Sonoff DIY POWR3 Manuale utente

User manual V1.0

POWR3

中文 ----------1-5 English----------6-10 FCC Warning----------11

Wi-Fi Smart Switch with Energy Monitoring

SONOFF TECHNOLOGIES CO., LTD. 中文

使⽤说明

设备安装、故障维修请由专业资质电⼯操作，以免发⽣触电危险！

1.断电

2.接线

灯具󳰙线⽰󳞱󽘪

ON OF F

LIn

NIn

100-240V AC

LOut

电器接线⽰意:

LIn

NIn

LOut

N100-240V AC

确保零⽕线接⼊⽆误。

SONOFF TECHNOLOGIES CO., LTD. 中文

3.下载“易微联”APP 易微联

eWeLink

Android™ & iOS

4.上电

通电后，设备⾸次使⽤，默认进⼊快速配⽹模式(Touch)。Wi-Fi指⽰灯呈“两短⼀⻓闪烁”。

三分钟内没有进⾏配⽹，设备将退出快速配⽹模式。如需再次进⼊，⻓按配对按钮5秒直到

Wi-Fi指⽰灯呈两短⼀⻓闪烁即可。

5.添加设备

点击“+”，选择“快速添加”，再根据app提⽰进⾏操作。

SONOFF TECHNOLOGIES CO., LTD. 中文

如使⽤快速添加模式配⽹失败，请使⽤“兼容模式”进⾏配对。

兼容配⽹模式

1⻓按配对按钮5秒直到Wi-Fi指⽰灯呈“两短⼀⻓闪烁”状态，松开。再次⻓按配对按钮5秒

直到Wi-Fi指⽰灯呈“快闪”状态，此时设备进⼊兼容模式。

2在app界⾯，点击“+”，选择“兼容模式”。

产品参数

型号

输⼊

输󱲠

⽀持平台

Wi-Fi

外壳材料

产品规格

POWR3

100-240V~50/60Hz25AMax

IEEE802.11b/g/n2.4GHz

PCV0

162x122x45.5mm

Android&iOS

最⼤负载 5500W

⼯作温度 -10℃~40℃

产品介绍

设备重量＜1Kg，建议安装⾼度＜2⽶。

Wi-Fi信号指⽰灯(蓝⾊)

复位键

配对按钮/⼿动开关

Android设备:

只需输⼊Wi-Fi󲸹码，点击“下⼀步”等待配对完成。

iOS设备:

输⼊ W i - F i󲸹码，点击“ 下⼀步 ”再点击“ 去连接”，将移动设备连接上 W i - F i 账号为：

ITEAD-**********，密码为：12345678，然后回到“易微联”app，点击“下⼀步”，等待配对

完成。

SONOFF TECHNOLOGIES CO., LTD. 中文

产品特点

本设备是⼀款带电量统计功能的智能开关，⽤您的智能⼿机在任何地⽅打开或关闭家⾥的

设备，设置定时开/关、分享给您的家⼈⼀起控制等等。

远程控制智能定时/延时语⾳控制分享功能

电量统计智能场景

更换设备󶶘络

设备更换新的⽹络环境使⽤时，需⻓按设备配对󳬝钮5󶋒󵸌󱳬Wi-Fi指⽰灯󲁢两󵾪⼀⻓闪烁，

󴋀开，此时设备进⼊快速配⽹模式，即可再󴤣添加。

过载保护操作记录

Wi-Fi信号指⽰灯状态说明

快速闪烁

快速配⽹模式

两短⼀⻓闪烁

常亮

兼容配⽹模式

设备已连接

快闪⼀下找不到路由

快闪⼆下连接上路由，但没连上外⽹

快闪三下升级中

状态描述

指⽰灯状态

SONOFF TECHNOLOGIES CO., LTD. 中文

常⻅问题

2.蓝灯2秒快闪两下：说明设备已连接到了Wi-Fi但没有连上外⽹。

请确认您的Wi-Fi当前连接外⽹是否稳定、正常。如时好时坏，频繁出现这种双闪情况，说明您

的⽹络不稳定，并⾮产品原因。

问：设备添加成功后，显⽰离线，⽆法控制？

答：设备刚添加成功后，需要1-2分钟时间连接您的路由器并连⽹。如果⻓时间还是显⽰不

在线，请根据Wi-Fi指⽰灯的状态来判断：

1.蓝灯2秒快闪⼀下：说明设备没有连上您的Wi-Fi。

①可能是Wi-Fi密码输⼊不正确.

②可能是设备离您的路由器太远，信号太弱，或环境有⼲扰。请先将设备靠近路由器，如

⽆改善，重新添加⼀遍.

③设备不能识别5G的Wi-Fi，请选择2.4G的Wi-Fi重新添加.

④检查您的路由器后台是否开启MAC地址过滤，如有，请关闭。

如果以上均尝试不能解决，请⽤⼀部⼿机开启个⼈热点，尝试重新添加。

恢复出⼚设置

在eWeLinkapp端“删除设备”，设备即恢复出⼚设置。

SONOFF TECHNOLOGIES CO., LTD. English

To avoid electric shocks, please consult the dealer or a qualiﬁed professional for

help when installing and repairing!

1. Power oﬀ

Operating Instruction

ON OF F

LIn

NIn

100-240V AC

LOut

LIn

NIn

LOut

N100-240V AC

Appliance wiring instruction:

Make sure the neutral wire and live wire connection is correct.

2. Wiring instruction

Light ﬁxture wiring instruction:

3. Download APP

eWeLink

Android™ & iOS

4. Power on

After powering on, the device will enter the quick pairing mode (Touch) during the

ﬁrst use. The Wi-Fi LED indicator changes in a cycle of two short and one long ﬂash

and release.

The device will exit the quick pairing mode (Touch) if not paired within 3mins. If you

want to enter this mode, please long press the manual button for about 5s until the

Wi-Fi LED indicator changes in a cycle of two short and one long flash and release.

SONOFF TECHNOLOGIES CO., LTD. English

5. Add the device

Tap “+” and select “Quick Pairing”, then operate following the prompt on the APP.

Compatible Pairing Mode

If you fail to enter Quick Pairing Mode (Touch), please try “Compatible Pairing Mode ”

to pair.

Long press Pairing button for 5s until the Wi-Fi LED indicator changes in a cycle

of two short ﬂashes and one long ﬂash and release. Long press Pairing button

for 5s again until the Wi-Fi LED indicator ﬂashes quickly. Then, the device enters

Compatible Pairing Mode.

2Tap “+” and select “ Compatible Pairing Mode ” on APP.

SONOFF TECHNOLOGIES CO., LTD. English

POWR3

IEEE 802.11 b/g/n 2.4GHz

PC V0

Android & iOS

5500W

-10℃~40℃

Wi-Fi

Material

Dimension

Operating systems

Model

Input

Max.load

Working temperature

Output

Specifications

For Android system:

Enter Wi-Fi password and tap “Next”. Be patient until pairing completes.

For iOS system:

S elect Wi-Fi SSID with Enter Wi-Fi passw o rd, tap “Next ” a n d t h en “ Connect ”.

ITEAD-****** and enter the password 12345678, and then go back to eWeLink

app and tap “Next”. Be patient until pairing completes.

100-240V~50/60Hz25AMax

162x122x45.5mm

100-240V~50/60Hz25AMax

Reset button

Pairing button/Manual switch

Wi-Fi LED indicator(Blue)

Product Introduction

Wi-Fi LED indicator status instruction

Status instruction

Wi-Fi LED indicator status

Quick Pairing ModeFlashes (one long and two short)

Device is connected successfully

Keeps on

Flashes quickly Compatible Pairing Mode

Unable to discover the router

Upgrading

Connect to the router but fail to connect to Wi-Fi

Flashes quickly once

Flashes quickly three times

Flashes quickly twice

Features

Remote Control Single/Countdown

Timing

Share Control Voice Control

Smart Scene

This device is a Wi-Fi smart switch with power monitoring that allows you to remotely

turn on/oﬀ the device, schedule it on/oﬀ or share it with your family to control together.

Power Monitoring Over-load Protection History Operation Record

SONOFF TECHNOLOGIES CO., LTD. English
