Sylvania SP269 Manuale
1
Bluetooth Mini Tower Speaker
Instruction Guide
MODEL NO.: SP269
2
3
Know your speaker
A:OFF/ON button
B:AUX
C:DC 5V
D:Bluetooth indicator light
Remote Control (only works under bluetooth
status )
OFF/ON A
1
2
46
3
57
C
D
B
AUX
DC 5V
4
1: Enter “Pairing” when the Bluetooth is
disconnected or when there is no connection.
2: Volume +
3: Volume -
4: Previous
5: Next
6: Pause/play
7: Remote control sensor light
Product Specications
- Dimension &weight :112 x 120 x 435mm
- weight : 1660g.
- standard battery :build in rechargeable 800mAh
lithium battery .
- Power supply of remote control : CR2025 DC
3V(included )
- Music play time :Max 3-4 hours (based on 50%-
60% volume )
- AC Adapter :110-240V (50-60Hz)
- Charging time : about 3-4 hours
Speaker Specications :
Diamter: ø 90mm + ø52mm
impedance :4 ohm
power output :3W x 2
Package& Accessories
- Speaker Unit
5
- Quick Start Guide
- AC Adapter(100-240V) 50-60Hz
- Audio cable
- Warranty card
Wireless function
- Frequency: 2.402-2.480 GHz
- Max transmission power rate: 2 grade, 4dBm
- Receiving sensitivity: -82dBm
- Transmission distance: within 10 meters
- Data transmission rate: 3Mbps
- Remote control sensor distance :>=3M
How To Use
1:Turn the switch to "ON" position , and speaker
will have a response ring,the blue and red
indication light blink alternaterly.bluetooth function
is available.the bluetooth speaker user name is
:Sylvania , the password is "0000" if needed.
AUX IN: Turn the switch to "ON" position ,connect
3.5mm AUX in cable (included ) to your music
device,then you can enjoy the music.
2:when connect to AC adapter (included )in, the
speaker can be charged when it's ON or OFF
status(we suggest to turn off speaker when charge
it.)
6
How to use remote control (below operations
are available only under bluetooth mode )
3. Press “+“, volume up;
4. Short press “ ” for previous song; Short press
“ ” for next song.
5. In the play mode, short press “ ” is pause/play
function;
6. Press Enter “Pairing” status when the
Bluetooth is disconnected .
7. The Bluetooth speaker can only match to one
signal per time.
8. It‘s not allow to show the same equipment name
in the Bluetooth connection list, or it will make the
one in same name can not be connected.
Points to keep your Bluetooth energetic
- The Bluetooth speaker has a anti signal disturb
design, but it will still be interrupted by the high
frequency device or within electromagnetic field.
Avoid to put it in such kind of environment.
- Different user port will make difference on the
transmission distance. Please use the qualify
Bluetooth port.
- Some cell phone music player device does not
have smooth cache, and it will be a slightly “POP“
tone when pause, it‘s a normal sound.
- The disconnection of Bluetooth is not a real time
7
operation, and it will be a few seconds delay from
the cell phone operation.
- When Bluetooth match is failed, delete other
Bluetooth device in the connection list, restart the
Bluetooth speaker and search the signal again.
- It must install a Bluetooth media player in the
computer when PC using the Bluetooth speaker.
- Please pull out the AUX-in cable before
connecting to the Bluetooth speaker, to make
sure the connection is correct.
- The speaker sound effect is affected by battery
capacity, cell phone performance and input media
source quality. If noise, user can download some
““0dB” music for test in AUX-in mode, in the
distance of 1m.
- If speaker will not be used for a long time, please
keep charge once per month, to avoid the over-
consumption of the battery to damage the speaker.
- Do not put the speaker in an extreme cold, hot,
wet or dusty environment, or it will be damage to
the function and device.
- Do not use the speaker in an extreme dry
environment, to avoid the static damage.
- Do not put the speaker into water or re.
- Do not scratch the speaker to protect the
interface and battery.
Thanks for using Our Bluetooth speaker
Enjoy music, enjoy life!
8
Haut-Parleur Bluetooth Mini
Guide d'instruction
N° DE MODÈLE : SP269
9
10
Apprenez à connaître votre enceinte
A. Bouton marche/arrêt
B. AUX
C. CC 5 V
D. Voyant Bluetooth
Télécommande (fonctionne uniquement sous
Bluetooth)
OFF/ON A
1
2
46
3
57
C
D
B
AUX
DC 5V
