TRENDnet TV-H400 Manuale utente

TV-H400

H/W: V1.0R

Quick Installation Guide

Table of Contents

Version 07.10.2008

English ...................................................................................................... 1

1. Before You Start

2. Hardware Installation .........................................................................

................................................................................

Troubleshooting ........................................................................................ 9

English

1. Before you start

Installation Requirements

Package Contents

The following items below are not included. Users must provide the items

themselves. Make sure to have each item on hand before installation.

?Power Adapter (12V DC, 0.6A)

?1 x Ceiling Mounting Bracket

?Hexagon screwdriver (1/4” L=6mm)

?Screws and washers

?Rubber seal

TV-H400

Quick Installation Guide

?Mounting Screws

?Dry Wall or Wood surface

?Power Cord

?Wire Stripper

?Phillips Screwdriver

?Pliers

?RJ-45 cable

Pan and Tilt Internet Camera Server

2. Hardware Installation

English

Note: Configure your Internet Camera Server to match your network before

installing the device.

3. Run all necessary cables (CAT 5

cable, power adapter cable, and

the power terminals) through the

wall mount.

2. Unscrew the thumbscrew to

remove the protective plate from

the wall mount. Save this screw.

You will need to use this screw

later.

1. Rotate the TV-H400's cover

counter clockwise and remove the

cover.

English

6. Use the provided rubber seal to

seal the housing.

4. Run each cable through the

opening located at the top of the

TV-H400. DO NOT run all cables

through the opening

simultaneously. Serious blockage

can occur.

7. Slide the protective plating into the

wall mount and tighten the thumb

screw.

5. After inserting the appropriate

cables, extend each cable to 6

inches for camera installation.

English

8. Screw the ceiling or wall mount on

top of the TV-H400 with the

provided Allen wrench and three

hexagon socket screws. The

screws are in the plastic bag

labeled Q2 or Q2B.

10. Take the circular base and

connect the three Hex screws to

create this assembly. Then

secure the hex crews with the

nuts. The nuts are in the plastic

bag labeled Q5.

9. Combine the 5cm Hex screws with

the 1cm Hex screws. The 5cm

Hex screws are in the plastic bag

labeled Q3. The 1cm Hex screws

are in the plastic bag labeled Q4.

English

13. Connect the remaining two hex

crews to this bracket.

12. Mount this bracket on top of the

three Hex screws, Then using the

three round head screws to

secure the bracket. These screws

are in the plastic bag labeled Q6.

11. Mount the assembly in step 10 to

the camera enclosure using the

three flat head screws. These

screws are in the plastic bag

labeled Q1.

English

15. Take the assembly in step 14 and

mount the assembly on top of the

mounting bracket with two round

head screws. These screws are

in the plastic bag labeled Q6.

16. Connect the Ethernet cable and

power adapter to the Internet

Camera Server.

14. Attach the mounting plate for the

camera with 3 small screws.

These screws should come with

the Internet Camera Server.

English

19. Plug the power to the Internet

Camera Server and the camera

enclosure into an available power

outlet.

18. Connect the power terminal to the

provided 12V DC, 0.6A power

adapter.

Your installation is now complete.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

For detailed information regarding the TV-H400 configuration and advanced

settings, please visit TRENDnet's website at www.trendnet.com

17. Place the TV-H400's cover over

the camera and rotate the cover

clock-wise.

English

Mounting the Camera Enclosure

1. Place the mounting bracket against

the wall or ceiling and mark each

of the four holes with a pencil.

3. Insert screw anchors into the

holes.

Note: Mounting screws and screw anchors are not included.

2. Drill holes for the screws at each

marked position.

4. Align the wall or ceiling mount

bracket with the screws, and then

use nuts and washers to secure it.
