Key Features

SA-FT3H

Flat Panel Speaker System



Flat Panel Matching 5.1 Satellite Speaker System



Specially developed flat drive that offer strong mid bass with

1-1/4" Depth)



Mica reinforced woofer cones for high power handling and

quick response



150W Powered Sub-Woofer with complimentary design to

the front speakers



Frequency extension up to 50KHz for the latest in high

resolution audio reproduction



Optional WS-FV20 Speaker Stands



Optional SS-FRF3H Satellite Speaker to transition from a 5.1

System to 6.1 or 7.1 system

Specifications

Audio

Impedance: Front and Satellite- 8 ohms, Center-

8ohms

Frequency Response: Front and Satellite-

140Hz-50,000Hz, Center- 150Hz-50,000Hz,

Subwoofer- 28Hz-200Hz

Woofer Size: Front and Satellite (each)- 4" (10cm),

Center- 3" (8cm) x2, Subwoofer- 6" (15cm) x2

Tweeter Size: Front and Satellite (each)- 1" (2.5cm),

Center- 1" (2.5cm)

Power

Power Consumption (in Operation): Subwoofer- 80W

Power Consumption (in Standby): Subwoofer- 0.3W

Power Requirements: Subwoofer- 120 V AC, 60Hz

Power Handling Capacity: 110 Watts

SA-FT3H

Weight

Front and Surround Speakers: Without Tabletop

Stands 1 lbs, 16 oz (900 g), With Tabletop Stands

2 lbs, 2 oz (950 g) Center Speaker: With

Tabletop Stand 1 lbs, 14 oz (850 g), With

Tabletop Stand 1 lbs, 16 oz (900 g) Subwoofer:

26 lbs, 7 oz (12 Kg)

Dimensions (WHD)

Front and Surround Speakers: Without Tabletop

Stands 4 8/11 x 14 1/6 x 1 4/15" (120 x 360 x

32mm), With Tabletop Stands 4 8/11 x 14 9/14 x

1 4/15" (120 x 372 x 32mm) Center Speaker:

With Tabletop Stand 16 13/14 x 3 7/15 x 1 4/15"

(430 x 88 x 32mm), With Tabletop Stand 16

13/14 x 3 6/7 x 2 3/5" (430 x 98 x 66mm)

Subwoofer: 7 1/6 x 18 7/9 x 13 9/10" (182 x 477

x 353mm)

UPC Code

0272426685080

©2005 Sony Electronics Inc.

Sony is a trademark of Sony. All other trademarks are property of their

respective owners.

Features and specifications are subject to change without notice.

Non-metric weights and measures are approximate.

Flat Panel Speaker System

SA-FT3H

®Sony Electronics Inc. • 16450 West Bernardo Drive • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com/dn Last Updated 2005-08-03
