Specifications
PowerAlert Console Launcher
1.9kW Single-Phase Switched PDU, 120V Outlets
(24 5-15/20R), L5-20P/5-20P, 10ft Cord, 0U
Vertical, TAA
MODEL NUMBER: PDUMV20NET
Description
Tripp Lite single phase Switched PDU / Power Distribution Unit offers advanced network control and
monitoring with the ability to turn on, turn off, recycle or lock-out power to each individual receptacle,
monitor site electrical conditions and remotely monitor output power consumption. PowerAlert interface
supports remote control and custom notification of user-specified conditions via email, PowerAlert
Console Launcher, SNMP, Telnet or SSH interface. Individually switched outlets can be controlled in real-
time to remotely reboot unresponsive network hardware, or be custom programmed for user-defined
power-up and power-down sequences to ensure proper startup of interdependent IT systems and prevent
inrush-related overloads as network equipment is first energized. Unused PDU outlets can be
electronically locked off to prevent the connection of unauthorized hardware. PDU output current
consumption in amps is continuously displayed locally via visual meter and remotely via network interface
to warn of potential overloads before critical IT mains or branch breakers trip.
Features
Highlights
Switched 20A 120V PDU, 0U 70
in. / 178cm Vertical Rackmount
Format
●
Reports voltage, frequency &
load level via ethernet interface
●
Visual current meter, Toolless
button mount installation
●
NEMA L5-20P input with 5-20P
adapter, attached 10 ft. / 3m
cord
●
24 switched NEMA 5-15/20R
outlets with cord retention
brackets
●
Temperature, humidity and
contact closure monitoring
options
●
Federal Trade Agreements Act /
TAA Compliant for GSA
Schedule purchases
●
Package Includes
Rackmount PDU
●
L5-20R to 5-15/20P adapter
●
Rackmount brackets
●
PDUMVROTATEBRKT
●
OVERVIEW
UPC Code 037332139719
PDU Type Switched
1 / 3
INPUT
Recommended Electrical Service 20A 120V
Maximum Input Amps 20
Maximum Input Amps Details Agency de-rated to 16A continuous
PDU Plug Type NEMA 5-20P; NEMA L5-20P
Input Phase Single-Phase
Input Cord Length (ft.) 10
Input Cord Length (m) 3.05
OUTPUT
Output Capacity Details 2.03kW (127V), 1.92kW (120V), 1.6kW (100V) / 20A total capacity (Agency de-rated to 16A); 16A max per outlet
Frequency Compatibility 50 / 60 Hz
Output Receptacles (24) 5-15/20R
Output Nominal Voltage 100; 120; 127
Customized Load Management
Receptacles Each outlet is individually controllable via remote interface
USER INTERFACE, ALERTS & CONTROLS
Front Panel LCD Display Digital meter reports PDU output current in amps
Front Panel LEDs 24 power availability LEDs confirm power off/on status for each built-in outlet
Switches Recessed reset switch for interface reboot and factory reset
SURGE / NOISE SUPPRESSION
Automatic Shut-Off No
PHYSICAL
Form Factors Supported 0U vertical rackmount; includes rackmount brackets. Supports toolless mounting in button-mount compatible racks
PDU Form Factor Vertical (0U)
Shipping Dimensions (hwd / cm) 10.16 x 15.24 x 184.15
Shipping Dimensions (hwd / in.) 4.00 x 6.00 x 72.50
Shipping Weight (kg) 7.03
Shipping Weight (lbs.) 15.50
Unit Dimensions (hwd / in.) 70 x 2.19 x 2.65
Unit Dimensions (hwd / cm) 178 x 5.6 x 6.7
Unit Weight (lbs.) 10
Unit Weight (kg) 4.54
2 / 3
© 2022 Tripp Lite. All rights reserved. All product and company names are trademarks or registered trademarks of their respective holders. Use of them does
not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:
https://www.tripplite.com/products/product-certification-agencies
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
Operating Elevation (ft.) 0-10,000
Operating Elevation (m) 0-3000
COMMUNICATIONS
PowerAlert Software SNMPWEBCARD Interface: PowerAlert 12
Communications Cable RJ45-to-DB9 configuration/console Access cable
SNMP Compatibility Pre-installed <a class="productLink" href="//www.tripplite.com/SNMP-Web-Management-Accessory-Card-
SmartPro-SmartOnline-UPS-Systems~SNMPWEBCARD">SNMPWEBCARD</a> provides remote
monitoring via PowerAlert Console Launcher, Telnet, SSH, and SNMP management systems. Remote management
enables outlets to be turned on and off individually
Network Compatibility 10 Mbps; 100 Mbps (Fast Ethernet)
STANDARDS & COMPLIANCE
Certifications Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico), RoHS compliant, TAA Compliant
Certification Details Series Number(s) AG-0009
WARRANTY
Product Warranty Period
(Worldwide) 2-year limited warranty
3 / 3
