USER MANUAL AND
INSTALLATION GUIDE
Springtree
DMX600
2(615) 599-1505 www.springtree.net
Table of Contents
Product Information
Description.................................................................................................................................3
Features....................................................................................................................................3
Safety Precautions....................................................................................................................3
Installation
Installation.................................................................................................................................4
Operation
Operating modes......................................................................................................................4
Touch buttons............................................................................................................................4
DMX Modes...............................................................................................................................5
Technical Specications
Dimensions................................................................................................................................6
Weight.......................................................................................................................................6
Warranty....................................................................................................................................6
Contact us.................................................................................................................................6
3
(615) 599-1505 www.springtree.net
Product Information
Features
Description
The DMX600 is a game-changing 24 volt, DMX-controlled power supply for Springtree LED
lighting modules. It can power up to (16) 30watt Spatial Flats, (8) 50watt Spatial Flats or (40) LED-
Board12 LED Modules.
Safety precautions
• To reduce the risk of electrical shock or re, do not expose this unit to moisture.
• Be sure that the local power outlet matches that of the required voltage for your unit.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user serviceable parts inside.
• Never plug this unit into a dimmer pack.
• This power supply is intended for indoor use ONLY.
• Always mount this unit in a safe and stable manner.
• Keep this manual for as long as you own this product!
• Low Voltage power (24v, 600w)
• DMX Control
• 2 operating modes (WW and RGBW)
4(615) 599-1505 www.springtree.net
Installation
To install the DMX600 you will need a dry, well-ventilated area
such as a electrical closet.
The DMX600 has 4 screw holes (2 per side) for mounting to the
wall. Be sure to leave room for the electrical and dmx wires and
connectors.
Do not block any vent holes.
Menu buttons
There are four buttons on the front of this unit: MENU, ENTER, UP and DOWN.
*Press MENU to choose your DMX mode and address as well as PWM (pulse width mod-
ulation) mode. There are 4 PWM modes to choose from. PWM is the rate of current pulses to the
LEDs. This aects how the lights appear to dim. Choose the mode that appears to work best with
your controller.
Operating modes
The DMX600 can operate in two modes:
Mode 1 - this mode is for use with warm white xtures. This mode will have only one DMX channel
(dimmer). Connections should look like the
picture on the right.
Connector 1 = + and R, Connector 2 = + and G
Connector 3 = + and B, Connector 4 = + and W
Mode 2 - this mode is MAINLY for use with RGBW xtures. (*see note for WW ZONE operation)
These lights use 5 DMX channels. RED, GREEN, BLUE, WHITE and DIMMER.
*NOTE* Mode 2 - WW ZONE operation. In addition to RGBW operation Mode 2 can op-
erate as a zone dimmer for WW xtures. Connection to the driver is the same as Mode 1 but the
driver operates as a 5 channel dimmer. Channel 1 = Zone 1 intensity, Channel 2 = Zone 2 intensity,
Channel 3 = Zone 3 intensity, Channel 4 = Zone 4 intensity and Channel 5 = Master Dimmer.
The mode selection is for entire driver. You cannot mix mode 1 and mode 2 on the same driv-
er.
Operation
5
(615) 599-1505 www.springtree.net
Operation - continued
Connections
The DMX600 can power up to (16) 30watt Spatial Flats, (8) 50watt Spatial Flats or (40)
LEDBoard12 LED Modules. The image below shows the DMX600 used with various combinations
of each light. Each of the 4 ports must not exceed 150 watts (120w recommended).
DMX Channels
6(615) 599-1505 www.springtree.net
• Input: AC 120V, 12A
• Output: DC 24V, 600W
• Dimensions: 15” x 8 1/4” x 2 7/8”
• Weight: 9.6lbs
TechnicalSpecications
Oce hours:
Monday-Friday, 8:30
AM to 5:00 PM CT
Telephone:
(615) 599-1505
E-mail:
Website:
www.springtree.net
Contact us
Springtree Media Group would like to thank you for choosing our company for
your lighting needs! If you have any questions or concerns, please contact us.
WARRANTY
1st YEAR - Parts and labor. Advanced replacement - First 90 days with shipping
covered by Springtree Media.
2nd YEAR - Repair/ Replace Springtree discretion. Return shipping covered by
customer.
