Vivo MOUNT-PC06B Manuale utente

Heavy Duty Under Desk Gaming PC Mount

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

https://vivo-us.com/products/mount-pc06b

SKU: MOUNT-PC06B

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

PACKAGE CONTENTS

TOOLS NEEDED

WARNING!

A1 (x1)

Mount

S-A (x9)

Pad

M-A (x4)

ST5.5x16mm

M-B (x4)

M5 Washer

If you do not understand these directions, or if you have any doubts about the safety of the

installation, please call a qualified technician. Check carefully to make sure there are no missing or

defective parts. Improper installation may cause damage or serious injury. Do not use this product

for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.

We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or

inappropriate use.

Drill

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

ASSEMBLY STEPS

STEP 1

Apply Pads (S-A) to top, bottom, and side of Mount (A) as shown.

33 lbs

(15 kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

Pencil

Phillips

Screwdriver

S-A

STEP 2

STEP 3

STEP 4

STEP 5

Hold Mount (A) in the desired location underneath the desktop, and use a pencil to mark the drilling

location. Using a 5/32” (4mm) drill bit, predrill holes 0.5” (12mm) deep.

Assemble Mount (A) to the desktop

using ST5.5x16mm Screws (M-A),

M5 Washers (M-B) and a Phillips

screwdriver.

Loosen the knob underneath Mount

(A) to adjust the width, and flip the

lever on the side up to adjust the

height. Insert the PC.

Once the PC is in place, tighten

knob underneath Mount (A) and

flip the lever on the side down to

lock it into place.

M-A

M-B

LAST UPDATED: 03/07/2022

REV1.1

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
