TRENDnet TFU-430 Manuale elenco delle parti

TFU-430

Quick Installation Guide

Table of Contents

Version 04.11.2007

Español .....................................................................................................

Troubleshooting ........................................................................................

1. Antes de iniciar ..................................................................................

2. Instalación del Hardware ....................................................................

Aplicación

Requisitos del sistema

Español

1. Antes de iniciar

Contenidos del paquete

Vista)

?M : 256MB RAM o superior(XP/2000)/ 512MB RAM o superior

(Windows Vista)

?Puertos USB: 1.1 ó 2.0

?Windows Vista/XP/2000/ME/98SE, Mac 8.6 y superior

?Puerto FireWire IEEE 1394 en su PC

CPU: 300MHz o superior (XP/2000)/ 800MHz o superior (Windows

emoria

?TFU-430

?Cable USB 2.0 de tipo A a tipo B

(12V DC, 1A)

?Cable de alimentación

?Cable FireWire IEEE 1394

Adaptador para corriente AC

Guía de instalación rápida

7-Port USB 2.0/FireWire Combo Hub

(TFU-430)

PC/MAC

Systems

USB Keyboard

FireWire

Digital

Camera

FireWire

Hard Drive

USB

Mouse

USB Printer

USB 2.0 (480Mbps) FireWire(400Mbps)

USB 1.1 (12Mbps)

* Backwards compatible

with USB 1.1 at 12Mbps

2. Instalación del Hardware

Dado que el TFU-430 es hot-pluggable, podrá conectarlo y desconectarlo

mientras el computador está encendido. Además, TFU-430 se alimenta de

corriente por bus y por tanto no requiere de un adaptador de energía AC. No

obstante, si usted utiliza periféricos externos USB o FireWire de alta velocidad,

es recomendable emplear adaptador para corriente externa AC incluido en el

paquete.

1. Encienda su PC y espere

hasta que se inicie por completo.

4. Conecte el extremo tipo B del

cable USB suministrado al puerto

UP.

5. Conecte el cable FireWire IEEE

1394 anexado al TFU-430.

2. Conecte el cable de alimentación

al adaptador de alimentación AC.

3. Conecte el adaptador de

alimentación AC al Hub USB.

Español

Registre su producto

Para asegurar los más altos niveles de servicio y apoyo al cliente, registre su producto

en línea en: www.TRENDnet.com/register

Gracias por elegir TRENDnet

8. Conecte el USB y los dispositivos

FireWire a los puertos restantes.

Nota:

1. U1, U2, U3 y U4 son puertos USB descendentes. No conecte el cable USB

de su PC a los puertos USB descendentes.

2. Uno de los puertos Firewire IEEE 1394 debe estar conectado a su PC como

puerto ascendente. Cualquier puerto Firewire IEEE 1394 puede actuar

como puerto ascendente.

7. Conecte el otro extremo del cable

Firewire incluido a su PC.

6. Conecte el otro extremo del cable

USB (tipo A) incluido a su PC.

La instalación ha sido completada

Español

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

Where is the Driver CD-Rom for the TFU-430?

Can I connect or disconnect the USB cable while the computer is on?

Yes, you can connect or disconnect the USB cable, or any external USB

device while the computer is on because the USB interface is Plug-and-Play and

hot-pluggable.

The TFU-430 does not require unique drivers; it uses generic USB and

preinstalled FireWire drivers provided by your operating system. You must have

properly installed USB and/or FireWire ports on your computer.

My computer does not detect my FireWire device. What should I do?

First, make sure you have connected the included FireWire cable from F1, F2,

or F3 port on the TFU-430 to the FireWire port on your computer. Please see

section 3 for more information. Second, your computer must have the FireWire

Host Controller installed properly for you computer's FireWire port to work. For

more information regarding FireWire Host Controller installation, please refer to

you computer's User Manual.

My computer does not detect my USB device. What should I do?

First, make sure you have connected the included USB cable from the UP port

on the TFU-430 to the USB port on your computer. Please see section 3 for more

information. Second, check that your computer's BIOS settings have USB

enabled. For more information regarding BIOS settings, please refer to your

computer's User Manual.

Can I daisy chain the TFU-430?

Yes you can. The TFU-430 can connect up to 127 USB and IEEE 1394

FireWire ports by daisy chaining TFU-430 USB hubs.

If you still encounter problems or have any questions regarding the TFU-430, please

contact TRENDnet's Technical Support Department.

Troubleshooting

Limited Warranty

TRENDnet warrants its products against defects in material and

workmanship, under normal use and service, for the following lengths of

time from the date of purchase.

TFU-430 - 2-Year Warranty

If a product does not operate as warranted above during the applicable

warranty period, TRENDnet shall, at its option and expense, repair the

defective product or part, deliver to customer an equivalent product or

part to replace the defective item, or refund to customer the purchase

price paid for the defective product. All products that are replaced will

become the property of TRENDnet. Replacement products may be new

or reconditioned.

TRENDnet shall not be responsible for any software, firmware,

information, or memory data of customer contained in, stored on, or

integrated with any products returned to TRENDnet pursuant to any

warranty.

There are no user serviceable parts inside the product. Do not remove

or attempt to service the product by any unauthorized service center.

This warranty is voided if (i) the product has been modified or repaired

by any unauthorized service center, (ii) the product was subject to

accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within

the applicable warranty period for a Return Material Authorization (RMA)

number, accompanied by a copy of the dated proof of the purchase.

Products returned to TRENDnet must be pre-authorized by TRENDnet

with RMA number marked on the outside of the package, and sent

prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDnet PRODUCT DOES NOT

OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE

REMEDY SHALL BE, AT TRENDnet'S OPTION, REPAIR OR

REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES

ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,

EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF

LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

TRENDnet NEITHER ASSUMES NOR AUTHORIZES ANY OTHER

PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN

CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR

USE OF TRENDnet'S PRODUCTS.

TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS

TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED

DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY

CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED

ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE

BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT,

FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW

TRENDnet ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY

LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING

NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,

SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF

REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT

OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION

OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY

TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE

PAID, AT TRENDnet’S OPTION. THIS DISCLAIMER OF LIABILITY FOR

DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED

HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of

the state of California.

AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry 1

Year Warranty

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may cause undesired

operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE

CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS

COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de

alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador

de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria

existente en el pais o zona de instalación.

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDnet’s website at http://www.trendnet.com

TRENDnet Technical Support

US Canada

24/7 Tech Support

Toll Free Telephone: 1(866) 845-3673

Europe (Germany France Italy Spain Switzerland UK)

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

Worldwide

Telephone: +(31) (0) 20 504 05 35

Toll Free Telephone: +00800 60 76 76 67

. . . . .

20675 Manhattan Place

Torrance, CA 90501

USA
