SOLTEK SL-75DRV2 Manuale utente
R
The Soul Of Computer Technology
SL-75DRV2 USER MANUAL v1.0
NOTICE
Product Model : SL-75DRV2
Manual Revision : V1.0
Release Date : Septem er 2001
• AMD Athlon ThunderbirdTM, and DuronTM processors are trademarks of AMD Corporation.
• VIA, KT 266A, VT8366A and VT8233 are trademarks of VIA Corporation.
• Norton AntiVirus, Norton Ghost are trademarks of Symantec Corporation.
T
his Users Guide & Technical Reference is to help system
manufacturers and end users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for printing or
clerical errors. Information in this document is subject to change
without notice and does not represent a commitment on the part of
Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for identification
purpose only. Product names appearing in this manual may or may
not be registered trademarks or copyrights of their respective
companies.
Soltek Computer Inc. provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. In no event shall Soltek Computer Inc. be liable
for any loss or profits, loss of business, loss of use or data, interruption of
business, or for indirect, special, incidental, or consequential damages of
any kind, even if Soltek Computer Inc. has been advised of the possibility
of such damages arising from any defect or error in this manual or product.
Copyright 2001 Soltek Computer Inc. All Rights Reserved.
SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306 3, Ta Tung Rd, Sec.1, Hsi Chih, Taipei
Hsien, Taiwan, R.O.C.
Telephone : 886 2 2642 9060
Fax : 886 2 2642 9065
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth
erlands
Telephone : 31 10 2457492
Fax : 31 10 2457493
E mail : sales@soultech europe.com
Web site : http://www.soultech europe.com
75DRV2/
4
CONTENT
CHAPTER 1 INTRODUCTION ............................................... 8
1 1 MAINBOARD SPECIFICATION ................................................. 9
1 1.1 PROCESSOR ................................................................................... 9
1 1.2 CHIPSET ........................................................................................... 9
1 1.3 AWARD BIOS V6.0 SUPPORTING................................................... 9
1 1.4 SOUND CONTROLLER .................................................................... 9
1 1.5 POWER MANAGEMENT .................................................................. 9
1 1.6 FULL FEATURED ACCELERATED GRAPHICS PORTS (AGP)
CONTROLLER ................................................................................ 10
1 1.7 MULTI I/O FUNCTION .................................................................... 10
1 1.8 EXPANSION SLOTS ....................................................................... 10
1 1.9 ADVANCED HIGH PERFORMANCE SDR/DDR DRAM ................. 10
CONTROLLER ................................................................................ 10
1 1.10 FORM FACTOR ............................................................................ 11
1 1.11 HARDWARE MONITOR ................................................................ 11
1 2 MAINBOARD LAYOUT ............................................................ 12
1 3 CHIPSET DIAGRAM................................................................ 13
CHAPTER 2 HARDWARE SETUP....................................... 15
2 1 CPU INSTALLATION ............................................................... 16
2 2 MEMORY INSTALLATION ....................................................... 17
2 3 ACCELERATED GRAPHICS PORT(AGP) PRO INSTALLATION ... 19
2 4 HDD/FDD INSTALLATION ....................................................... 20
2 5 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE 22
2 5.1 Information On AMD Socket 462 Processor (Model 4, 5 Products) ... 22
2 5.2 Information On AMD Socket 462 Processor (Model 6, 7 Products) ... 23
5
Content
2 5.3 Frequency Ratio Select (By SW1 DIP1 DIP5) ................................ 24
2 5.4 Processor Core Voltage Select (By SW2 DIP1 DIP6) ..................... 25
2 5.5 CPU External Frequency Setting (By SW3) .................................... 26
2 6 JUMPER SETTING FOR DEVICES ON BOARD .................... 27
2 6.1 JP1/JP2 Memory Module Voltage Select ........................................ 27
2 6.2 JP17 Power Lost Resume ............................................................... 28
2 6.3 JP18/19 AGP Voltage Select ........................................................... 28
2 6.4 JBAT1 For Clear CMOS Data ......................................................... 29
2 7 CONNECTORS CONFIGURATIONS ...................................... 30
2 7.1 On Board FAN Connector (FAN1, FAN2, FAN3, FAN4) .................. 30
2 7.2 WOL1 Wake On LAN ...................................................................... 31
2 7.3 CD ROM Audio Connector (JCD_IN1) ............................................ 31
2 7.4 Thermal Sensor Connector (RT2) ................................................... 32
2 7.5 Complex Header CON1 .................................................................. 33
2 7.6 ATX Power Supply Connector ......................................................... 34
2 7.7 Chassis Panel Connector ............................................................... 35
2 7.8 Smart Card Reader Connector (SCR1) .......................................... 36
2 7.9 Communication And Networking Riser Slot (CNR) ......................... 37
2 7.10 USB Header (USB2/USB3 Header) .............................................. 38
2 7.11 PS/2 Mouse And PS/2 Keyboard .................................................. 38
CHAPTER 3 SOFTWARE SETUP ....................................... 40
3 1 OPEN UP THE SUPORT CD AND CHOOSE DRIVERS AND
UTILITIES ................................................................................ 41
3 2 PROCEED TO VIA 4 IN 1 DRIVERS INSTALLATION............ 42
3 3 PROCEED TO AC’97 AUDIO DRIVER INSTALLATION .......... 44
3 4 PROCEED TO HARDWARE MONITOR INSTALLATION ....... 45
75DRV2/
6
CHAPTER 4 BIOS SETUP ................................................... 48
4 1 WHAT IS BIOS SETUP............................................................ 49
4 2 HOW TO RUN BIOS SETUP ................................................... 49
4 3 WHAT IS CMOS ...................................................................... 49
4 4 WHAT IS POST ....................................................................... 49
4 5 BIOS UPGRADE ..................................................................... 49
4 5.1 BEFORE UPGRADING BIOS ......................................................... 50
4 5.2 UPGRADE PROCESS .................................................................... 50
4 6 BIOS SETUP CMOS SETUP UTILITY................................ 54
4 6.1 CMOS SETUP UTILITY .................................................................. 54
4 6.2 STANDARD CMOS SETUP ............................................................ 55
4 6.3 ADVANCED BIOS FEATURES ....................................................... 58
4 6.4 ADVANCED CHIPSET FEATURES ................................................ 62
4 6.5 INTEGRATED PERIPHERALS ....................................................... 67
4 6.6 POWER MANAGEMENT SETUP ................................................... 73
4 6.7 PNP / PCI CONFIGURATION ......................................................... 79
4 6.8 SMARTDOC ANTI BURN SHIELD ................................................. 82
4 6.9 FREQUENCY/VOLTAGE CONTROL .............................................. 84
4 6.10 LOAD OPTIMIZED DEFAULTS..................................................... 87
4 6.11 SET SUPERVISOR / USER PASSWORD .................................... 87
4 6.12 SAVE & EXIT SETUP.................................................................... 88
4 6.13 EXIT WITHOUT SAVING .............................................................. 88
APPENDICES ......................................................................... 90
APPENDIX 1 IDENTIFY BIOS VERSION & BIOS PART NUMBER ... 91
APPENDIX 2 IDENTIFYING MAINBOARD MODEL NUMBER .... 92
APPENDIX 3 TECHNICAL TERMS ............................................... 93
7
Content
Mainboard
====Support CD
====User’s Manual
====Bundled Bonus Pack CD
====Bundled Bonus Pack Manual
====Temperature Sensor Cable
====ATA66/100 IDE Cable
====RS232 Cable
FDD Cable
ITEM LIST CHECKUP
75DRV2
8
CHAPTER 1
INTRODUCTION
This chapter contains the following topics :
1-1 MAINBOARD SPECIFICATION
1-2 MAINBOARD LAYOUT
1-3 CHIPSET DIAGRAM
• This chapter briefly introduces the characteristics of the mainboards. It includes
the information regarding the chipset, CPU types, built in functions and layout.
Users will have more ideas about mainboards after reading this chapter.
Chapter 1 Introduction
9
1-1 MAINBOARD SPECIFICATION
1-1.1 PROCESSOR
• Supporting Socket A based AMD Athlon™/Duron™/Athlon 4™ processors.
• Supporting 200MHz & 266MHz FSB bus.
• Supporting Processor VID(voltage ID) and FID(Frequency ID) auto
detection.
1-1.2 CHIPSET
• North Bridge: VIA VT8366A KT 266A.
• South Bridge: VIA VT8233.
• LPC I/O ITE 8705.
1-1.3 AWARD BIOS V6.0 SUPPORTING
• Plug & Play V1.0.
• Flash Memory for easy upgrade.
• Year 2000 compliant.
• BIOS writing protection.
• SmartDOC Anti Burn shield.
1-1.4 SOUND CONTROLLER
• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio
Controller with Codec onboard.
1-1.5 POWER MANAGEMENT
• ACPI 1.0 compliant (Advanced Configuration and Power Interface).
• APM V1.2 compliant (legacy power management).
• Supporting ACPI suspend STR mode (Suspend To DRAM) and POS mode
(Power On Suspend).
• System event monitoring with two event classes.
• Supporting PS/2 Keyboard & Mouse power on.
• Supporting Wake On LAN (WOL) & Wake On Modem.
• Supporting real time clock (RTC) with date alarm, month alarm, and century
field.
• USB boot up Function.
75DRV2
10
1-1.6 FULL FEATURED ACCELERATED GRAPHICS PORTS
(AGP) CONTROLLER
• AGP v2.0 compliant.
• Supports Side Band Addressing(SBA) mode (non multiplexed address /
data).
• Supporting 66MHz 1x, 2x, and 4x modes for AD and SBA signaling.
1-1.7 MULTI-I/O FUNCTION
• Two UltraDMA 33/66/100 Master Mode PCI EIDE ports.
• Two UARTs for complete Serial Ports.
• One dedicated IR connector:
At third serial port dedicated to IR function either through the two complete serial
ports or the third dedicated port Infrared IrDA (HPSIR) and ASK( Amplitude Shift
Keyed) IR.
• Multi mode parallel connector supporting:
Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
One FDDs with drive swap function.
• Universal Serial Bus connector supporting:
USB v1.1 and Intel Universal HCI v1.1 compatible.
2 built in USB connectors, in addition to one internal USB header which requires
a USB cable to support 2 more optional USB ports.
• PS/2 keyboard connector.
• PS/2 Mouse connector.
1-1.8 EXPANSION SLOTS
• Five PCI bus Master slots.
• One CNR slot.
• One AGP PRO 4x mode slot.
• Three 184 pin DIMM slots.
• One SCR (Smart Card Reader) slot.
1-1.9 ADVANCED HIGH PERFORMANCE SDR/DDR DRAM
CONTROLLER
• Supporting memory size up to 3GB.
• Supporting 184 pin DDR SDRAM type only.
• Supporting PC1600 and PC2100 DDR SDRAM.
Indice
Altri manuali SOLTEK Scheda madre
SOLTEK
SOLTEK KT400-C Manuale utente
SOLTEK
SOLTEK SL-B8D-F Manuale utente
SOLTEK
SOLTEK SL-85DR Manuale utente
SOLTEK
SOLTEK SL-55D5 Manuale per l'uso e la cura
SOLTEK
SOLTEK B9A-FGR Manuale utente
SOLTEK
SOLTEK SL-75KIV Manuale utente
SOLTEK
SOLTEK SL-53A2 Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-67D Manuale utente
SOLTEK
SOLTEK 85DRV5-L Manuale utente
SOLTEK
SOLTEK SL-65DRV Manuale utente
SOLTEK
SOLTEK 75FRN2 Series Manuale utente
SOLTEK
SOLTEK SL-B5A-FG Manuale utente
SOLTEK
SOLTEK 85DIR Manuale utente
SOLTEK
SOLTEK B7A-F Manuale utente
SOLTEK
SOLTEK SL-75KV Manuale utente
SOLTEK
SOLTEK SL-63AV Manuale utente
SOLTEK
SOLTEK 86SP2 Manuale utente
SOLTEK
SOLTEK SL-75LIV Manuale utente
SOLTEK
SOLTEK SL-65KVB Manuale utente
SOLTEK
SOLTEK SL-55F5 Manuale utente
Manuali Scheda madre popolari di altre marche
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuale utente
Gigabyte
Gigabyte GA-9IVDT Manuale utente
Texas Instruments
Texas Instruments ADS8372EVM Manuale utente
Commell
Commell MS-C73 Manuale utente
IBT Technologies
IBT Technologies MB860 Manuale utente
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuale utente
