TRENDnet TEG-S80TX Manuale utente

TEG-S80TX

8-Port 10/100/1000Mbps

Copper Gigabit Ethernet Switch

User’s Guide

FCC Warning

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with this user’s guide,

may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this

product may cause radio interference in which case the user

may be required to take adequate measures.

VCCI Warning

P/N:6012-8000T01

Rev.A1-01

TABLE OF CONTENTS

ABOUT THIS GUIDE...........................................................................1

TERMS................................................................................................1

OVERVIEW OF THIS USER’S GUIDE........................................................1

INTRODUCTION.................................................................................3

GIGABIT ETHERNET TECHNOLOGY......................................................3

SWITCHING TECHNOLOGY ..................................................................4

FEATURES...........................................................................................5

UNPACKING AND SETUP..................................................................7

UNPACKING........................................................................................7

SETUP .................................................................................................7

DESKTOP OR SHELF INSTALLATION .....................................................8

RACK INSTALLATION ..........................................................................9

IDENTIFYING EXTERNAL COMPONENTS .....................................11

FRONT PANEL...................................................................................11

REAR PANEL.....................................................................................12

LED INDICATORS..............................................................................12

TECHNICAL SPECIFICATIONS......................................................15

ABOUT THIS GUIDE

This user’s guide tells you how to install your 8-Port

10/100/1000Mbps Gigabit Ethernet Switch and how to connect

it to your Ethernet network.

Terms

For simplicity, this documentation uses the terms “Switch” (first

letter upper case) to refer to the 8-Port 10/100/1000Mbps Gigabit

Ethernet Switch, and “switch” (first letter lower case) to refer to

all Ethernet switches, including the 8-Port 10/100/1000Mbps

Gigabit Ethernet Switch.

Overview of this User’s Guide

? ?Introduction. Describes the Switch and its features.

? ?Unpacking and Setup. Helps you get started with the basic

installation.

? ?Identifying External Components. Describes the front

panel, rear panel, and LED indicators.

? ?Technical Specifications. Lists the technical specifications.

INTRODUCTION

This section describes the features of the 8-Port

10/100/1000Mbps Gigabit Ethernet Switch, as well as giving

some background information about Gigabit Ethernet and

switching technology.

Gigabit Ethernet Technology

Gigabit Ethernet is an extension of IEEE 802.3 Ethernet, utilizing

the same packet structure, format, and support for CSMA/CD

protocol, full duplex, flow control, and management objects, but

with a tenfold increasein theoretical throughput over 100-Mbps

Fast Ethernet and a hundredfold increase over 10-Mbps

Ethernet. Since it is compatible with 10-Mbps and 100-Mbps

Ethernet environments, Gigabit Ethernet provides a

straightforward upgrade without wasting a company’s existing

investment in hardware, software, and trained personnel.

The increased speed and extra bandwidth offered by Gigabit

Ethernet is essential when coping with the network bottlenecks

that frequently develop as computers and their busses get

faster and more users use applications that generate more

traffic. Upgrading key components, such as your backbone and

servers to Gigabit Ethernet can greatly improve network

response times as well as significantly speed up the traffic

between your subnets.

Since the Gigabit Ethernet data transfer rate is 10 times faster

than Fast Ethernet, servers equipped with Gigabit Ethernet

NIC’s are able to perform 10 times the number of operations in

the same amount of time. This makes Gigabit Ethernet the

perfect solution for video conferencing, complex imaging, and

similar data-intensive applications.

Switching Technology

Another key development pushing the limits of Ethernet

technology is in the field of switching technology. A switch

bridges Ethernet packets at the MAC address level of the

Ethernet protocol, transmitting among connected Ethernet or

Fast Ethernet LAN segments.

Switching is a cost-effective way of increasing the total network

capacity available to users on a local area network. A switch

increases capacity and decreases network loading by dividing

network into different segments and each segment has its own

bandwidth (10, 100, or 1000Mbps).

The switch acts as a high-speed selective bridge between the

individual segments. Traffic that needs to go from one segment

to another is automatically forwarded by the switch (without

interfering with any other segments). This allows the total

network capacity to be multiplied, while maintaining the same

network cabling and adapter cards.
