TP-Link Auranet EAP110 Manuale utente

7106506406 REV1.0.0

Specifications are subject to change without notice. TP-LINK is a registered

trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product

names are trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any

means or used to make any derivative such as translation, transformation,

or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.

www.tp-link.com

›English

›Español

›Français

› Português

Ceiling Mount Access Point

Installation Guide

Guía de Instalación

Guide d'installation

Guia de Instalação

CONTENTS

English..................................................................................................1

Español.................................................................................................7

Français..............................................................................................13

Português ...........................................................................................19

English

Note: The image may differ from the actual product.

Network Topology

A typical network topology for the EAP is shown below.

EAP Controller

A DHCP server (typically a router) is required to assign IP addresses to the EAPs

and clients in your local network. A computer running the EAP Controller software,

which can be in the same or different subnet with the EAPs, is used to centrally

manage the EAPs.

You can get the EAP Controller software from our website http://www.tp-link.com.

Hardware Installation

■Option1：

Ceiling Rail Mounting

Follow the steps below to install the EAP with the provided accessories:

1Position the Ceiling T-rail Clip and push the

movable part toward the rail base.

Ceiling T-rail Clip M3×6 Pan-head Screws (Qty.5)

Controller

Host

Router Switch

Internet

Clients

EAP

English

2Use an M3×6 pan-head screw to secure the T-rail

Clip onto the ceiling rail.

3Attach the mounting bracket to the Ceiling T-rail

Clip using four M3x6 pan-head screws.

4Attach the EAP to the mounting bracket by

aligning ARROW 1 (on the EAP) with ARROW 2

(on the mounting bracket), then rotate the EAP

clockwise until it locks into place.

5Connect the Ethernet cable to the ETHERNET

port.

English

■Option2：

Ceiling Mounting

Follow the steps below to install the EAP with the provided accessories:

1Remove the ceiling tile.

2Place the mounting bracket in the center

of the ceiling tile. Mark the three positions

of the screw holes and a 10mm hole for

the Ethernet cable to feed through. Drill

three 4mm holes and a 10mm hole for the

Ethernet cable.

3Secure the mounting bracket to the ceiling

tile using three M3x30 pan-head screws,

washers and wing nuts.

Washers

(Qty.3)

M3×30 Pan-head Screws

(Qty.3)

Wing Nuts

(Qty.3)

Hole for Ethernet cable

English

4Attach the EAP to the mounting bracket by

aligning ARROW 1 (on the EAP) with ARROW

2 (on the mounting bracket), then rotate the

EAP clockwise until it locks into place.

5Feed the Ethernet cable through the hole and

set the ceiling tile back into place. Connect

the Ethernet cable to the ETHERNET port.

■Option3：

Wall Mounting

Follow the steps below to install the EAP with the provided accessories:

1Attach the EAP to the mounting bracket by

aligning ARROW 1 (on the EAP) with ARROW 2

(on the mounting bracket), then rotate the EAP

clockwise until it locks into place.

2Make two small pencil marks on the wall. Make

sure the two marks are level and should be

98.6mm apart. Drill two 6mm holes through

the center of your marks.

98.6mm

M3×28 Plastic Wall Anchors

(Qty.4)

M3×20 Self-tapping Screws

(Qty.4)

English

3Insert the plastic wall anchors into the 6mm

holes and drive the self-tapping screws into the

anchors. Do not drive the screws all the way in

and leave enough clearance to hang the EAP.

4Hang the EAP on the screws. Make sure the

EAP is firmly seated against the wall.

5Connect the Ethernet cable to the ETHERNET

port on the EAP.

English

Power Supply

■Power via PSE Device or Power Adapter

If the product is provided with a power adapter, power the device via a PSE device

(such as a PoE switch) or the power adapter.

Via PoE Switch

ON/OFF

Via Power Adapter

ON/OFF

■Power via POE Adapter

If the product is provided with a POE adapter, power the device via the POE

adapter.

PoE LAN

PoE Switch

PoE Adapter

(Up to 100m)

Switch

Español

Nota: La imagen puede diferir del producto actual.

Topología de la Red

Una Topología de la Red típica para el EAP se muestra a continuación.

EAP Controller

Se requiere un servidor DHCP (típicamente un router) para asignar las direcciones

IP a los EAPs y a los clientes en su red local. Una computadora que ejecute el

software del Controlador EAP, la cual puede estar la misma o en diferente subred

con los EAPs, se usa para manejar de manera central los EAPs.

Puede obtener el software del Controlador del EAP desde nuestro sitio web

http://www.tp-link.com.

Instalación del Equipo

■Opción 1: Montaje de la base en techo

Siga los pasos que se muestran a continuación para instalar el EAP con los

accesorios suministrados:

1Coloque la base en T para techo y empuje la

parte movible hacia la base del carril.

Sujeta la base T

para techo

Tornillos de cabeza plana M3×6

(Cantidad 5)

Host del

Controlador

Router Switch

Internet

Clientes

EAP

Español

2Use un tornillo de cabeza plana M3×6 para fijar

el sujeta-carril en T sobre el carril del techo.

3Fije el soporte de montaje al sujeta-carril en T

para techo usando cuatro tornillos de cabeza

plana M3x6.

4Fije el EAP al soporte de montaje alineando la

FLECHA 1 (en el EAP) con la FLECHA 2 (en el

soporte de montaje), después rotar el EAP en

sentido de las manecillas del reloj hasta que se

fije en su lugar.

5Conecte el cable de red al puerto ETHERNET.
