Supermicro X13SRA-TF Manuale utente

X13SRA-TF

ENGLISH

繁體中文

简体中文

日本語

한국어

QUICK REFERENCE GUIDE

Revision 1.00

Standardized Warning Statements

Motherboards

About Standardized Warning Statements

The following statements are industry standard warnings, provided to warn the user of situations where bodily injury

might occur. Should you have questions or experience di󰀩culty, contact Supermicro's Technical Support Department

for assistance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the Supermicro chassis.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or an equiva-

lent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.

警告

電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有電池。請按照製造商的說明指示處理

廢棄舊電池。

警告

电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更换原有电池。请按制造商的说明处理

废旧电池。

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメーカーが推奨する型、または同等のもの

を使用下さい。使用済電池は製造元の指示に従って処分して下さい。

경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제조사에서 권장하는 동등한

종류의 배터리로만 교체해야 합니다. 제조사의 안내에 따라 사용된 배터리를 처리하여 주십시오.









Note: For complete product safety information, refer to https://www.supermicro.com/about/policies/safety_information.cfm.

X13SRA-TF QUICK REFERENCE GUIDE Product Safety Information

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

X13SRA-TF QUICK REFERENCE GUIDE 限用物質含有情況標示聲明書

限

用

物

質

含

有

情

況

標

示

聲

明

書

設備名稱：主機板 /

Motherboard

型號（型式）：X13SRA-TF

單元Ｕnit

限用物質及其化學符號

鉛Lead

(Pb) 汞Mercury

(Hg) 鎘Cadmium

(Cd)

六價鉻

Hexavalent

chromium

(Cr+6)

多溴聯苯

Polybrominated

biphenyls

(PBB)

多溴二苯醚

Polybrominated

diphenyl ethers

(PBDE)

主機板

(Motherboard)

－○○○○○

備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準

值。

備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。

備考3.〝－〞係指該項限用物質為排除項目。

Equipment name

Type designation (Type)

Restricted substances and its chemical symbols

Declaration of the Presence Condition of the Restricted Substances Marking

Note 1

：

“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the

reference percentage value of presence condition.

Note 2

：

“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.

Note 3

：

The “−” indicates that the restricted substance corresponds to the exemption.

AMI BIOS POST Codes

About AMI BIOS POST Codes

The table below lists some of AMI BIOS POST codes for this motherboard. For more information, refer to https://www.

supermicro.com/manuals/other/AMI_AptioV_BIOS_POST_Codes_for_SM_Motherboards.pdf.

Code Description

0x32 CPU post-memory initialization is started

0x55 No Memory detected or memory failed

0x63 CPU DXE initialization is started

0x69 North Bridge DXE initialization is started

0x70 South Bridge DXE initialization is started

0x92 PCI Bus initialization is started

0x99 Super IO Initialization

0x9A USB initialization is started

0xA0 IDE initialization is started

0xA9 Boot into BIOS setup menu

0xAE Legacy Boot event

0xB2 Legacy Option ROM Initialization

0xB4 USB hot plug

0xD6 No console output devices are found

0xD7 No console input devices are found

0xF2 Recovery process started

0xF9 Recovery capsule is not found

X13SRA-TF QUICK REFERENCE GUIDE BIOS POST Codes

M.2 Device Installation

X13SRA-TF QUICK REFERENCE GUIDE

Note 1: It is strongly recommended that you install a heatsink on the M.2 device or use a M.2 device

with a built-in heatsink.

Note 2: Be sure to install the M.2 device(s) prior to placing the motherboard into a chassis.

This motherboard has two M.2 M-key sockets that support the 2280 and 22110 M.2 devices.

One stando󰀨 and a screw are pre-installed into the position of each 22110 mounting hole.

Refer to the illustration below for the locations of M.2 sockets and mounting holes. Follow

the steps on the next two pages to install the M.2 device.

SP1

X13SRA-TF

DESIGNED IN USA

REV:1.01

22110

2280

2280 M.2 Device Installation

X13SRA-TF QUICK REFERENCE GUIDE 2280 M.2 Device Installation

1. Locate the pre-installed standoff and

screw. Remove the screw and set it aside.

2. Using a hex socket screwdriver, remove

and then re-install the stando󰀨 to the posi-

tion of the 2280 mounting hole.

3. Insert the M.2 device into the M.2 socket

at a 30-degree angle and press it down.

4. Tighten the screw to secure the M.2 device

into place. Do not overtighten so as to

avoid damaging the M.2 device.

22110 M.2 Device Installation

X13SRA-TF QUICK REFERENCE GUIDE 22110 M.2 Device Installation

1. Locate the pre-installed screw. Remove

the screw and set it aside.

2. Insert the M.2 device into the M.2 socket

at a 30-degree angle and press it down.

3. Tighten the screw to secure the M.2 device

into place. Do not overtighten so as to

avoid damaging the M.2 device.

Memory Population

Note: Unbalanced memory conguration decreases memory performance and is not recommended for Supermicro

motherboards.

Memory Population

X13SRA-TF QUICK REFERENCE GUIDE

Memory Population Table

DDR5 Memory Population Table

DDR5 DIMMF1 DIMMF2 DIMME1 DIMME2

CPU

DIMMA2 DIMMA1 DIMMB2 DIMMB1

1DDR5

DDR5

2DDR5 DDR5

4DDR5 DDR5 DDR5 DDR5

6DDR5 DDR5 DDR5 DDR5 DDR5 DDR5

DDR5 DDR5 DDR5 DDR5 DDR5 DDR5

8DDR5 DDR5 DDR5 DDR5 DDR5 DDR5 DDR5 DDR5

DDR5 Memory Support for the Intel Xeon W Processors

Type Ranks Per DIMM

& Data Width

DIMM Capacity (GB)

Speed (MT/s); Voltage (V);

DIMM Per Channel (DPC)

1DPC (Note) 2DPC

16GB 1.1V

RDIMM

SRx8 (RC D) 16GB

4800 4400

SRx4 (RC C) 32GB

DRx8 (RC E) 32GB

DRx4 (RC A) 64GB

RDIMM 3DS (4R/8R) x4 (RC A) 2H-128GB

4H-256GB

*1DPC applies to 1 SPC (Sockets Per Channel) or 2 SPC implementation.

X13SRA-TF

Quick RefeRence Guide Rev. 1.00

SUPERMICR R

Motherboard Layout and Features

BAR CODE

IPMI CODE

MAC CODE

SAS CODE

JTPM1

SP1

USB9 (3.2)

(USB3.2 GEN2X2)

UID-LED

JPI2C1

M.2-C01 LED

M.2-C02 LED

JF1

JWD1

JPL1

JPUSB1

JPL2

JSD1

FAN2

HD AUDIO

AUDIO FP

JUIDB1

LED8

COM1

USB0/1

FANB FANC

BATTERY

DIMME2

DIMMF2

DIMMF1

DIMME1

DIMMA2

DIMMA1

DIMMB2

DIMMB1

SATA1

SATA0 SATA3

SATA2 SATA4

SATA5

M.2-C01

M.2-C02

JPME2

JL1

JCMOS

JBT1

JPW2

JPW3

FAN1

FANA

JSTBY1

CPU SLOT6 PCIe 5.0 X16

JOH1

JPW1

12V_

PUMP_PWR1

USB8

(USB3.2 GEN2X2)

VGA

CPU SLOT4 PCIe 5.0 X16

PCH SLOT1 PCIe 4.0 X4

CPU SLOT2 PCIe 5.0 X16

BMC LED

JSPDIF_OUT

JPAC1

CPU

PCH

BIOS LICENSE

LAN

CTRL

BMC

USB6/7

(USB3.2 GEN2)

LAN1

USB4/5

(USB3.2 GEN2)

LAN2

Power LED

(PCIe 5.0 X4)

X13SRA-TF

DESIGNED IN USA

REV:1.01

JRK1

(RAID Key Header)

JD1

(SPEAKER 1-4)

USB2/3 (3.0)

(USB3.2 GEN1)

LAN

CTRL

BACK PANEL I/O

LGA 4677

=mounting hole
