TRENDnet TEW-805UB Manuale utente
TEW-805UB
rev: 02.22.2013
AC1200 Dual Band Wireless USB Adapter
TEW-805UB (v1.0R)
TRENDnet’s AC1200 Dual Band Wireless USB Adapter, model
TEW-805UB, connects a laptop or desktop computer to a revolutionary
Wireless AC network. Connect to a Wireless AC network at an amazing
867 Mbps or to a Wireless N network at up to 300 Mbps. A SuperSpeed
5 Gbps USB 3.0 port maintains a high speed connection to your
computer.
Quickly connect to a Wireless AC or N network at the touch of a button
with the convenience of one-touch Wi-Fi Protected Setup (WPS).
An LED on the front of the adapter conveys device status. Upgrade
your computer’s wireless connection to experience the speed of
revolutionary Wireless AC.
PRODUCT OVERVIEW
• Upgrade your computer to revolutionary 867 Mbps Wireless AC
• Connect to a Wireless N network at up to 300 Mbps
• 5 Gbps USB 3.0 connection to computer
• Powered by the computer’s USB port
• One-touch connection to router with Wi-Fi Protected Setup (WPS)
Wireless AC: Next generation Wireless AC
Dual Band: Up to 867 Mbps Wireless AC or 300 Mbps Wireless N
Compatible: Connects to standard Wireless N networks
USB 3.0: SuperSpeed 5 Gbps USB 3.0 connection to computer
Coverage: Expanded coverage with MIMO technology
One Touch Connection: Connect to a router at the touch of the Wi-Fi Protected Setup (WPS) button
FEATURES
• Wi-Fi compliant with IEEE 802.11ac and 802.11n standards
• High-speed data rates up to 867 Mbps with 802.11ac technology and 300 Mbps with 802.11n technology
• USB 3.0 connector
• LED indicator
• Backwards compatible with IEEE 802.11g, IEEE 802.11b, and IEEE 802.11a networks
• Compatible with Windows 8 (32/64-bit), 7 (32/64-bit), Vista (32/64-bit), and XP(32/64-bit) operating systems
• One-touch network connection with Wi-Fi Protected Setup (WPS) button
• Dynamic Data Rate Scaling from 867 Mbps to 1 Mbps
• Supports advanced wireless encryption up to WPA2-RADIUS
• Easy user setup and diagnostic utilities
• Coverage of up to 100 meters indoor (330 feet) and 300 meters outdoor (980 feet)*
• 3-year limited warranty
* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifi cations. Actual data throughput and coverage
will vary depending on interference, network traffi c, building materials and other conditions.
TEW-805UB
rev: 02.22.2013
AC1200 Dual Band Wireless USB Adapter
TEW-805UB (v1.0R)
SPECIFICATIONS
HARDWARE
Interface • USB 3.0, 2.0, 1.1 standard
Standards • IEEE 802.11a, IEEE 802.11ac (draft), IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n
WPS Button • Enables WPS connection
Power Consumption • Receive mode: 167 mA (max.)
• Transmit mode: 224 mA (max)
Supported OS • Windows 8 (32/64-bit), 7 (32/64-bit), Vista (32/64-bit), Windows XP (32/64-bit)
Dimensions (L x W x H) • 80 x 27 x 12 mm (3.1 x 1 x 0.5 in.)
Weight • 20 g (0.7 oz)
Temperature • Operating: 0° ~ 40° C (32° ~ 104° F)
• Storage: -10° ~ 70° C (14° ~ 158° F)
Humidity • Max 95% (non-condensing)
Certifi cations • CE, FCC
WIRELESS
Modulation • DBPSK / DQPSK / CCK / OFDM (BPSK / QPSK / 16-QAM / 64-QAM / 128-QAM / 256-QAM)
Antenna • 2 internal antennas
Frequency • 802.11b/g/n: 2.412 ~ 2.472 GHz
• 802.11a/n/ac: 5.150 GHz ~ 5.350 GHz / 5.725 GHz ~ 5.825 GHz (FCC), 5.150 GHz ~5.350 GHz / 5.470 GHz ~ 5.725 GHz (ETSI)
Media Access Protocol • CSMA/CA with ACK
Data Rate (auto fallback) • 802.11a: up to 54 Mbps
• 802.11b: up to 11 Mbps
• 802.11g: up to 54 Mbps
• 802.11n: up to 300 Mbps (for both 2.4 & 5 GHz)
• 802.11ac: up to 867 Mbps
Output Power • 802.11b: 15 dBm (typical)
• 802.11g: 15 dBm (typical)
• 802.11n: 15 dBm (typical) (for both 2.4 & 5 GHz)
• 802.11a: 15 dBm (typical)
• 802.11ac: 12 dBm (typical)
Receiving Sensitivity • 802.11b: -76 dBm (typical)
• 802.11g: -65 dBm (typical)
• 802.11n: -61 dBm (typical)
• 802.11a: -65 dBm (typical)
• 802.11ac: -51 dBm (typical)
Encryption • 64/128-bit WEP, WPA / WPA2-RADIUS, WPA / WPA2-PSK (AES/TKIP)
Channels • 2.4 GHz: 1~11 (FCC), 1~13 (ETSI)
• 5 GHz: 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 (FCC) 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120,
124, 128, 132, 136, 140 (ETSI)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TEW-805UB
CD-ROM (Utility & Driver)
Multi-Language Quick Installation Guide
RELATED PRODUCTS
TEW-812DRU AC1750 Dual Band Wireless Router
TEW-684UB N900 Dual Band Wireless USB Adapter
TEW-692GR N900 Dual Band Wireless Router
NETWORKING SOLUTIONS
AC1200 Dual Band Wireless USB Adapter
TEW-805UB (v1.0R)
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time, without
notice. For the most recent product information please visit http://www.trendnet.com Copyright ©TRENDnet.All Rights Reserved.
