SOLTEK SL-85DR-C Manuale utente
Mainboard
SL-85DR-C User Manual V1.0
R
The Soul Of Computer Technology
his Users Guide & Technical Reference is to help system
manufacturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer nc. is not responsible for printing or
clerical errors. nformation in this document is subject to change
without notice and does not represent a commitment on Soltek
Computer nc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer nc.
Companies and products mentioned in this manual are for identification
purpose only. Product names appearing in this manual may or may
not be registered trademarks or copyrights of their respective
companies.
Soltek Computer nc. provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. n no event shall Soltek Computer nc. be liable
for any loss or profits, loss of business, loss of use or data, interruption of
business, or for indirect, special, incidental, or consequential damages of
any kind, even if Soltek Computer nc. has been advised of the possibility
of such damages arising from any defect or error in this manual or product.
Copyright © 2001 Soltek Computer Inc. All Rights Reserved.
NO ICE Product Model : SL-85DR-C
Manual Revision : V1.0
Release Date : ovember 2001
• ntel Pentium 4 and Northwood are trademarks of ntel Corporation.
• ntel 845-D is trademark of ntel Corporation.
SOLTEK AROUND THE WORLD
SOL EK COMPU ER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : 886-2-2642-9060
Fax : 886-2-2642-9065
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL ECHNOLOGY EUROPE B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth-
erlands
Telephone : 31-10-2457492
Fax : 31-10-2457493
E-mail : [email protected]
Web site : http://www.soultech-europe.com
SOL EK KOREA INC.
Address : 1002, Chung Jin Bldg. 53-5 Wonhyo-Ro, 3-Ka,
Yongsan-Ku Seoul 140-113, Korea
Telephone : 82-2-32717400
Fax : 82-2-32717405
E-mail : [email protected]
85DR-C
4
CO TE T
Chapter 1 Specification ............................................................ 8
1-1 Mainboard Specifications ...........................................................9
1-1.1 CPU Socket .................................................................................... 9
1-1.2 Sysem Chipset Architecture ........................................................... 9
1-1.3 Memory .......................................................................................... 9
1-1. AWARD BIOS V6.0 ....................................................................... 9
1-1.5 Hardware Monitoring ..................................................................... 9
1-1.6 Sound Controller .......................................................................... 10
1-1.7 Multi-I/O Function ....................................................................... 10
1-1.8 Expansion Slots ............................................................................ 10
1-1.9 Accelerated Graphics port (AGP) Interface ................................. 10
1-1.10 FORM FACTOR ........................................................................ 10
1-1.11 Power Management .................................................................... 11
1-2 Mainboard Layout .....................................................................12
1-3 Chipset System Block Diagram ................................................13
Chapter 2 Hardware Setup .................................................... 15
2-1 Pentium CPU Installation with Socket 78............................16
2-2 Pentium CPU Fan Installation: ..............................................17
2-3 Memory Installation ..................................................................18
2-3.1 To Install DIMM Module ............................................................. 18
2-3.2 To Remove a DIMM: ................................................................... 18
2- AGP X (Accelerated Graphics Port) Installation ..................19
2-5 HDD/FDD Installation ..............................................................20
2-6 Jumper and Switch Settings ......................................................22
2-6.1 Switch 1 CPU Clock Select......................................................... 23
2-6.2 Factory Test (By JP2) ................................................................... 2
2-6.3 Memory Module Voltage Select (By JP3/JP ) ............................. 2
5
Content
2-6. JP13 Memory Stick/Secure Digital Memory Card Select............ 25
2-6.5 AGP Voltage Select (By JAGP1/JAGP2) ..................................... 25
2-6.6 JBAT1 Clear CMOS ..................................................................... 26
2-7 Other Connectors Configuration ...............................................27
2-7.1 On Board FAN Connectors (FAN1,FAN2, FAN3) ...................... 27
2-7.2 WOL1 Wake On LAN .................................................................. 28
2-7.3 CD-ROM Audio Connector (CD9/CD10) ................................... 29
2-7. Thermal Sensor Connector RT2 (Optional) ................................. 30
2-7.5 Complex Header NJ1 ................................................................... 31
2-7.6 ATX Power Supply Connectors version 2.03 for Pentium ........ 33
2-7.7 CMEM1 Memory Stick/Secure Digital Memory Card Connector.. 3
2-7.8 Communication And Networking Riser Slot (CNR) ................... 35
2-7.9 Smart Card Reader Connector (SCR1) ........................................ 36
2-7.10 USB Header (Header USB1) ..................................................... 37
2-7.11 PS/2 Mouse And PS/2 Keyboard................................................ 37
2-7.12 Chassis Panel Connector ............................................................ 38
2-8 IRQ Description ........................................................................39
Chapter 3 Software Setup ...................................................... 41
3-1 Open up the Support CD and choose Drivers and Utilities ...... 2
3-2 Install “Intel Chipset Software Installation Utility” .................. 3
3-3 Install “Intel Application Accelerator” ......................................
3- AC’97 Audio Driver Installation ............................................... 6
3-5 Install Hardware Monitor Utility .............................................. 7
3-5.1 Installation ................................................................................... 7
3-5.2 Verification .................................................................................. 8
Chapter 4 BIOS Setup............................................................ 50
-1 About BIOS Setup .....................................................................51
-2 To run BIOS Setup ....................................................................51
85DR-C
6
-3 About CMOS.............................................................................51
- The POST ( Power On Self Test ) .............................................51
-5 To upgrade BIOS.......................................................................52
-5.1 Before Upgrading BIOS ............................................................... 52
-5.2 Upgrade Process ........................................................................... 52
-6 BIOS Setup --- CMOS Setup Utility.........................................55
-6.1 CMOS Setup Utility ..................................................................... 55
-6.2 Standard CMOS Setup ................................................................. 56
-6.3 Advanced BIOS Features ............................................................. 59
-6. Advanced Chipset Features .......................................................... 63
-6.5 Integrated Peripherals................................................................... 66
-6.6 Power Management Setup............................................................ 72
-6.7 PNP / PCI Configuration .............................................................. 77
-6.8 SmartDoc Anti-Burn Shield ......................................................... 80
-6.9 Frequency/Voltage Control .......................................................... 82
-6.10 Load Optimized Default ............................................................. 85
-6.11 Set Supervisor / User Password.................................................. 86
-6.12 Save & Exit Setup ...................................................................... 87
-6.13 Exit Without Saving ................................................................... 87
Appendices .............................................................................. 89
Appendix-1 Identifying BIOS version and BIOS part Number .....90
Appendix-2 Identifying Mainboard model Number ......................91
Appendix-3 Technical Terms...........................................................92
7
Content
Mainboard
Support CD
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Temperature Sensor Cable (Optional)
ATA66/100 DE Cable
RS232 Cable
FDD Cable
User’s Manual
ITEM LIST CHECKUP
8
85DR-C
Chapter 1 Specification
• This chapter introduces the characteristics of this series of mainboards.
t includes the information on the chipset, CPU types, built-in functions
and layout. Users will have more ideas about this powerful series after
reading this chapter.
The topics contained in this chapter are:
1-1 Mainboard Specifications
1-2 Mainboard Layout
1-3 Chipset Diagram
Introduction
9
Chapter 1 Specification
1-1.1 CPU Socket
• CPU Socket 478B on board, supporting ntel® Pentium 4 and Northwood
processors in the 478-pin package for 400MHz System Bus.
1-1.2 Sysem Chipset Architecture
• NTEL 845-D Chipset Memory Control Hub (MCH):
To work with ntel Pentium 4 Processor for managing and arbitrating
between 4 interfaces:
-- the System Bus (Host nterface);
-- the memory nterface;
-- the AGP Port and the Hub nterface;
• MCH Clockings:
-- Asynchronous;
-- System Bus target speed at 400MHz;
-- AGP and Hub nterface constantly at 66MHz base;
• ntel CH2 Chipset (Second generation /O Controller Hub):
Communicating with ntel 845-D by the Hub interface at 66MHz/266MB/s;
-- Transmitting nterrupt related messages;
-- Transmitting Power management events;
-- Transmitting SM , SC , SERR indication messages;
1-1.3 Memory
2pcs of D MM on board for single / double sided D MMs, supported by
2.5V default voltage:
• ntel 845-D MCH directly supporting one channel of DDR SDRAM up to
2GB capacity.
1-1.4 AWARD BIOS V6.0
• Supporting Plug & Play V1.0.
• FLASH MEMORY for easy upgrade.
• Supporting B OS writing protection.
• Year 2000 compliant.
1-1.5 Hardware Monitoring
• Programmable control, status, to provide monitoring and alarm for flexible
desktop management of hardware temperatures. Utility Software is
enclosed in Support CD to help display monitoring statuses of:
-- 6 positive voltages, 3 types of hardware temperatures, 3 Fan speeds;
1-1 Mainboard Specifications
10
85DR-C
1-1.7 Multi-I/O Function
• ntegrated DE Controller, supporting:
-- 2x Ultra ATA100 / 66 / 33 Connectors
-- Two UARTs for Complete Serial Ports (2x COM ).
• Dedicated R Connector:
-- Third serial port dedicated to R function either through the two complete serial
ports or the third dedicated port nfrared- rDA (HPS R) and ASK (Amplitude Shift
Keyed) R.
• Multi-mode parallel connector:
-- Standard mode, ECP and EPP support.
• Floppy Disk connector:
-- One FDD connector with drive swap support.
• Universal Serial Bus connector:
-- USB V1.1 compliant.
-- 2 built-in USB connectors and one USB Header (USB1) which requires an
optional USB cable to provide 2 more optional USB ports.
• PS/2 Keyboard connector.
• PS/2 Mouse connector.
1-1.8 Expansion Slots
• Six PC bus Master slots.
• One AGP 4x mode slot.
• One CNR slot.
• One SCR1 slot.
• Two D MM slots.
• One CMEM1 slot.
1-1.9 Accelerated Graphics port (AGP) Interface
• One AGP slot on board is supported by the ntel 845-D Chipset MCH
AGP nterface in 1.5V mode (with AGP voltage selectable in B OS Setup):
-- AGP v2.0 compliant.
1-1.10 FORM FACTOR
• ATX form factor.
• This mainboard is compatible with both ATX Power Supply Version 2.03
(with +12V Power Connector) and the older ATX Power Supply (with
Peripheral Power Connector).
• Mainboard size: 30.5cm x 21.0cm.
Altri manuali per SL-85DR-C
1
Indice
Altri manuali SOLTEK Scheda madre
SOLTEK
SOLTEK SL-75DRV3/75DRV3+ Manuale utente
SOLTEK
SOLTEK SL-75DRV-X Manuale utente
SOLTEK
SOLTEK NF4-754RL Manuale utente
SOLTEK
SOLTEK SL-85DRV3 Manuale utente
SOLTEK
SOLTEK SL-63AV Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-85DIV Manuale utente
SOLTEK
SOLTEK SL-55B5 Manuale utente
SOLTEK
SOLTEK SL-B5A-FG Manuale utente
SOLTEK
SOLTEK SL-85LIR3 Manuale utente
SOLTEK
SOLTEK SL-865G3 Manuale utente
SOLTEK
SOLTEK SL-65MIV-C Manuale utente
SOLTEK
SOLTEK SL-75KAV Manuale utente
SOLTEK
SOLTEK SL-85DR Manuale utente
SOLTEK
SOLTEK SL-65MV Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-75KIV Manuale utente
SOLTEK
SOLTEK 75DRV Manuale utente
SOLTEK
SOLTEK SL-855GEI-FDGR Manuale utente
SOLTEK
SOLTEK SL-67D Manuale utente
SOLTEK
SOLTEK SL-53D2 Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-67B-W Manuale utente
Manuali Scheda madre popolari di altre marche
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuale utente
Gigabyte
Gigabyte GA-9IVDT Manuale utente
Texas Instruments
Texas Instruments ADS8372EVM Manuale utente
Commell
Commell MS-C73 Manuale utente
IBT Technologies
IBT Technologies MB860 Manuale utente
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuale utente
