01 8
SMC Networks
Central Europe
Freischützstr. 81
D-81927 Munich
Germany
Telephone
+49 (0) 89 92861-0
Facsimile
+49 (0) 89 92861-230
SMC is a registered trademark; and EtherPower, EZStart, SimulTasking, TigerSwitch and SuperDisk are trademarks of SMC Networks, Inc.
Other product and company names are trademarks or registered trademarks of their respective holders. © Copyright 2001 SMC Networks, Inc.
●Storage: 32º - 1 8ºF
Humidity
●% to 80% non-condensing
Network Connection
●IEEE 802.3 - 10Mbps via RJ-4 port
●IEEE 802.11b - 11Mbps via antenna
Antenna
●Dual Dipole antenna
LED Indicators
●Link/ Activity
●Transmit/ Receive
●Power
Standards Conformance
Certification
●CE Mark
●FCC Part 1 Class B
●ETSI
●ANSI C63.4 - 1994
●CISPR 22: 1993 +AI: 199 + A2: 1996, Class B
●EN 011: 1998
●ETS 300-328
●EN60601-1-2: 1993
●IEC 801-2: 1991
●IEC801-3: 1984
Standards
●IEEE 802.3, 802.11b
SMCPWR-INJ - EZ Connect Power Injector**
Size
●.71 x .08 x 2. 4cm
Connectors
●Two RJ-4 Connectors: one labelled
●Access Point and one labelled Network
Voltage
●7-3 VDC
Weight
●0.10lbs
Wires Used
●Pins 4 and - Positive
●Pins 7 and 8 - Negative
L
i
m
i
t
e
d
L
i
f
e
t
i
m
e
W
a
r
r
a
n
t
y
L
i
m
i
t
e
d
L
i
f
e
t
i
m
e
W
a
r
r
a
n
t
y
www.smc.com
EZ Connect™ Wireless Access Point
SMC2655W
Data Sheet
