StarTech.com EC13942 Manuale utente

ExpressCard Firewire Card

EC13942 Instruction Manual

Actual product may vary from photo

2 Port ExpressCard IEEE-1394 Firewire Card

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation and usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Verifying successful installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting FireWire devices to the ExpressCard . . . . . . . . . . . . . . . .2

Basic Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Instruction Manual

Thank for purchasing a StarTech.com 2 Port ExpressCard IEEE-1394 Firewire Card.

Providing a versatile FireWire solution, EC13942 offers data transfer rates of up to

400Mbps, offering a stable platform for virtually any FireWire peripheral connection.

IInnttrroodduuccttiioonn

Features

BBeeffoorreeYYoouuBBeeggiinn

•High speed data transfer rates of up to 400 Mbps

•Compliant with IEEE 1394-1995, 1394a-2000 and OHCI 1.1 standards

•Supports asynchronous and isochronous data transfer modes

•One available ExpressCard Slot

System Requirements

•Hot swap capable - allows you to connect or disconnect devices without turning off

your notebook computer

•1 x 2 Port FireWire ExpressCard Adapter

Package Contents

•1 x 4-6 Pin FireWire Cable

This package should contain:

•1 x User Manual

Instruction Manual

IInnssttaallllaattiioonnaanndduussaaggee

1. Insert the ExpressCard into an available ExpressCard / 54 or 34mm slot. Since this

card is hot-pluggable, this can be performed while the computer is on or off. Once

the card has been inserted, ensure the computer is powered, to proceed with

installation.

2. Windows will detect that the card has been inserted, and will prompt for driver

installation. Follow the on-screen instructions. Once the driver has been installed,

the operating system will notify you that your new hardware is ready for use.

Connecting FireWire devices to the ExpressCard

To verify that the necessary drivers have successfully (automatically) been installed:

1. Right-click My Computer, then click Manage. Click on Device Manager.

2. Double click on the [+] symbol next to 1394 Bus Controller or IEEE 1394 Bus host

Controllers option. If the driver installation is successful, you will notice a Texas

Instruments OHCI Compliant IEEE 1394 Host Controller displayed.

Verifying successful installation

To begin using your FireWire peripherals with EC13942, simply insert the FireWire

connector provided by the peripheral or attached cable into one of the FireWire ports

provided by the ExpressCard.

Please note that for peripherals requiring lower voltages, EC13942 offers built-in power

capability. If more power is required, an external 12VDC (1A) power adapter (not

included with EC13942) can be connected to the power jack on the ExpressCard.

Instruction Manual

If you find that the peripherals connected to EC13942 (in the powered state) are not

functioning, or are not being detected, please ensure the following:

1. The drivers have been installed.

2. Any previous driver installations (if this product has been previously installed) have

been removed.

3. There are no conflicts with other device drivers. To determine this:

a. Browse to the Device Manager, by right-clicking on My Computer, and selecting

Manage. In the left pane, click on Device Manager.

b. Look for any exclamation marks (!) or question marks (?) listed next to the FireWire

controller card, in the right pane.

Basic troubleshooting

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

1394_6

6 ft. IEEE-1394 FireWire Cable 6-pin to 6-pin

1394_46_6

6 ft. IEEE-1394 FireWire Cable 4-6 M/M

FIRE46FM

IEEE-1394 Firewire 4-6 Adapter F/M

PEX2EC

PCI-Express to ExpressCard Adapter

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

SSppeecciiffiiccaattiioonnss

Bus Type ExpressCard

Connectors 2 x FireWire Ports

Power Adapter Optional 12V (1A) adapter not included

Maximum Data Transfer Rate 400 Mbps

OS Support Windows® 2000/XP/XP 64-bit/Server 2003/Vista

Dimensions 122x24.4x34.4 mm

Weight 35g

Revised: 19 February 2007 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products

and to access exclusive interactive tools such as the Parts Finder and the

KVM Reference Guide. StarTech.com makes it easy to complete almost

any IT solution. Find out for yourself why our products lead the industry in

performance, support, and value.
