TRENDnet TE100-S16D Manuale utente

TE100-S16D

rev: 22.06.2011

16-Port 10/100Mbps Switch

TE100-S16D(V1.0R)

The 16-Port 10/100Mbps Switch, model TE100-S16D, is a reliable

Plug-and-Play solution in a compact form factor. Boost network

efﬁ ciency with a total switching capacity of 3.2Gbps with Full-Duplex

mode.

Diagnostic LEDs on the front of the switch help with network

troubleshooting. IEEE 802.3x ﬂ ow control and 4K MAC address entry

support provide uninterrupted connectivity. This switch is well suited for

networking room, departmental group, and home ofﬁ ce applications.

FEATURES

• 16 x 10/100Mbps Auto-Negotiation, Auto-MDIX Ethernet ports

• Compliant with IEEE 802.3/IEEE 802.3u standards

• 3.2Gbps switching fabric

• Store-and-Forward switching architecture with non-blocking wire-speed performance

• IEEE 802.3x Flow Control support

• Provides 4k MAC address entries

• 1.25Mbits RAM data buffer

• Diagnostic LEDs

• Compact housing

• Plug & Play installation

• 3 year limited warranty

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,

16-Port 10/100Mbps Switch

TE100-S16D (V1.0R)

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TE100-S16D

Multi-Language Quick Installation Guide

Power adapter (5V DC, 2A)

RELATED PRODUCTS

TE100-S16g 16-Port 10/100Mbps GREENnet Switch

TE100-S24g 24-Port 10/100Mbps GREENnet Switch

TEG-S50g 5-Port Gigabit GREENnet Switch

SPECIFICATIONS

HARDWARE

Standards • IEEE 802.3 10Base-T

• IEEE 802.3u 100Base-TX

• IEEE 802.3x Flow Control

Network Media • Ethernet: UTP/STP Cat. 5 up to 100 m

• Fast Ethernet: UTP/STP Cat. 5, 5e, 6, up to 100 m

Data Rate • Ethernet: 10Mbps/20Mbps (half/full-duplex)

• Fast Ethernet: 100Mbps/200Mbps (half/full-duplex)

Protocol / Topology • CSMA /CD, Star

Power Consumption • 4.8 Watts (max.)

Switch Fabric • 3.2Gbps forwarding capacity

Interface • 16 x 10/100Mbps Auto-MDIX RJ-45 ports

RAM Data Buffer • 1.25Mbits

Filtering Table • 4K entries

Diagnostic LED • Power, Link/ACT

Power • 5V DC, 2A external power adapter

Dimension • 265 x 122.7 x 41 mm (10.4 x 4.8 x 1.6 in.)

Weight • 410 g (14.4 oz)

Temperature • Operating: 0° ~ 40° C (32° ~ 104° F); Storage: -10° ~ 70° C (14° ~ 158° F)

Humidity • Max. 90% (non-condensing)

Certiﬁ cations • CE, FCC
