TRENDnet TE100-S16V Manuale utente

TRENDnet’s TE100-S16V 16-Port 10/100Mbps Smart Switch

is the ideal switch for network segmenting. It has an optional

fiber optic module that makes the switch flexible enough for

mid-sized companies and branch offices to meet their high

bandwidth requirements. By using standard auto-negotiation,

it provides a cost-effective way of integrating 10Mbps

segments with 100Mbps Fast Ethernet networks, and is ideal

for extending distances between two 100Mbps network

segments. Supporting Virtual Local Area Networking (VLAN),

it is powerful and easy-to-use in reducing unnecessary

broadcast traffic and enhance network security.

TE100-S16V

16-port 10/100Mbps Smart Switch

16 10/100Mbps Auto-negotiation, Auto-MDIX Fast Ethernet Ports

1 expansion slot for optional 100Base-FX fiber module

Full/Half-Duplex transfer mode for each port

Wire Speed reception and transmission

Store and Forward switching method

Supports 512K bytes RAM data buffering

Extensive diagnostic LED’s on the front panel

Broadcast storm protection

IEEE 802.3x flow control for half-duplex mode

Back pressure flow control for half-duplex mode

Supports Port-Based VLAN (17 groups) and Port-Based / IEEE 802.1p

QoS (high or low)

Integrated address Look-Up Engine with 4K entries MAC address table

Support Port setting function allow user setting each port

disable/enable, speed, duplex mode, and device flow control

Supports RS-232 Console port in front panel for configuration

Standard 19” Rack-mount design

5-Years Warranty

BENEFITSFEATURES

Easy Upgrade:

Expandability:

Flexibility:

Performance:

Cost-Effectiveness:

Ethernet workgroups are able to

upgrade to Fast Ethernet by changing

adapters and a hub without changing

switches.

Expand the connection up to 2Km with

optional fiber module (50/125 or

62.5/125um multimode fiber with SC

type connector).

Port-based VLAN reduces broadcast

traffic and enhance network security.

Provides non-blocking high performance

with internal switch controller.

The TE100-S16V presents 10/100Mbps

of Fast Ethernet at an affordable rate.

TE100-S16V (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE100-S16V

16-Port 10/100Mbps Smart Switch

TE100-S24V

24-Port 10/100Mbps Smart Switch

NETWORKING SOLUTIONS

SPECIFICATIONS

LAN Standards:

IEEE 802.3 10Base-T, IEEE 802.3u

100Base-TX, 100Base-FX

Network Media:

Ethernet: UTP/STP Cat. 3, 4, 5Fast

Ethernet: UTP/STP Cat. 5Fiber

Module: 50/125 or 62.5/125um

multimode fiber

Protocol:

CSMA/CD

Topology:

Star

LAN Port:

16 x 10/100Mbps Auto-MDIX ports,

1 expansion slot for 100Base-FX

fiber module

Address Table:

4K entries per device

•

Data Transfer Rate:

Ethernet: 10/20Mbps – Half/Full-Duplex

Fast Ethernet: 100/200Mbps –

Half/Full Duplex

Diagnostic LEDs:

Per Unit: Power, System,

Per Port:

TX: Link/Activity, Speed,

FX: Link/Activity. FDX

Power Consumption:

12 Watts. Max

Dimensions:

440 x 200 x 44 mm

(17.32 x 7.87 x 1.73 inches)

(W x H x D)

Temperature:

Operating: 0° ~ 40°C (32° ~ 104°F)

Storage: -10° ~ 70°C (14° ~ 158°F)

•

Humidity:

10% ~ 90% (no-condensing)

Emission:

FCC Class A, CE Mark A, VCCI-A

•

TE100-S16V

16-port 10/100Mbps Smart Switch

TE100-S16V

16-port 10/100Mbps Smart Switch

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
