Texas Instruments ADS5410 EVM Manuale utente

ADS5410 EVM

June 2002 AAP High-Speed Data Converter (Dallas)

User’s Guide

SLAU082

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,

enhancements, improvements, and other changes to its products and services at any time and to discontinue

any product or service without notice. Customers should obtain the latest relevant information before placing

ordersandshouldverifythatsuchinformationiscurrentandcomplete.AllproductsaresoldsubjecttoTI’sterms

and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in

accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI

deems necessary to support this warranty. Except where mandated by government requirements, testing of all

parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for

their products and applications using TI components. To minimize the risks associated with customer products

and applications, customers should provide adequate design and operating safeguards.

TIdoesnotwarrantorrepresentthatanylicense, eitherexpress orimplied, isgranted underanyTIpatent right,

inwhichTIproductsorservicesareused.InformationpublishedbyTIregardingthird–partyproductsorservices

does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.

Use of such information may require a license from a third party under the patents or other intellectual property

of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without

alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction

of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for

such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that

product or service voids all express and any implied warranties for the associated TI product or service and

is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM IMPORTANT NOTICE

Texas Instruments (TI) provides the enclosed product(s) under the following conditions:

This evaluation kit being sold by TI is intended for use for ENGINEERING

DEVELOPMENT OR EVALUATION PURPOSES ONLY and is not considered by TI to

befitforcommercialuse.Assuch,thegoodsbeingprovidedmaynotbecompleteinterms

of required design-, marketing-, and/or manufacturing-related protective considerations,

including product safety measures typically found in the end product incorporating the

goods. As a prototype, this product does not fall within the scope of the European Union

directive on electromagnetic compatibility and therefore may not meet the technical

requirements of the directive.

Should this evaluation kit not meet the specifications indicated in the EVM User’s Guide,

the kit may be returned within 30 days from the date of delivery for a full refund. THE

FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY SELLER TO

BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR

STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS

FOR ANY PARTICULAR PURPOSE.

Theuserassumesallresponsibilityandliabilityforproperandsafehandlingofthegoods.

Further, the user indemnifies TI from all claims arising from the handling or use of the

goods. Please be aware that the products received may not be regulatory compliant or

agency certified (FCC, UL, CE, etc.). Due to the open construction of the product, it is

the user’s responsibility to take any and all appropriate precautions with regard to

electrostatic discharge.

EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE, NEITHER

PARTY SHALL BE LIABLE TO THE OTHER FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

TIcurrentlydealswithavarietyofcustomersforproducts,andthereforeourarrangement

with the user is not exclusive.

TI assumes no liability for applications assistance, customer product design,

software performance, or infringement of patents or services described herein.

Pleasereadthe EVMUser’s Guideand,specifically, the EVMWarnings and Restrictions

notice in the EVM User’s Guide prior to handling the product. This notice contains

important safety information about temperatures and voltages. For further safety

concerns, please contact the TI application engineer.

Personshandlingtheproductmusthaveelectronicstrainingandobservegoodlaboratory

practice standards.

No license is granted under any patent right or other intellectual property right of TI

covering or relating to any machine, process, or combination in which such TI products

or services might be or are used.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

EVM WARNINGS AND RESTRICTIONS

It is important to operate this EVM within the input voltage range of 0 V to 5 V.

Exceeding the specified input range may cause unexpected operation and/or irreversible

damage to the EVM. If there are questions concerning the input range, please contact a TI

field representative prior to connecting the input power.

Applyingloadsoutsideofthespecifiedoutputrangemayresultinunintendedoperationand/or

possible permanent damage to the EVM. Please consult the EVM User’s Guide prior to

connecting any load to the EVM output. If there is uncertainty as to the load specification,

please contact a TI field representative.

Duringnormaloperation,somecircuitcomponentsmayhavecasetemperaturesgreaterthan

40°C.TheEVM isdesignedto operateproperlywith certain componentsabove 40°C aslong

astheinputandoutput rangesare maintained.Thesecomponentsincludebut arenot limited

tolinearregulators,switchingtransistors,passtransistors,andcurrentsenseresistors.These

typesof devicescanbeidentifiedusingtheEVM schematiclocated intheEVMUser’sGuide.

When placing measurement probes near these devices during operation, please be aware

that these devices may be very warm to the touch.

Mailing Address:

Texas Instruments

Post Office Box 655303

Dallas, Texas 75265

Information About Cautions and Warnings

Preface

Read This First

About This Manual

This user’s guide is to assist the user with the operation of the EVM using the

ADS5410 devices.

How to Use This Manual

This document contains the following chapters:

-Chapter 1—Overview

-Chapter 2—Physical Description

-Chapter 3—Circuit Description

Information About Cautions and Warnings

This book may contain cautions and warnings.

This is an example of a caution statement.

A caution statement describes a situation that could potentially

damage your software or equipment.

This is an example of a warning statement.

A warning statement describes a situation that could potentially

cause harm to you.

The information in a caution or a warning is provided for your protection.

Please read each caution and warning carefully.

Contents

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

testedforcompliancewiththelimitsofcomputingdevicespursuanttosubpart

Jofpart15ofFCCrules,which aredesignedtoprovidereasonableprotection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Contents

vii

Contents

1 Overview 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Purpose 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 EVM Basic Functions 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 ADS5410 EVM Operational Procedure 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Physical Description 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 PCB Layout 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Bill of Materials 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Circuit Description 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Circuit Function 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.1 Analog Inputs 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.2 Clock Inputs 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.3 Control Inputs 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.4 Power 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1.5 Outputs 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Schematic Diagram 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figures

2–1 Top Layer 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–2 Inner Layer 1, Ground Plane 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–3 Inner Layer 2, Power Plane 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–4 Bottom Layer 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents

viii

Tables

1–1 Two Pin Jumper List 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1–2 Three Pin Jumper List 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2–1 Bill of Materials 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3–1 Output Connector J15 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Notes, Cautions, and Warnings

Voltage Limits 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Overview

Thisuser’sguidegivesageneraloverviewoftheADS5410evaluationmodule

(EVM) and provides a general description of the features and functions to be

considered while using this module.

Topic Page

1.1 Purpose 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 EVM Basic Functions 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Power Requirements 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 ADS5410 EVM Operational Procedure 1-3. . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Purpose

1-2

1.1 Purpose

The ADS5410 EVM provides a platform for evaluating the ADS5410

analog-to-digital converter (ADC) under various signal, reference, and supply

conditions. Use this document in combination with the EVM schematic

diagram supplied.

1.2 EVM Basic Functions

Analog input to the ADC is provided via two external SMA connectors. The

single-ended input the user provides is converted into a differential signal at

the input of the device. One input uses a differential amplifier, while the other

input is transformer coupled.

TheEVMprovidesanexternalSMAconnectionforinputoftheADCclock.The

usercansendthisclocktotheoutputconnectorwiththedigitaldataorprovide

asecondclocksourcetobesentinplaceoftheADCclock.Thisallowstheuser

to provide the required setup and hold times of the output data with respect to

theoutputclock.Seethe Clock Inputssectionfortheproperconfigurationand

operation.

DigitaloutputfromtheEVMisviaa40-pinconnector.Thedigital linesfromthe

ADC are buffered before going to this connector. More information on this

connector can be found in the ADC output section.

PowerconnectionstotheEVMareviabananajacksockets.Separatesockets

are provided for the analog and digital supply.

1.3 Power Requirements

The EVM can be powered directly with only a 1.8-V and 3.3-V supply if using

themodulewithatransformer coupledinputandaninternalreferencesource.

A voltage of ±5 V is required if using the differential amplifier input. Provision

hasalsobeenmadetoallowtheEVMtobepoweredwithindependentanalog,

digital, and I/O supplies to provide higher performance.

Voltage Limits

Exceeding the maximum input voltages can damage EVM

components. Undervoltage may cause improper operation of

some or all of the EVM components.

Indice

Altri manuali Texas Instruments Convertitore multimediale

Texas Instruments

Texas Instruments SLVU013 Manuale utente

Texas Instruments

Texas Instruments LDC3114 Manuale utente

Texas Instruments

Texas Instruments TPS6103 Series Manuale utente

Texas Instruments

Texas Instruments TLC3578EVM FAMILY TLC3578EVM Manuale utente

Texas Instruments

Texas Instruments TPS548D21EVM-784 Manuale utente

Texas Instruments

Texas Instruments TVP5147M1PFP Manuale di installazione e d'uso

Texas Instruments

Texas Instruments TPS543C20EVM-054 Manuale utente

Texas Instruments

Texas Instruments ADS1230REF Manuale utente

Texas Instruments

Texas Instruments TPS6100 EVM Series Manuale utente

Texas Instruments

Texas Instruments TPS65917-Q1 Manuale del prodotto

Texas Instruments

Texas Instruments TPS6204xEVM Manuale utente

Texas Instruments

Texas Instruments TPS40051 Manuale utente

Texas Instruments

Texas Instruments LM5160 Manuale utente

Texas Instruments

Texas Instruments LM5181-Q1 Manuale utente

Texas Instruments

Texas Instruments TPS549B22EVM-847 Manuale utente

Texas Instruments

Texas Instruments PCM2704 Manuale utente

Texas Instruments

Texas Instruments UCC2977EVM Manuale utente

Texas Instruments

Texas Instruments TPS40003 Manuale utente

Texas Instruments

Texas Instruments DAC 300 Series Manuale utente

Texas Instruments

Texas Instruments ADS79 EVM-PDK Series Manuale utente

Texas Instruments

Texas Instruments EUROTEXT CF70200 Manuale utente

Texas Instruments

Texas Instruments UCC28782EVM-030 Manuale utente

Texas Instruments

Texas Instruments H.264 High Profile Encoder Manuale utente

Texas Instruments

Texas Instruments LP87524B-Q1 Manuale del prodotto

Manuali Convertitore multimediale popolari di altre marche

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuale utente

SPROLINK

SPROLINK VA1 Manuale utente

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuale utente

Nikon

Nikon AF-S TC-20E III Manuale utente

Axis

Axis AXIS Q7406 Manuale utente

Omega

Omega TAC80B-J Manuale utente

Zoom

Zoom Thunderbolt TAC-2R Manuale utente

OST

OST iConverter 10/100M Manuale utente

Vertiv

Vertiv Netsure Manuale utente

birddog

birddog MINI Manuale utente

Roland

Roland GI-10 Manuale utente

Wallenstein

Wallenstein WX310 Manuale utente

Pace

Pace MSS 200-1 Manuale utente

Solar Converters

Solar Converters EQ 12/24-50 Manuale utente

CYP

CYP EL-7400V Manuale utente

TIE

TIE MIDI 1i1o Manuale utente

DCS

DCS Vivaldi Upsampler Manuale utente

Westermo

Westermo MCW-211 SERIES Manuale utente
