StarTech.com FAN939775HP Manuale utente

Universal AMD/Intel CPU Cooler

FAN939775HP Instruction Manual

Actual product may vary from photo

Universal Intel/AMD Heatpipe CPU Cooler

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a Universal Intel P4/AMD Athlon Heatsink with fan.Designed to

fit a wide range of Intel and AMD processors, this extra-large heat sink and fan provides

maximum heat dissipation for your hard-working CPU. The fan is capable of moving up to

65 CFM and includes an External Speed Controller that allows you to customize the fan

speed, and in turn the air flow and noise level of the fan.

FFeeaattuurreess

• Universal design: Compatible with Intel P4 , LGA775 and AMD K7 , K8

• Nickel plated Heat Pipe and special welding techniques enable seamless connection

between fins and pipes, for maximum heat dissipation

• Three sets of heat pipes provide high thermal-conductive efficiency

• Easy installation

• Adjustable fan speeds enable control of noise and fan performance

BBeeffoorreeYYoouuBBeeggiinn

System Requirements

• Intel P4, LGA775 (Socket T) or AMD K7, K8, Opteron processor

• 1 available TX3 power connector

• ATX Form Factor case

Contents

This package should contain:

• Heat Pipe Main Unit (1)

• Frame with Fan (1)

• External Speed Controller (1)

• Screw kit (1)

• CPU Fixing bracket kit (1)

• Heatsink Paste (1)

• Instruction Manual (1)

Instruction Manual

PPaarrttssLLiisstt

Instruction Manual

Heat Pipe Main Unit Frame with Fan External Speed Controller

Screw kit Base/Retention Clip for

Intel P4 Socket 478

Base/Retention Clip for

Intel LGA775 (Socket T)

Retention Clip for AMD

Opteron & K8

Retention Clip for AMD

K7 & Intel P3

CAUTION: Computers contain sensitive electronic components that are easily damaged

by static electricity and excessive shock. When handling the mainboard and other

components, ensure you are properly grounded using an anti-static mat or similar

device. If anti-static equipment is not available, ground yourself by touching the exterior

of the computer case or another large metal surface before handling any peripherals.

Installing FAN939775HP requires that you open your computer case to disconnect and

reconnect wires. If you are unfamiliar with this kind of work, consider bringing your

computer to your local computer store for help.

IInnssttaallllaattiioonn

Note: Although FAN939775HP supports a variety of different CPUs, the illustrations below depict installation on an

Intel chipset. Installation steps are identical for both AMD and Intel chipsets, with the exception of the parts used.

When installing FAN939775 on a Socket AM2 system, please ensure that the motherboard already has the AM2

retention module (mounting bracket), and use the K8 clip.

Instruction Manual

1. Remove the original CPU

cooler and any devices used to

retain the CPU within the

socket.

4. Remove the protective film

from the base on the heat pipe

main unit. Place the main unit

on the CPU, aligning the holes

of the P4 clip with the posts.

7. Put the transparent frame onto

the main unit, directing the fan

as required by the structure of

your computer contents.

5. Place the retention clip inside

the frame of the heatpipe

base, then install the main unit

onto the CPU, being sure to

line the clip up with the posts.

3. Apply enough thermal paste to

the top of the CPU to cover the

entire top surface.

2. Place the base clip

backing onto the backside of

the motherboard

6. Tighten the posts to secure the

heatpipe unit onto the

mainboard.

8. Using the screw kit, screw the

frame into the main unit.

9. Connect the power cord from

the fan speed controller to the

main unit/frame.

11. Secure the fan speed

controller into an open slot on

the back of the computer.

10. Connect the remaining power

cable to the motherboard.

12. Check to make sure the main

unit is securely positioned on

the mainboard.

SSppeecciiffiiccaattiioonnss

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Heatsink Dimension 93 x 93 x 98.5 mm

DC Fan Size 92 x 92 x 25 mm

Base Material Heat Pipe

Bearing Type One Ball

Speed 1500 ~ 2800 RPM

Noise Level 18 ~ 28 dBA

Max Air flow 30 ~ 60 CFM

Rated Voltage 12 V.DC

Weight 950 g

Regulatory Certifications FCC, CE

Revised: 15 March 2007 (Revision A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products

and to access exclusive interactive tools such as the Parts Finder and the

KVM Reference Guide. StarTech.com makes it easy to complete almost

any IT solution. Find out for yourself why our products lead the industry in

performance, support, and value.
