Information About Cautions and Warnings

Preface

Read This First

About This Manual

This user’s guide is to assist the user with the operation of the EVM using the

ADS5102/3 devices.

How to Use This Manual

This document contains the following chapters:

-Chapter 1—Overview

-Chapter 2—Physical Description

-Chapter 3—Circuit Description

Information About Cautions and Warnings

This book may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

Contents

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

testedforcompliancewiththelimitsofcomputingdevicespursuanttosubpart

Jofpart15ofFCCrules,which aredesignedtoprovidereasonableprotection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Contents

vii

Contents

1 Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Purpose 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 EVM Basic Functions 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 ADS5102/3 EVM Operational Procedure 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Physical Description 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 PCB Layout 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Bill of Materials 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Circuit Description 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Circuit Function 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.1 Analog Inputs 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.2 External Reference Inputs 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.3 Clock Inputs 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.4 Control Inputs 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.5 Power 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.6 Outputs 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Schematic Diagram 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figures

2–1 Top Layer 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 Inner Layer 1, Ground Plane 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–3 Inner Layer 2, Power Plane 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–4 Bottom Layer 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

viii

Tables

1–1 Two Pin Jumper List 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–2 Three Pin Jumper List 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Bill of Materials 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 Reference Voltage Adjustment Ranges 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–2 Output Connector J15 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Notes, Cautions, and Warnings

Voltage Limits 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Overview

This user’s guide gives a general overview of the ADS5102/3 evaluation

module (EVM) and provides a general description of the features and

functions to be considered while using this module.

Topic Page

1.1 Purpose 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 EVM Basic Functions 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 ADS5102/3 EVM Operational Procedure 1-3. . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Purpose

1-2

1.1 Purpose

The ADS5102/3 EVM provides a platform for evaluating the ADS5102/3

analog-to-digital converter (ADC) under various signal, reference, and supply

conditions. Use this document in combination with the EVM schematic

diagram supplied.

1.2 EVM Basic Functions

Analog input to the ADC is provided via two external SMA connectors. The

single-ended input the user provides is converted into a differential signal at

the input of the device. One input uses a differential amplifier, while the other

input is transformer coupled.

TheEVMprovidesanexternalSMAconnectionforinputoftheADCclock.The

usercansendthisclocktotheoutputconnectorwiththedigitaldataorprovide

asecondclocksourcetobesentinplaceoftheADCclock.Thisallowstheuser

to provide the required setup and hold times of the output data with respect to

theoutputclock.Seethe Clock Inputssectionfortheproperconfigurationand

operation.

DigitaloutputfromtheEVMisviaa40-pinconnector.Thedigital linesfromthe

ADC are buffered before going to this connector. More information on this

connector can be found in the ADC output section.

PowerconnectionstotheEVMareviabananajacksockets.Separatesockets

are provided for the analog and digital supply.

In addition to the internal reference provided by the ADS5102/3 device,

options are provided on the EVM to allow adjustment of the ADC references

via an onboard reference circuit. A precision voltage reference source, a

resistor network, and an operational amplifier (op amp) provide the

ADS5102/3 device reference voltages REFT and REFB.

1.3 Power Requirements

The EVM can be powered directly with a single 1.8-V supply if using the

module with transformer coupled input, internal reference source, and 1.8-V

logic outputs.

Avoltageof3.3VisrequiredfortheDRVDDpowerinputtoprovide3.3-Vlogic

outputs. A voltage of ±5 V is required if using external references and/or

differential amplifier input. Provision has also been made to allow the EVM to

be powered with independent 1.8-V analog and digital supplies to provide

higher performance.

Voltage Limits

Exceeding the maximum input voltages can damage EVM

components. Undervoltage may cause improper operation of

some or all of the EVM components.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Texas Instruments Convertitore multimediale

Texas Instruments

Texas Instruments ADS5410 EVM Manuale utente

Texas Instruments

Texas Instruments DM6467 Manuale utente

Texas Instruments

Texas Instruments ADS79 EVM-PDK Series Manuale utente

Texas Instruments

Texas Instruments TPS53319EVM-136 Manuale utente

Texas Instruments

Texas Instruments TMS320DM36X Manuale utente

Texas Instruments

Texas Instruments EUROTEXT CF70200 Manuale utente

Texas Instruments

Texas Instruments UCC28517 Manuale utente

Texas Instruments

Texas Instruments TLC4541EVM Manuale utente

Texas Instruments

Texas Instruments TPS6100 EVM Series Manuale utente

Texas Instruments

Texas Instruments TPS548D21EVM-784 Manuale utente

Texas Instruments

Texas Instruments LP87524B-Q1 Manuale del prodotto

Texas Instruments

Texas Instruments TPS54320 Manuale utente

Texas Instruments

Texas Instruments DAC 3202 Series Manuale utente

Texas Instruments

Texas Instruments DAC 300 Series Manuale utente

Texas Instruments

Texas Instruments TPS40090EVM-002 Istruzioni per l'installazione e il funzionamento

Texas Instruments

Texas Instruments H.264 High Profile Encoder Manuale utente

Texas Instruments

Texas Instruments TVP5154A Manuale utente

Texas Instruments

Texas Instruments UCC2977EVM Manuale utente

Texas Instruments

Texas Instruments DAC63202W Manuale utente

Texas Instruments

Texas Instruments UCC2891 Manuale utente

Texas Instruments

Texas Instruments MSC1210 Manuale utente

Texas Instruments

Texas Instruments TPS53513 Manuale utente

Texas Instruments

Texas Instruments TIDA-060040 Manuale utente

Texas Instruments

Texas Instruments UCC28610EVM-474 Manuale utente

Manuali Convertitore multimediale popolari di altre marche

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuale utente

SPROLINK

SPROLINK VA1 Manuale utente

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuale utente

Nikon

Nikon AF-S TC-20E III Manuale utente

Axis

Axis AXIS Q7406 Manuale utente

Omega

Omega TAC80B-J Manuale utente

Zoom

Zoom Thunderbolt TAC-2R Manuale utente

OST

OST iConverter 10/100M Manuale utente

Vertiv

Vertiv Netsure Manuale utente

birddog

birddog MINI Manuale utente

Roland

Roland GI-10 Manuale utente

Wallenstein

Wallenstein WX310 Manuale utente

Pace

Pace MSS 200-1 Manuale utente

Solar Converters

Solar Converters EQ 12/24-50 Manuale utente

CYP

CYP EL-7400V Manuale utente

TIE

TIE MIDI 1i1o Manuale utente

DCS

DCS Vivaldi Upsampler Manuale utente

Westermo

Westermo MCW-211 SERIES Manuale utente
