Systembuild Evolution 3034335COM Manuale utente

3034335COM

StorageCabinet

B343034335COM0

ForthelatestinformationonSystemBuildproducts

followusatAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

AssemblyDifficultyMeter

Easy Tough

WARNING:Manufacturerassumesnoliability

forimproperinstallationorexcessiveloads

placedonscrewsorbracket.Thiswallanchor

isnotasubstituteforproperadultsupervision.

SecureYourFurniture

Keepyourhomeandfamilysafe

withthewallanchorkitthatis

includedwiththeproduct.



Seriousorfatalcrushinginjuriescan

occurfromtippingfurniture.

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐866‐452‐4081(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.systembuild.com

ContactUs!

HelpfulHints

2

systembuild.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐866‐452‐4081

Monday‐Friday

9am‐5pmCST

Visitsystembuild.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

ESTIMATEDASSEMBLYTIME:1HOUR

3

systembuild.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Tube

You

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



4

systembuild.com

Tube

You

5

systembuild.com

BoardIdentification

Notactualsize

Tube

You

This piece is

paperboard

construction. It is not

made from wood, but

is required for the

assembly of your unit.

LeftPanel

31117335010

RightPanel

31117335020

shelf(2)

31117335030

Bottom

31117335040

Adjustableshelf(2)

37362335060

Door(4)

33034335070

DrawerSide(2)

39991167346200C

DrawerBack

39991167051390B

DrawerFront

38235335080

DrawerBottom

39991341052210D

BackPanel

K111733500

DWR

SIDE

DWR

BACK

DWR

BTM

6

systembuild.com

BoardIdentification

Notactualsize

Tube

You

DWR

SIDE

DWR

BACK

DWR

SIDE

This piece is paperboard construction. It

is not made from wood, but is required

for the assembly of your unit.

DWR

BTM

7

systembuild.com

PartList

ActualSize

Tube

You

(x8)

#A22610

cambolt

(x8)

#A22620

camlock

(x8)

#A21660

wooddowel

(x10)

#A11080

7/16"flat

headscrew

(x10)

#A12120

7/16"round

headscrew

(x2)

#A11160

5/8"flat

headscrew

(x8)

#A12420

5/8"round

headscrew

(x4)

#A12930

1‐1/8"round

headscrew

(x2)

#A89020

bumper

(x4)

#A23030

confirmatscrew

(x42)

#A21110

nail

(x4)

#A21970

drivefastener

(x8)

#A17400

8‐32x7/8"

(x8)

#A80250

shelfsupport

(x1)

#A84050

safetybracketkit

17a

17b

17d

(x2)

#A89210

bumper

17c

(x2)

#A17200

8‐32x1/2"

8

systembuild.com

PartList

NotActualSize

23b

23a

23c

23d

(x5)

#A52680

handle

(x8)

#A65615

hinge

(x1)

#A54900

drawerbrace

(x2)

#A54520

drawerbracket

(x4)

#A44140

foot

leftcabinetmember

rightcabinetmember

leftdrawermember

(x1)

#A56770

drawerslidekit

rightdrawermember

9

systembuild.com

STEP1

Tube

You

2723a

(x4) (x3)

leftcabinetmember

(x1)

markedwith"L"

23a

finishededge

markedwith"L"

10

systembuild.com

STEP2

(x4) (x3) (x1)

markedwith"R"

rightcabinetmember

finishededge

markedwith"R"

23b
