SMC Networks SMCWEBS-N Manuale utente

Key Features and Benefits

The SMCWEBS-N is an all-in-one networking solution for connecting and sharing

your high speed cable/xDSL internet connection. This multi-functional broadband AP

combines a 4-port 10/100Mbps LAN switch, a 300Mbps high speed Wireless-N

(802.11n) access point, and a user friendly web-based interface in one convenient

device.

SMCWEBS-N is Wi-Fi certified n for full compliance with 802.11n standards,

providing up to 300Mbps high speed wireless connection. With security being a key

consideration, SMCWEBS-N supports the latest WPA and WPA2 wireless encryption

standards, which prevent unauthorized access to wireless networks.

Product Overview

SMCWEBS-N

Wireless AP

Advanced, Robust Security

Wireless security is comprehensive and includes WPA/WPA2 PSK and

Enterprise as well as a WPS button to provide the ultimate convenience for

one touch secure connectivity.

Feature Rich

The SMCWEBS-N provides a multitude of features for the most demanding

network requirement including Wireless Distribution System (WDS), Dual

SSIDs, Quality of Service (QoS) and more.

Application Diagram

PHYSICAL

• 4-port 10/100Mbps LAN switch

• Two external detachable 2dBi antennas

• WPS button

• Reset button

MANAGEMENT FEATURES

• Web based management interface (HTTP)

• Firmware upgrade via web-interface

• Time synchronize

• UPnP

• LED indicators:

- Power

- LAN (Ethernet Link/Activity)

- WLAN (Wireless Link/ Activity)

- WPS (WPS in progress)

SECURITY FEATURES

• Access Control

• MAC, IP and Port filter

• SSID Broadcast disable

• Wireless MAC address filtering

• WEP 64-/128-Bit Encryption

• WPA-/WPA2-PSK (Pre-shared Key) , AES, TKIP

• WPA-/WPA2 Enterprise mode (802.1x)

• WiFi Protected Setup (WPS), PIN and PBC methods

TX Output Power (Typical)

• 802.11n: 17 +/- 1 dBm

• 802.11g: 17 +/- 1 dBm

• 802.11b: 20 +/- 1 dBm

DIMENSIONS

• (L)184.17*(W)137*(H)34.6mm

WEIGHT

• 255g

POWER REQUIREMENTS

• Input Voltage: 100V AC to 240V AC, 50 / 60Hz

• Output Power: 5V DC, 2A

COMPLIANCE

• FCC Part 15B Class B, Part 15C 15.247, 15.207 (2.4 GHz)

• EN 55022

• EN 55024

• EN61000-3-2, EN61000-3-3

• EN 300 328, EN 301 489-1, EN 301 489-17

SYSTEM REQUIREMENTS

• Broadband (Cable/xDSL) Internet service and modem with

Ethernet connection.

• 2.4GHz 802.11n draft wireless adapter or 2.4GHz 802.11b/g

wireless adapter installed on each PC. Alternatively an Ethernet

adapter may be used.

• Internet Explorer 5.5 or above, Mozilla Firefox 1.0 or above

PACKAGE CONTENTS

• SMCWEBS-N

• 5V, 2A power adapter

• RJ45 cable (1m)

• Quick Installation Guide

• Warranty information card

WARRANTY

Features

STANDARDS

• Wired: IEEE 802.3 (10Base-T)

IEEE 802.3u (100Base-TX)

• Wireless: IEEE 802.11b

IEEE 802.11g

IEEE 802.11n (draft 2.0)

OPERATING FREQUENCY

• FCC: 2412~2462MHz (Ch1~Ch11)

• ETSI: 2412~2472MHz (Ch1~Ch13)

• Japan: 2412~2484MHz (Ch1~Ch14)

TEMPERATURE

• Operating: 0ºC to 40ºC (32ºF to 104ºF)

• Storage: -20ºC to 60ºC (-4ºF to 140ºF)

HUMIDITY

• Operating: 10% to 85% Non-Condensing

• Storage: 5% to 90% Non-Condensing

WARRANTY

Please check www.smc.com for the warranty terms in your

country/region

Contact

North America

20 Mason, Irvine,

CA 92618, U.S.A.

1-800-SMC-4YOU

24/7 Technical Support

Europe/Africa

Fructuos Gelabert 6-8

08970 Sant Joan Despi

Barcelona, Spain

SMC Networks Asia Pacific

1 Coleman Street

#07-09, The Adelphi

Singapore 179803

Tel: 65-63387667 Fax: 65-63387767

Taiwan

No. 1 Creation Rd, lll,

Science-based Industrial Park,

Hsinchu 30077, Taiwan, R.O.C.

Tel: +886 3 5770270 Fax: +886 3 5780764

Check www.smc.com for your local country contact information

Networks. Other trademarks or registered trademarks are the

property of their respective owners. Information is subject to

V1.03
