StarTech.com USB6N1DOCK Manuale utente

6-in-1 USB 2.0 Docking Station / Port Replicator

StarTech ID: USB6N1DOCK

Want more out of your laptop? This mobile docking station from StarTech.com gives you all the

convenience of a desktop system without losing the portability of a laptop. This six-in-1 expansion

kit gives your laptop two high-speed USB 2.0 ports, PS/2 keyboard and mouse ports, a parallel port,

a serial port, a USB data link port, and a 10/100 Mbits/sec Ethernet port.

The USB6N1DOCK is lightweight and compact so it can travel anywhere your laptop does. The docking

station plugs into your laptop’s USB port and is perfect for users who want maximum performance in

minimum space.

USB 2.0 certified by the USB-IF

Applications and Solutions

> Connect serial, parallel, USB, Ethernet and PS/2 devices to your system

> Has the ability to create a direct USB-to-USB data exchange channel between two computers

Features

> Adds a Parallel, Serial, 10/100 Mbits/sec Ethernet LAN, PS/2 Keyboard/Mouse and two USB 2.0

ports to your laptop or desktop system

> Backward compatible with USB 1.1 devices

> Easy Plug and Play installation

> Occupies only one USB port, while providing ample connectivity

> USB 2.0 certified by the USB-IF

> Users can add on/daisy chain additional hubs or docking stations for increased connectivity

Specifications

> Color Black

> Connector Types 1 - USB B Female

> Connector Types 2 - USB A Female

> Connector Types 1 - DB25 Female

> Connector Types 1 - DB9 Male

> Connector Types 2 - DIN 6 Female

> Connector Types 1 - RJ45 Female

> Enclosure Type Plastic

> Product Height 0.98 in [2.5 cm]

> Product Length 7.01 in [17.8 cm]

> Operating Temperature 0 to 50

> Power Adapter Included Yes

> Power Adapter - Amperage 2.5A

> Power Adapter - DC Voltage 5V DC

> Center Tip Polarity Positive

> Carton Quantity 20

> Industry Standards USB 2.0

> Industry Standards IEEE 1294

> Industry Standards IEEE 802.3

> Industry Standards USB 1.1

> Storage Temperature -20 to 70

> USB-IF Certified Yes

> Shipping (Package) Weight 1.28 lb [0.58 kg]

> Product Weight 5.65 oz [160 g]

> Product Width 2.17 in [5.5 cm]

> Power Bus Powered or Self Powered
