StarTech.com EC1U2F Manuale utente

ExpressCard Firewire & USB Card

EC1U2F Instruction Manual

Actual product may vary from photo

2 Port FireWire and 1 Port USB 2.0 ExpressCard Adapter

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation and usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting FireWire and USB devices to the ExpressCard . . . . . . . .2

Basic Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Instruction Manual

Thank for purchasing a StarTech.com 2 Port Firewire and 1 Port USB 2.0 ExpressCard

adapter. Providing a versatile connectivity solution, this device offers data transfer rates

of up to 480Mbps (when used with high-speed USB peripherals), and 400Mbps

(FireWire), providing the ideal platform for connecting any FireWire or USB peripheral.

IInnttrroodduuccttiioonn

Features

BBeeffoorreeYYoouuBBeeggiinn

•USB 2.0 and IEEE-1394a compliant

•Supports USB transfer rates up to 480 Mbps and USB 1.1 transfer rates up to 12

Mbps

•Supports FireWire 100/200/400 Mbps transfer rates

•One available ExpressCard Slot

System Requirements

•Compliant with ExpressCard / 34mm Type II standard

•1 x ExpressCard Adapter

Package Contents

This package should contain:

•1 x User Manual

•Windows 2000/XP/64-Bit/Vista

Instruction Manual

IInnssttaallllaattiioonnaanndduussaaggee

1. Insert the ExpressCard into an available ExpressCard / 54 or 34mm slot. Since this

card is hot-pluggable, this can be performed while the computer is on or off. Once

the card has been inserted, ensure the computer is powered, to proceed with

installation.

2. Windows will detect that the card has been inserted, and will prompt for driver

installation. To install the necessary software, follow the on-screen instructions. Once

the driver has been installed, the operating system will notify you that your new

hardware is ready for use.

Connecting FireWire and USB devices to the ExpressCard

To begin using your FireWire and USB peripherals with EC1U2F, simply insert the

FireWire or USB connector provided by the peripheral or attached cable as appropriate

into one of the ports provided by the ExpressCard.

Once USB and/or FireWire devices are connected to the ExpressCard, Windows will

request the required drivers for each device respectively. For further information

regarding the attached peripheral drivers, please consult the documentation that

accompanied the purchase of the peripheral device(s).

Please note: For peripherals requiring lower voltages, EC1U2F offers built-in power

capability. If more power is required, an external 5VDC power adapter (not included with

EC1U2F) can be connected to the power port on the ExpressCard.

Instruction Manual

If you find that the peripherals connected to EC1U2F (in the powered state) are not

functioning, or are not being detected, please ensure the following:

1. The drivers have been installed.

2. Any previous driver installations (if this product has been previously installed) have

been removed.

3. There are no conflicts with other device drivers. To determine this:

a. Browse to the Device Manager, by right-clicking on My Computer, and selecting

Manage. In the left pane, click on Device Manager.

b. Look for any exclamation marks (!) or question marks (?) listed next to the FireWire

controller card, in the right pane.

Basic troubleshooting

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

1394_6

6 ft. IEEE-1394 FireWire Cable 6-pin to 6-pin

1394_46_6

6 ft. IEEE-1394 FireWire Cable 4-6 M/M

FIRE46FM

IEEE-1394 Firewire 4-6 Adapter F/M

PEX2EC

PCI-Express to ExpressCard Adapter

USB2HAB6

6 ft High Speed Certified USB 2.0 Cable

USB2HAB10

10 ft High Speed Certified USB 2.0 Cable

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

SSppeecciiffiiccaattiioonnss

Bus Type ExpressCard

Connectors 1 x USB 2.0 Type A

2 x FireWire 6-pin

Power Adapter Optional 5V DC 1A (not included)

Maximum Data Transfer Rate 480Mbps for USB / 400Mbps for FireWire

OS Support Windows 2000/XP/64-BIT/Vista

Chipset TI

Regulatory Certifications CE, ROHS, FCC

Revised: 11 April 2007 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products

and to access exclusive interactive tools such as the Parts Finder and the

KVM Reference Guide. StarTech.com makes it easy to complete almost

any IT solution. Find out for yourself why our products lead the industry in

performance, support, and value.
