Sonoff SNBZ-01 Manuale utente
SNBZ-01
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch • Manuel d'utilisation
2
English
3 –10
Čeština
11 –18
Slovenčina
19 –26
Magyar
27 –34
Deutsch
35 –42
Français
43 –50
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
4
The device can be operated intelligently via working with the SONOFF ZigBee Bridge to
communicate with other devices.
The device can work with other gateways supporting ZigBee 3.0 wireless protocol.
Detailed information is in accordance with the final product.
Operating instruction
1. Download APP
2. Add sub-devices
Connect the Bridge before adding the sub-device
Access eWeLink APP, select the Bridge that you want to connect, and tap “Add” to add a
sub-device. Then long press “RST” reset button on the device for 5s until the LED
indicator flashes three times, which means the device has entered the pairing mode,
and be patient until pairing completes.
If the addition failed, move the sub-device closer to the Bridge and try again.
5
Specifications
Model
SNZB-01
Working voltage
3V
Wireless connection
ZigBee (IEEE 802. 15. 4)
Working temperature
10~40°C
Working humidity
10-90% RH (non-condensing)
Material
PC
Dimension
43x43x16mm
Product Introduction
Features
SNZB-01 is a ZigBee low-energy wireless switch that allows you to move to any place.
Peel and stick. Connect it with the Bridge and you can create a smart to trigger other
devices.
Low-energy
Smart scene
Button action instruction
You can select to press once, press twice or long press the wireless switch to control the
connected device for various functions.
Manual switch
Reset button
LED indicator
6
Sonoff ZigBee Bridge supports connecting multiple sub-
devices at the same time.
Power the Bridge on, access the Bridge page in the eWeLink APP, and tap “Add”. Then
set the sub-device to be paired to the pairing mode and be patient until the pairing
completes.
Delete sub-devices
Long press the reset button on the sub-devices for 5s until the LED indicator flashes
three times. In this case, the sub-device is deleted from the Bridge successfully.
Users can delete sub-devices directly from the sub-device page on APP.
7
Installation methods
1. Placed on the desktop for use.
2. Tear off the protective film of the 3M adhesive and stick the device on
the desired area.
Do not install on the metal surface, otherwise it will affect the wireless
communication distance.
The device weight is less than 1 kg.
The installation height of less than 2m is recommended.
8
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
9
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: Wireless Switch
Model / Type: SNZB-01
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2014/53/EU
Directive No. 2011/65/EU as amended 2015/863/EU
10
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
