Viessmann VITOTRONIC 100 Manuale di istruzioni

VITOTRONIC 100

Boiler control unit

for high temperature heating systems

Vitotronic 100

Model KK5, Part No. 7133 373

Boiler control

For elevated boiler water temperature operation

For heating systems with one high temperature heating

circuit (without mixing valve)

With analog boiler water temperature display

Viessmann quick-connect plug-in system

Technical Data Manual

Certified as a component part

of Viessmann boilers only

5265 489 v1.3 07/2004

Product Information/Standard Equipment/

Application

Viessmann Manufacturing Company Inc.

750 McMurray Road

Waterloo, Ontario •N2V 2G5 •Canada

Tel. (519) 885-6300 •Fax (519) 885-0887

www.viessmann.ca •[email protected]

Viessmann Manufacturing Company (U.S.) Inc.

45 Access Road

Warwick, Rhode Island •02886 •USA

Tel. (401) 732-0667 •Fax (401) 732-0590

www.viessmann-us.com •[email protected]

Product Information

The benefits at a glance:

HSpace heating circuit controlled by

room thermostat

HSingle-stage boiler control

HBuilt-in boiler low temperature

protection

HShort assembly time and start-up due

to diagnostic and Rast-5 plug-in

systems

Modular structure

The control unit consists of:

system ON/OFF switch, temperature

display, pump aquastat for boiler

protection,

–adjustable high limit

(type RAK 51.1/3382, Mfg. Etheco or

type TR 97.55180.251, Mfg. EGO)

–fixed high limit

(type RAK 75.4/3412, Mfg. Etheco or

type STW 56.10525.400, Mfg. EGO)

–electronic circuit board with power

supply

–quick-connect Rast-5 plug-in system

–fixed high limit test terminals

Vitotronic 100,Model KK5

HElectronic boiler control:

–for single-boiler systems

–for heating circuits without mixing

valve

–for a single-stage burner

–with analog temperature display

Boiler-specific functions

The Vitotronic 100 controls the boiler

temperature according to heat demand

input (room thermostat connections).

Boiler water temperature is limited

through the adjustable aquastat.

Minimum boiler water temperature

protection is achieved with the built-in

pump aquastat.

Standard Equipment

Vitotronic 100, Model KK5

(Part No. 7133 373)

with

Hadjustable and fixed high limit

Hbuilt-in pump aquastat

Hpower supply cord

Technical data

Operating Voltage: 120 VAC

Operating Frequency: 60 Hz

Nominal Current: 6A

Power Consumption: 10 W

Certification: CSA certified

(in conjunction with

Viessmann Vitorond boiler)

Max. ambient temperature:

–at operation: 32 to 104 ºF

0to 40ºC

(in rooms and installation sites

with normal ambient conditions)

–when storing or transporting:

–4 to +149 ºF

–20 to +65 ºC

Output rating:

–Heating circuit pump:3 FLA, 120 V

–Burner: 2 FLA, 120 V

Minimum boiler temperature protection

The minimum boiler water temperature is

selected with the adjustable pump

aquastat.

Application

In conjunction with the following Viessmann boilers

Boiler Model and Series

Fuel Minimum boiler water

temperature

without low

limit

with low limit

(average temp.)

Oil-fired hot water

heating boiler with

power burner

Vitorond 200 Oil 104 ºF/40 ºC

5265 489 v1.3 Technical information subject to change without notice. Printed on environmentally friendly

(recycled and recyclable) paper.
