NETWORK SETUP
Network connection
Set IP_ADDRESS in MC6N to an available unused address.
It MUST match the subnet in use. Set the PC to use
DHCP server.
Note: the MC6N always has a xed IP address.
Point-to-point or closed network
(No DHCP server)
The PC MUST be set to a xed IP_ADDRESS.
The rst 3 “octets” MUST be the same as the MC6N and
the last MUST be dierent, but not 000, 254 or 255.
Setting a xed IP address
In Windows 7. Open “Network and Sharing Centre” then change “Adapter
Settings”. Select the properties of the Local Area Network and the IPv4
properties. The IP Address is set to 192.168.0.100 with subnet mask set to
255.255.255.0. Assuming that the MC6N has IP_ADDRESS=192.168.0.250 or
similar.
SwitchPC Laptop MC6N
DCHP Server
Example : 192.168.0.100 Example : 192.168.0.250
PC Laptop MC6N
Example : 192.168.0.100 Example : 192.168.0.250
