TPI 1008a Manuale utente
1008a
Rev. 3x Meters
Indoor Air Quality Meter
The Value LeaderTM
www. .com information@itm.com1.800.561.8187
Contents
1. Introduction
2. General Overview
3. Familiarization
3.1 Front View
3.2 Soft Keys
3.3 Back View
4. Operation
4.1 Turning On & Off / Performing a Test / Main Display
4.2 Selecting Temperature Units
4.3 Min / Max Mode
4.4 Activating the Backlight
4.5 Printing Test Results
4.6 Setting CO2 Alarm Level
4.7 Ambient Air CO2 Reset
5. Data Logging
6. Retrieving Logged Data
7. Technical Specifications
8. Maintenance
8.1 Battery Replacement
8.2 Service
9. Technical Information
10. Error Codes & Troubleshooting
www. .com information@itm.com1.800.561.8187
1. Introduction
Thank you for purchasing TPI brand products. The TPI 1008a Indoor
Air Quality (IAQ) Meter is a state of the art, easy to use tester designed
to provide you with the necessary measurements to monitor and make
adjustments to air handling devices. The instrument is ruggedly con-
structed and comes with a 3 Year unit and 2 Year sensor Guarantee.
2. General Overview
The 1008a IAQ meter uses state of the art sensors to measure carbon
dioxide (CO2), and temperature. The CO2 sensor in your meter will
need to be replaced periodically and calibration is recommended once
every year.
You should keep battery power applied to your sensors at all times.
The following guidelines will help prevent damage to your sensors:
Always store your unit in a place where the temperature does not get
down to or below freezing.
Always maintain battery power to the sensors. When the batteries get
low replace them as soon as possible.
Never allow foreign objects or material to enter the sensor holes, dam-
age to the sensor may result.
www. .com information@itm.com1.800.561.8187
General Overview (Continued)
This manual will guide you through the functions of the TPI 1008a
which will give you many years of reliable service.
Your TPI 1008a Indoor Air Quality meter comes complete with the
following standard accessories:
•TPI 1010 Instrument
•Protective Rubber Boot (A800)
•Soft Carrying Case (A921)
•USB Cable & Software (A803)
•Instruction Manual
Your TPI 1008a Indoor Air Quality meter has the following optional
accessories available:
•Power adapter / Battery eliminator (A804)
•Infrared Printer (A740)
•Magnetic strap kit to hang meter (A127)
•Boot hook to hang meter (A103)
•Replacement Software only (A802)
•Replacement USB cable only (A801)
( ) Denotes part number
A804 Battery Eliminator Specifications:
Input: 100 ~ 240VAC @ 47 ~ 63Hz
Output: 5VDC @ 2A
Center pin positive
Fitted with two pin European style plug. Comes with USA pin adapter.
www. .com information@itm.com1.800.561.8187
3. Familiarization
3.1 Front View
Sensor Locations: Places where the CO and Temperature sensors
are located and protected.
Display :Large 2 Parameter Backlit LCD Display.
Protective Rubber Boot Provides protection to meter housing and sen
sors.
Keypad Selects all available functions
USB Port Location for connection of USB cable for PC
communication.
Power Adapter Socket Location to connect power adapter.
Display
Keypad
CO2 &
Temperature
Sensor Location
USB Port Power Adapter
Socket
Protective
Rubber Boot
Infrared Window
for Printing Test
Results
(Requires optional A740
printer)
www. .com information@itm.com1.800.561.8187
3.2 Soft Keys
On / Off key - Used to turn the IAQ meter on or off. Press to turn
on, press and hold to turn off.
Up Arrow key - Used to select and change parameters.
Down Arrow key - Used to select and change parameters.
Mode key - Used to switch between Celsius and Fahrenheit units
of display and to enter CO2 alarm level input mode. Press to
switch between Celsius and Fahrenheit units. Press and hold to
enter and exit CO2 alarm level mode.
Backlight key - Used to turn the display backlight on and off.
Min / Max key - Used to activate and cycle through minimum,
maximum, and average display modes. Press to activate Min/Max
mode, press repeatedly to cycle through min, max, and avg dis-
plays. Press and hold to deactivate Min/Max mode.
Log key - Used activate and deactivate data logging.
RCL Key - Used to recall (display) logged data.
www. .com information@itm.com1.800.561.8187
3.3 Back View
Tilt Stand
Battery Cover Screw
Hanger Hole
Hanger Hole: Use to hang instrument for hands free operation. Can
be used with A127 magnetic strap kit or A103 hook.
Tilt Stand: Use to stand instrument on a table.
Batter Cover Loosen this screw and open cover to access batteries.
Screw:
www. .com information@itm.com1.800.561.8187
4. Operation
4.1 Turning On & Off / Performing a Test / Main Display
Enter the area to be tested, the measured values will be displayed.
Carbon dioxide (CO2) in parts per million (ppm) is displayed at the top and
Temperature in °F or °C (selectable)is displayed at the bottom of the main
display.
The battery indicator is located at the left center of the display. When the bat-
teries become low they must be replaced to maintain proper operation.
The 1008a has a CO2 alarm. If the CO2 level measured is at or above the
set alarm level the 1008a will beep and the display will flash red as a
warning. This alarm point is adjustable. Additional functions can be acti-
vated during testing. Please see next sections.
Carbon dioxide (CO2)
Temperature
Battery indicator
Press the key and the 1008a will begin a 30 second countdown. During
this time the 1008a performs a self diagnostic. Once the countdown ends the
1008a will display CO2 and Temperature.
To turn the 1008a off, press and hold the key down until the 1008a turns
off.
www. .com information@itm.com1.800.561.8187
4.2 Selecting Temperature Units
4.3 Min / Max Mode
4.4 Activating the Backlight
4.5 Printing Measurements (Requires A740 Printer)
Pressing the key activates Min/Max mode and “Max Min” will be displayed.
In this mode the 1008a will keep track of the minimum, maximum, and average
CO2 and Temperature being measured. When “Min Max” is displayed the 1008a
will display the real time reading.
Pressing the
key switches the temperature display between °F and °C.
To deactivate Min/Max mode and return to normal operation, Press and hold the
key until the 1008a beeps.
Pressing the key turns the display backlight on and off. Power
consumption is much higher when the backlight is activated. The backlight
will automatically turn off 30 seconds after it is activated. To conserve bat-
tery life the backlight should only be used when necessary.
Pressing the key will cause the 1008a to display “MAX”. This indicates the
Maximum CO2 and Temperature measured is displayed.
Press the key again and the 1008a will display “MIN”. This indicates the
Minimum CO2 and Temperature measured is displayed.
Press the key again and the 1008a will display “AVG”. This indicates the
Average CO2 and Temperature measured is displayed.
Pressing the key will cause the 1008a to display “MAX MIN”. This indicates
the real time reading is displayed and the Min/Max mode is still active. The steps
above can be repeated to cycle through the Min, Max, and Avg displays.
Align the infrared window of the A740 printer with the infrared window of
the 1008a located on the upper right side of the meter. Keep the printer in
clear line of sight approximately 6 to 8 inches away from the 1008a. Press
and hold the key for approximately 2 to 3 seconds and the 1008a will
send test data to the printer.
www. .com information@itm.com1.800.561.8187
The 1008a is equipped with an audible and visual alarm for carbon dioxide. The
alarm level is factory set to off. When CO2 above the alarm level is measured, the
1008a will beep and the display will flash red.
The alarm level is adjustable and can be set from 1100ppm to 5000ppm in
100ppm increments.
Using the Arrow keys set the alarm point to the desired level. The
keys adjust the alarm level from “Off” to 5000ppm in 100ppm increments.
Once the desired alarm point is set, press and hold the key to return to
normal operation.
1) With the 1008a turned on, press and hold down the
CO2 alarm level in ppm
4.6 Setting CO2 Alarm Level
key until the CO2
alarm screen is displayed.
4.7 Ambient Air CO2 Reset
The CO2 sensor can be reset at ambient level as needed. This can be performed if
the CO2 reading seems to be too high or low or just to ensure your 1008A is
operating properly. Note: This does not take the place of a full factory calibration
which is recommended once per year.
1. Take the 1008A outside in ambient air. Allow the CO2 reading to stabilize. Make
sure you are not breathing into the sensor area.
2. Press and hold the key until the 1008A beeps and the display resets to
400ppm CO2 (+/- 75ppm). IMPORTANT: DO NOT PERFORM THIS PROCEDURE
INDOORS. IF THIS HAPPENS BY ACCIDENT, PERFORM THE PROCEDURE AS
INSTRUCTED ABOVE TO RESET THE CO2 READING.
www. .com information@itm.com1.800.561.8187
