Panel meter with totalized function

Pulse input

471B

Quick Manual

Contents

Introduction ·····················································1

About this booklet ·········································································1

Precautions ··················································································1

Installation Precautions ··································································2

Nomenclature···················································3

Operation Panel ············································································3

Rear Panel····················································································5

Installation·······················································6

Installation Conditions····································································6

Accessories···················································································6

Mounting Method ··········································································7

Dismounting·················································································8

Wiring Method ············································································9

Terminal layout and explanation ···················································· 11

Usage of Function Code···································16

Function code list ········································································ 16

Setting method of code No. ·························································· 17

Function setting method······························································· 18

Specification···················································22

Optional output ··············································24

PhotoMOS compare output ··························································· 24

Analog output············································································· 26

BCD output (Digital output) ·························································· 28

Introduction

About this booklet

Thank you for purchasing our digital panel meter 471B. Before use of the product, read this

quick manual carefully and thoroughly, and keep it available for routine reference.

The following symbol marks are used in this quick manual for the safety use of the product.

!Warning

This is the warning to avoid danger. Severe injure or fatal accident

may occur to the user in case the product is mishandled.

!Caution

This is the caution to avoid danger. Minor injury to the user or

physical obstacle may occur in case the product is mishandled.

Precautions

For the safe use of this product, users must follow the following warning and caution.

!Warning

There is no power on-off switch on the model 471B. It immediately starts

to operate after turning the power ON.

Never touch the terminals when power is ON. There may be risk of

electric shock.

!Caution

The rated data for warm up is specified for more than 15 minutes.

When the front panel or the case becomes dirty, wipe it with soft cloth. If

the dirt is difficult to remove, wipe it lightly with the soft moist cloth with

mild detergent diluted with water and finish by wiping with a dry cloth.

Do not use organic solvent like benzene or paint thinner as they may

deform or discolor the surface of the case.

Introduction（contd.）

Installation Precautions

For the safe use of this product, users must follow the following caution.

!Caution

If the product is installed inside the cabinet, provision for the proper heat

dissipation should be done to prevent the temperature to exceed more

than 50 ℃inside the cabinet.

Do not mount the product in quite near distance. The rise of temperature

may decrease the life of the product.

Do not use the products in the following places. It may be the cause of

damage or malfunction.

∗Wet place (rain, water drops), direct sunlight

∗Place having high temperature, humidity, dust and corrosive gases

∗Place having excessive noise, waves, static electricity

∗Place having lots of vibration and shock

Store the product in the specified temperature range between -20℃to

65℃

Nomenclature

Operation Panel

No.

Name

Function

①

Display 1

Instantaneous or totalized value display

Red or green can be select for display color

②

Display 1 Over

Light on when instantaneous value display 1 exceeds 999999.

Light on when totalized value display 1 exceeds 999999.

③

TOTAL

Light on with red color during display 1 is totalized value

④

Display 2

Instantaneous or totalized value display in while color

⑤

INST

Light on with red color during display 1 is instantaneous value

⑥

Display1 Unit

Pasting position of instantaneous and totalization unit seal

⑦

Display2 Unit

Pasting position of instantaneous and totalization unit seal

⑧

Comparative

display

The comparison status of the comparison output is displayed.

⑨

SET Display

Light on during setting mode

OVER SETAL1 AL2 AL3 AL4

RESET

ENTER

MODE

INST

TOTAL

ｋＷｈ

ｋＷ

①Display 1

②Display 1 Over

③TOTAL

④Display 2

⑤INST

⑧Comparative display

(AL1～AL4)

⑨SET Display

⑩Setting key

⑪Reset key

⑥Display1 Unit

⑦Display2 Unit

Nomenclature（contd.）

No.

Name

Function

⑩

Setting key

MODE

During measurement mode：Change to Setting

mode、Adjustment mode

During setting mode：Change to each code No.

▼

During measurement mode：Invalid

During setting mode：Digit selection of setting value

▲

During measurement mode：Invalid（Except when

switching to diagnostic mode）

During setting mode：Change of setting value

ENTER

During measurement mode：Invalid

During setting mode：Set value changed to saved

measurement mode

⑪

Reset key

RESET

During measurement mode：

Display shows “０”.（If the Reset totalizing

function is set, set the totalized to initial

value）

During setting mode：

Setting mode changes to measurement

mode without saving the set value.

LED Display

マイナス

Rear Panel

No.

Name

Function

⑫

Terminal A1～A6

Sensor power supply, Input、P.O output terminal

⑬

BCD OUTPUT

CONNECTOR

Open collector NPN transistor output

Terminal RS-232C

B1～5:RS-232C communication, B6: Vacant terminal

Terminal RS-485

B1:+, B2:-, B4～5: Terminating resistance,

B3, B6:Vacant terminal

⑭

Terminal C1～C6

C1～3:Control input terminal, C4:Vacant terminal、

C5～6:Analog output terminal

⑮

Terminal D1～D6

D1～6:Compare output terminals of AL1 to AL4

⑯

Terminal E1～E6

E1,E3:Power supply terminal, E5:Ground terminal

E2,E4,E6:Vacant terminal

※The specification of ⑬, C5 to C6 of ⑭and ⑮are option.

A B C D E

12 13 14 15 16

Installation

Installation Conditions

Power supply

AC100 to 240V 50/60Hz、DC24V、DC110V

Voltage tolerance of

power supply

AC90 to 250V、DC24V±10%、DC100 to 170V

Power consumption

During AC100V: Approx. 11VA、During AC200V: Approx. 15VA

During DC24V: Approx. 250mA、During DC110V: Approx. 50mA

Operating ambient

temperature

0 to 50℃, 40 to 85%RH（No condensation）

Storage temperature

－20 to 65℃（No condensation）

Weight

Approx. 300g

Mounting method

Tighten from behind the panel with exclusive mounting bracket.

Insulation resistance

Measuring input terminals

–

External Case DC 500 V, More than 100 M

Power supply terminal

–

External Case DC 500 V, More than 100 M

Power supply terminal

–

Measuring input DC 500 V, More than 100 M

Measuring input terminals

–

BCD output DC 500 V, More than 50 M

Measuring input terminals

–

Analog output DC 500 V, More than 50 M

Withstanding voltage

Measuring input terminals

–

External Case AC 2000 V for one minute

Power supply terminal

–

External Case AC 2000 V for one minute

Power supply terminal

–

Measuring input AC1500 V for one minute

Measuring input terminals

–

BCD output AC 500 V for one minute

Measuring input terminals

–

Analog output AC 500 V for one minute

Protective structure

Front operation unit IP65, Case part except front side IP20,

Terminal block IP00

Accessories

Make sure that the following things beside the main body part are included.

471B main unit

Bracket 2 pcs.

Waterproof packing

Quick Manual (This booklet)

(For the model with RS-232C or RS-485, exclusive quick manual is included.)

Unit Sticker

Connector (2m with flat cable) (In case of BCD Output model)

Mounting Method

Mounting pitch

Panel cutout dimensions: 92 0

＋0．8×45 0

＋0．6mm

Panel thickness: 0.6 to 3.5mm (Degree of protection IP65)

3.6 to 10mm (Degree of protection IP20)

If the material of the panel is aluminum, it may

be deformed due to its weak strength. So, it is recommended to use the

thickness of aluminum panel sheet at least 1.5mm.

Mounting Method to Panel

1Insert the main unit fitted with the waterproof packings into the hole, from the panel

front, and insert the attached bracket to the ditch on both sides of the main unit.

Push the bracket as shown by arrow ①until the main unit is stably stays and fix the

bracket. The packings functions as stopper too, so do not remove it. Refer to the

side view of the bracket mounting.

2To fix the main unit more firm, press the back part (center part) of the bracket

indicated by arrow ②by screwdriver, which enhances the stopper strength.

!Caution

When pushing by screwdriver, apply it to the arrow ②

The pushing of other part may cause the damage of bracket.

More than 30mm

More than 130mm

More than 75mm

ECBA D

①

②

①

Push ②

Top view of bracket mounting

Side view of bracket mounting

Bracket

Panel to mount

Waterproof packings

Installation（contd.）

Dismounting

1By extending with fingers the lever outward by about 1mm, as shown in the bracket

lock releasing figure, the lever lock can be released.

2Keep extending the lever outward, slide the bracket backward of the main unit, and

remove it from the ditch.

!Caution

The extension of the lever for long time or the stress to it by metallic

piece like screwdriver may damage the lever.

ECBA D

Lever

About 1mm extension

releases the lock

Enlarged view of

bracket inside

Bracket lock releasing
