White Knight Basic Air Vented Dryer - Parts List
Item Description Code Expl.View
101 Motor & 8µf Capacitor Assembly 4213 092 25611 3
102 Pulley 4213 075 13932 3
112 8µf Capacitor 4213 092 08091 3
125 Drive Belt 4213 092 18601 3
141 Mains Cable & Plug 4213 076 35123 3
142 Terminal Block 4213 078 44613 3
144 Earth Tab Assembly 4213 092 41181 2
196 Cabinet Assembly 4213 092 17761 1
199 Plinth Assembly 4213 092 35741 1
203 Complete Door/Window Assembly 4213 092 28061 1
203a Ignis Door Frame Assembly 4213 092 17771 1
211 Timer MS65 4213 078 55121 1
227 Heating Element 4213 092 38041 1
228 Heat TOC 4213 078 50161 3
229 Thermostat (exhaust) 4213 078 48373 2
230 Thermostat (inlet) 4213 078 56261 3
235 Rocker Switch 4213 078 51061 1
248 Microswitch/Bracket Assembly 4213 092 05251 1 & 2
266 Drum Assembly 4213 092 05531 3
270 Drum Shaft/Bearing Kit 4213 092 05591 3
352 Timer Knob Assembly 4213 092 38401 1
353 Control Panel Assembly 4213 092 38411 1
359 Door Hinge Assembly 4213 092 26071 1
362 Window 4213 077 44094 1
363 Door Frame 4213 077 52694 1
363a Door Insert 4213 077 52982 1
364 Latch Pivot 4213 075 13013 1
365 Latch Spring 4213 075 70833 1
366 Door Latch 4213 077 53413 1
367 Switch Strike 4213 077 83571 1
369 Loom Clip 4213 075 70941 1
370 Latch Guide 4213 077 40992 1
376 Front Panel Assembly 4213 092 18271 1 & 2
385 Top Cover Bracket 4213 077 40923 1
386 Top Cover Assembly 4213 092 21521 1
390 Gasket 4213 074 50862 3
391 Rocker Button 4213 077 59394 1
393 Flex Support Clip 4213 077 40982 3
394 Foot 4213 077 39833 1
395 Heater Wires Clip 4213 075 70971 3
399 Heater Support 4213 080 06619 3
400 Heater Plate 4213 080 14551 3
401 Access Panel Plate 4213 080 06622 2
402 Access Panel 4213 080 06555 3
403 Roller Assembly 4213 092 35651 1
408 Cable Clamp 4213 077 47303 3
413 Back Panel 4213 080 0654B 3
427 Motor Spring Clip 4213 078 45362 3
432 Motor Mount Bracket 4213 080 0675A 3
437 Fixed Rear Vent Assembly 4213 092 06511 2 & 3
440 Banjo Assembly 4213 092 17811 2
441 Front Bearing (short) 4213 077 40952 2
442 Front Seal 4213 077 61701 2
444 Lifter 4213 077 41009 3
445 Front Bearing (long) 4213 077 40962 2
445a Bearing Pads & Brush Seal Kit 4213 092 21171 2
446 Fan 4213 077 40896 2 & 3
447 Access Cover Assembly 4213 092 18081 2 & 3
448 Spring Clip (Fan) 4213 075 71162 2
449 Button Switch Spring 4213 075 71151 1
450 Switch Bracket 4213 070 11631 1
454 Filter 4213 092 17821 2
455 Screw 6 x 10 Countersunk Head 8213 130 30971 2
456 Banjo Seal 4213 077 07991 2
457 J' Clip 2513 482 08002 2
458 Banjo Insert No 2 White 4213 077 40962 2
4213 094 86242
