How to Use This Manual

iii

Preface



About This Manual

This users guide describes the characteristics, operation, and use of the

TPS65100EVM-030 evaluation module (EVM). This EVM contains Texas

Instruments TPS65100 triple output LCD supply IC with linear regulator

controller and VCOM buffer. This users guide includes EVM specifications,

test results, schematic diagram, bill of materials (BOM), and recommended

test setup.

How to Use This Manual

This document contains the following chapters:

-Chapter 1 – Introduction

-Chapter 2 – EVM Operation

-Chapter 3 – Board Layout

-Chapter 4 – Bill of Materials and Schematic

Related Documentation From Texas Instruments

SLVS496 − TPS65100 data sheet

If you need Assistance

Contact your local TI sales representative.

FCC Warning

This equipment is intended for use in a laboratory test environment only. It

generates, uses, and can radiate radio frequency energy and has not been

tested for compliance with the limits of computing devices pursuant to subpart

J of part 15 of FCC rules, which are designed to provide reasonable protection

against radio frequency interference. Operation of this equipment in other

environments may cause interference with radio communications, in which

case the user at his own expense will be required to take whatever measures

may be required to correct this interference.

Trademark

Powermite is a registered trademark of Microsemi Corporation.

Contents



1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Background 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Performance Specification Summary 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Modifications 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 EVM Operation 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Input/Output Connect 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.1 J1−VIN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.2 J2−GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.3 J3−VOUT1 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.4 J4−GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.5 J5−VCOM 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.6 J6−GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.7 J7−VCOMIN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.8 J8−VOUT4 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.9 J9−GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.10 J10−VOUT2 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.11 J11−GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.12 J12−VOUT3 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.13 J13−GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.14 JP2−Enable (EN) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.15 JP3−Enable Regulator (ENR) 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.16 JP2 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Test Setup 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Test Results 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Board Layout 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Layout 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 Bill of Materials and Schematic 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 Bill of Materials for VIN = 3.3 V and VOUT1 = 10 V 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 Bill of Materials for VIN = 5 V and VOUT1 = 13.5 V 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2 Schematic 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents



2−1 TPS65100 VOUT1 Efficiency 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−2 TPS65100 Main Boost Converter Load Transient for VI= 3.3 V and VO= 10 V 2-4. . . . . . . .

2−3 TPS65100 Main Boost Converter Load Transient for VI= 5 V and VO= 13.5 V 2-4. . . . . . . .

3−1 Top Assembly Layer 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−2 Top Layer Routing 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−3 Bottom Layer Routing 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−1 TPS65100EVM Schematic 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .



1−1 Performance Specification Summary for VI= 3.3 V and VOUT1 = 10 V 1-2. . . . . . . . . .

1−2 Performance Specification Summary for VI= 5 V and VOUT1 = 13.5 V 1-3. . . . . . . . . . . . . . .

4−1 Bill of Materials for VIN = 3.3 V and VOUT1 = 10 V 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−2 Bill of Materials for VIN = 5 V and VOUT1 = 13.5 V 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1

Introduction



This chapter contains background information for the TPS65100EVM-030

evaluation module.

Topic Page

1.1 Background 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Performance Specification Summary 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Modifications 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Chapter 1

Background

1-2

1.1 Background

The TPS65100EVM uses a TPS65100 multichannel output IC to provide three

LCD power rails, as well as a linear regulator controller to provide 3.3 V and

a VCOM buffer. The goal of the EVM is to facilitate evaluation of the

TPS65100.

1.2 Performance Specification Summary

Table 1−1 provides a summary of the TPS65100EVM performance

specifications. All specifications are given for an ambient temperature of 25°C.

Table 1−1.Typical Performance Specification Summary for VIN = 3.3 V and VOUT1 = 10 V,

TA= 25°C

Specification

Voltage Range

(V) Current Range

(mA)

Specification

Min Typ Max Min Typ Max

VIN 2.7 3.3 4.0 3000

VOUT1 9.85 10 10.15 0 300

VOUT2 −5.10 −5 −4.90 0 20 (1)

VOUT3 22.5 23 23.5 0 20 (1)

VOUT4 N/A(2) N/A

VCOM 4.92 5 5.07 0 650 peak (1)

1) Maximum currents are determined by ambient conditions.

2) The linear regulator requires VIN ≥3.7 V for normal operation and should

be disabled using JP3.

1.3 Modifications

The primary goal of this EVM is to facilitate user evaluation of the TPS65100.

To facilitate user customization of the EVM, the board was designed with

devices having 603 or larger footprints. So, a real implementation would likely

occupy less total board space.

Changing components can improve or degrade EVM performance. For

example, using an inductor with larger dc resistance for the main boost

converter will lower efficiency of the solution. In addition, using a BJT with

lower Beta or in a smaller package will limit the total output current that the

linear regulator can provide.

The main boost converter requires external compensation components (R7,

C11) for stability. This EVM has been optimized for an input voltage of 3.3 V.

If a different input voltage and/or a different output voltage is to be applied, the

main boost converter needs to be re-compensated in order to be stable over

the entire load and temperature range (see Table 1−2 and Table 4−2).

Indice

Altri manuali Texas Instruments Scheda madre

Texas Instruments

Texas Instruments LMG342XEVM-04X Manuale utente

Texas Instruments

Texas Instruments TPS7B82EVM-024 Manuale utente

Texas Instruments

Texas Instruments BQ25303J Manuale utente

Texas Instruments

Texas Instruments DRV425EVM Manuale utente

Texas Instruments

Texas Instruments REF35EVM Manuale utente

Texas Instruments

Texas Instruments LMH2832EVM-50 Manuale utente

Texas Instruments

Texas Instruments TLC6C5816-Q1EVM Manuale utente

Texas Instruments

Texas Instruments TPS7H1101SPEVM Manuale utente

Texas Instruments

Texas Instruments bq24750A Manuale utente

Texas Instruments

Texas Instruments BQ25790EVM Manuale utente

Texas Instruments

Texas Instruments DAC8554EVM Manuale utente

Texas Instruments

Texas Instruments LM2796 Manuale utente

Texas Instruments

Texas Instruments TPS7B4255EVM-062 Manuale utente

Texas Instruments

Texas Instruments DAC5686 EVM Manuale utente

Texas Instruments

Texas Instruments AN-1622 LM49100 Manuale utente

Texas Instruments

Texas Instruments LMT01EVM Manuale utente

Texas Instruments

Texas Instruments BOOSTXL-DRV8305EVM Manuale utente

Texas Instruments

Texas Instruments OMAP35x Manuale utente

Texas Instruments

Texas Instruments ADS1232REF Manuale utente

Texas Instruments

Texas Instruments bq2083EVM-001 Manuale utente

Texas Instruments

Texas Instruments ISOTMP35 Manuale utente

Texas Instruments

Texas Instruments LMX248 Series Manuale utente

Texas Instruments

Texas Instruments LP8752 Q1 Series Manuale utente

Texas Instruments

Texas Instruments TPS61040EVM Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente
